Advantech Slide-In Modular Media Converter 10/100Mbps to Fiber Series

The Advantech IMC-750/751 series represents a premium family of slide-in module Ethernet-to-fiber media converters designed for the IMC-7xx chassis. These hot-swappable modules bring the power of fiber connectivity to copper networks with ease, delivering reliable 10/100 Mbps Ethernet performance through fiber links. Built for seamless integration, the IMC-750/751 modules enable network operators to deploy multiple fiber types and wavelengths within a single network architecture, providing greater flexibility and future-ready scalability without a full network overhaul. With Advantech’s commitment to modularity and manageability, these converters simplify upgrades, support centralized monitoring, and reduce downtime during maintenance or expansion. Whether you’re upgrading a data center, campus, or industrial network, the IMC-750/751 series offers a practical path to extend reach, improve resilience, and optimize fiber utilization while preserving existing copper investments.

• Hot-swappable slide-in design for quick deployment and effortless maintenance inside the IMC-7xx chassis, minimizing downtime and service disruption.
• 10/100 Mbps Ethernet to fiber conversion that enables legacy copper networks to leverage modern fiber infrastructure without replacing existing switches or cabling.
• Support for multiple fiber types and wavelengths within a single network, giving you deployment flexibility to match fiber availability, distance, and performance needs.
• Seamless integration with Advantech’s modular ecosystem, allowing copper and fiber links to coexist within the same chassis and enabling scalable network growth.
• Monitoring and control via centralized management, providing visibility into link status, performance, and diagnostics from a single management point.

Technical Details of Advantech Slide-In Modular Media Converter 10/100Mbps to Fiber Series

• Chassis compatibility: Designed for the IMC-7xx family and inserted as a slide-in module within the chassis.
• Interface: Converts 10/100Base-TX Ethernet to fiber, enabling Ethernet-over-fiber connectivity for extended reach and improved immunity to EMI.
• Fiber support: Enables connections across different fiber types and wavelengths to suit network topology and distance requirements.
• Management: Monitored and controlled via a centralized management approach, providing operational insight and streamlined administration.
• Installation/replacement: Hot-swappable module that allows in-service upgrades and maintenance without powering down the entire chassis.

how to install Advantech Slide-In Modular Media Converter

To install or replace an IMC-750/751 module in an IMC-7xx chassis, follow these general steps to ensure a safe and effective deployment. Always refer to your organization’s change management policies and the chassis user guide for specific procedures and safety precautions.

• Power down the relevant system or confirm that the IMC-7xx chassis supports hot-swapping for the intended module slot, then prepare a clean, static-free workspace.
• Identify the vacant slot in the IMC-7xx chassis where the slide-in module will be inserted, and verify compatibility with the IMC-750/751 module.
• Remove the protective cover or slot filler, and align the module with the chassis connector and guide rails. Ensure the module orientation matches the slot and that all connectors are aligned.
• Gently slide the module into the chassis until it seats securely. Listen for a click or confirm the module is firmly connected to the backplane, then secure any retention screws if required.
• Attach the fiber optic cable to the module’s fiber interface (using the appropriate connector and polarity). Connect the 10/100Base-TX Ethernet cable to the RJ-45 port on the module if required for management or hybrid configurations.
• Power on the chassis (or verify the chassis power state if hot-swapping is supported). Use the centralized management interface to verify module status, link status, and any diagnostic indicators on the module LEDs.
• Configure any required management parameters, such as VLANs, QoS, or monitoring thresholds, through the centralized management console or SNMP-based tools as applicable.
• Perform a basic test by verifying connectivity across the link, confirming link integrity, and observing any alarms or error counters. Document the installation for future maintenance.

Frequently asked questions

• What is the Advantech IMC-750/751 series? A family of slide-in Ethernet-to-fiber media converter modules designed for the IMC-7xx chassis, enabling 10/100 Mbps copper-to-fiber conversions with modular, hot-swappable deployment.
• Are the IMC-750/751 modules hot-swappable? Yes. They are designed for hot-swappable installation, enabling maintenance or upgrades with minimal disruption to network services.
• Which networks benefit from these modules? Networks seeking to extend copper Ethernet links over fiber, improve EMI resistance, and simplify fiber deployment in data centers, campuses, and industrial environments.
• Can I manage IMC-750/751 modules centrally? Yes. The modules are designed to be monitored and controlled via a centralized management approach, giving visibility into link status, performance, and diagnostics across the chassis.
• Do these modules support multiple fiber types and wavelengths? Yes. They are designed to allow integration of different fiber types and wavelengths within the same network, enabling flexible and scalable deployments.
