Advantech McBasic IMC-450 Transceiver/Media Converter

The Advantech McBasic IMC-450 Transceiver/Media Converter is the ultimate solution for enhancing your network's connectivity. Designed to effortlessly bridge the gap between copper and fiber cables, this media converter is perfect for various environments, ensuring reliable communication and seamless integration. With its advanced features, the IMC-450 series extends the reach and scalability of your network while maintaining outstanding performance, making it an essential component for any networking setup.

• High-Speed Connectivity: The IMC-450 series offers a 10/100Mbps copper UTP port alongside a fiber port, guaranteeing fast and reliable data transmission suitable for diverse applications.
• Automatic Link Restoration: Equipped with automatic link restoration, this media converter maintains uninterrupted network connections even during temporary disruptions, ensuring consistent communication.
• Versatile Configuration Options: Available in SFP form factor and options for fixed-fiber in both single-mode and multi-mode, the IMC-450 series caters to a wide array of networking needs.
• Link Fault Pass Through (LFPT): The built-in LFPT functionality allows network operators to easily identify fault conditions, ensuring swift troubleshooting and minimal downtime.
• Multiple Mounting Options: The IMC-450 series supports various mounting configurations, including desktop, DIN rail, or wall-mount options, providing flexibility for installation in any environment.

Technical Details of Product

• Model: Advantech McBasic IMC-450
• Ports: One 10/100Mbps copper UTP port, One fiber port
• Power: Internal AC power supply with optional power security device
• Supported Copper Ports: Optional 10/100/1000Mbps
• Link Fault Pass Through: Enable via dip switch on the front
• Diagnostic Features: Link Loss and Fiber Alert support
• Mounting Options: Desktop, DIN rail, or wall-mount

How to Install

1. Choose an appropriate mounting location for the IMC-450 series based on your network requirements.
2. If using a DIN rail, ensure the rail is securely mounted. For desktop or wall-mount installations, prepare the surface accordingly.
3. Connect the copper UTP cable to the designated copper port on the media converter.
4. Connect the fiber cable to the fiber port, ensuring proper alignment and secure connections.
5. If applicable, configure the dip switch for Link Fault Pass Through as needed.
6. Plug in the internal AC power supply and switch on the device.
7. Verify the link status lights on the front of the unit to ensure successful connections.

Frequently Asked Questions

• What is the maximum distance supported by the IMC-450 series? The distance varies based on the fiber type used (single-mode or multi-mode) and the specific network configuration.
• Can I use SFP modules with the IMC-450 series? Yes, the IMC-450 series supports a range of SFP modules for added flexibility in your networking setup.
• Is installation complicated for the IMC-450 series? No, the installation is straightforward, with multiple mounting options and clear connection points for both copper and fiber cables.
• What is Link Fault Pass Through (LFPT) and how does it work? LFPT allows the media converter to pass fault conditions through to the connected devices, enabling quicker detection and resolution of network issues.
• What types of environments are suitable for the IMC-450 series? The IMC-450 is versatile and can be installed in various environments, including office settings, data centers, and industrial spaces.
