Allied Telesis L3 Switch: 16 x 10/100/1000T Ports + 1 x 100/1000X SFP Port

The Allied Telesis x230 Series Layer 3 switches deliver enterprise-grade routing and switching in a compact, edge-ready package. Designed for modern networks that demand fast, reliable access with smart traffic control, this L3 switch combines 16 copper Gigabit ports with a single fiber uplink to create a flexible, scalable foundation for small to mid-size offices, branch sites, and campus edge deployments. Whether you’re consolidating access, segmenting networks with VLANs, or enabling efficient inter-VLAN routing, this device is built to handle growing workloads while simplifying management and provisioning.

• Flexible copper and fiber connectivity: 16 x 10/100/1000T copper ports paired with 1 x 100/1000X SFP uplink give you versatile access to end devices and a high-speed fiber backbone for uplinks to core networks or distribution switches.
• Layer 3 routing for edge networks: This switch offers robust Layer 3 capabilities that enable efficient traffic routing at the network edge, reducing congestion and improving overall performance for distributed environments.
• Advanced traffic management: Built-in features such as VLANs, QoS, and access control mechanisms help prioritize critical applications, isolate broadcast domains, and safeguard networks against irregular traffic spikes.
• Comprehensive management options: Intuitive web-based management alongside CLI access and SNMP support provides flexible administration, making configuration, monitoring, and troubleshooting straightforward for IT teams of all sizes.
• Durable, compact design for edge deployments: The 1U form factor is ideal for rack-mounted setups in offices and smaller data centers, offering reliable operation in demanding environments while minimizing rack space requirements.

Technical Details of Allied Telesis L3 Switch with 16 x 10/100/1000T Ports and 1 x 100/1000X SFP Port

• Model family: Allied Telesis x230 Series Layer 3 switch, designed for edge networking and compact deployments.
• Port configuration: 16 x 10/100/1000T copper Ethernet ports and 1 x 100/1000X SFP fiber uplink for fast, flexible connectivity.
• Layer 3 capabilities: Supports routing at the network edge with IPv4/IPv6 capabilities, enabling static routing and basic dynamic routing options to simplify inter-site connectivity.
• Traffic control and security: VLAN support, Quality of Service (QoS) features, and access controls to manage broadcast domains and prioritize critical applications.
• Management interfaces: Web GUI for quick setup, a command-line interface for fine-tuned configuration, and SNMP for integration with centralized monitoring systems.
• Performance characteristics: Non-blocking or high-efficiency switching fabric tailored for steady, predictable performance under typical office and campus-edge loads.
• Physical design: 1U rack-mountable chassis with durable construction designed to endure 24/7 operation in professional environments.
• Power and cooling: Designed to operate within standard data center and office power environments, with considerations for energy efficiency and thermal management in compact spaces.

How to Install Allied Telesis L3 Switch

• Prepare and inspect: Unpack the switch and verify that all accessories are present (rack ears, mounting hardware, power cable). Inspect the unit for any transport damage before installation.

• Rack mounting: Install the switch in a standard 19-inch rack using the supplied rack ears. Secure the unit with screws to prevent movement during operation.

• Power and cabling: Connect the power cord to a reliable power source. Attach copper devices to the 16 x 10/100/1000T ports using appropriate Ethernet cables. Insert the 100/1000X SFP module into the uplink port and connect the fiber optic cable to the SFP transceiver.

• Initial access and configuration: Access the switch management interface via the default IP address or console port, then begin with a basic configuration: assign an management IP, set up a secure administrator account, and enable essential services such as SSH for secure remote access.

• Networking setup and validation: Create VLANs as needed, configure inter-VLAN routing or static routes for sites, apply QoS policies for critical applications, and implement access controls. Validate connectivity across end devices, test uplink performance, and monitor the switch using SNMP or the built-in dashboards to ensure the deployment meets expected performance benchmarks.

Frequently Asked Questions

• Q: What is the primary use case for this Allied Telesis L3 switch?

  A: It is designed for edge and distribution-layer deployments where a compact, feature-rich Layer 3 switch is needed to provide reliable access, basic routing, VLAN segmentation, and QoS for small to mid-sized networks.

• Q: How many copper and fiber connections does it support?

  A: The unit provides 16 copper 10/100/1000T ports for end-device connectivity and 1 x 100/1000X SFP port for a fiber uplink, enabling flexible deployment options.

• Q: Can I manage this switch remotely?

  A: Yes. It includes web-based management, a command-line interface, and SNMP for integration with centralized network management systems, making it straightforward to monitor and configure from a central location.

• Q: Does it support IPv4 and IPv6 routing?

  A: The switch supports Layer 3 routing with IPv4 and IPv6 capabilities, enabling static routing and other routing options to connect multiple networks efficiently at the edge.

• Q: What deployment environments is it best suited for?

  A: It is ideal for small to medium offices, branch offices, and campus edge deployments where reliable access, straightforward management, and scalable performance are essential.

• Q: How should I install and configure VLANs and QoS?

  A: VLANs are created per the network design to segment traffic, while QoS policies prioritize time-sensitive applications. The exact steps are available in the web GUI or CLI guide and can be tailored to your traffic profiles.
