Allied Telesis Transceiver/Media Converter — 1x RJ-45 and 1x SC Gigabit Bridge

Discover a flexible, high-performance solution for connecting copper Ethernet networks to fiber infrastructure with the Allied Telesis Transceiver/Media Converter. Designed for desktop deployment with optional wall-mount compatibility, this device combines a 1 x Network (RJ-45) port supporting Gigabit Ethernet (1000Base-T) with 1 x SC fiber port (1000Base-X) to deliver reliable, scalable data transmission across mixed-media networks. Built for enterprise workgroups, data centers, campuses, and lab environments, it helps future-proof your network by enabling seamless upgrades from copper to fiber while preserving existing investments. Enjoy automatic negotiation, auto MDI/MDI-X, and intelligent link management features that reduce configuration complexity and boost uptime. This transceiver/media converter is RoHS compliant, ensuring compliant materials and safer handling in modern office and technical settings.

• Interface versatility: 1 x copper Network (RJ-45) port supporting 10/100/1000 Mbps and 1 x SC fiber port supporting 1000Base-X, enabling copper-to-fiber bridging in a single, compact unit.
• Smart, automated operation: Auto Negotiation and Auto MDI/MDI-X simplify installation by automatically configuring port speed and crossover settings to match connected devices.
• Reliability features: Smart Link Restoration, Link Test, and Smart MissingLink help maintain network integrity and uptime even in the presence of transient faults or link degradation.
• Flexible mounting options: Desktop use with optional wall-mount capability via AT-DMCWLMT (sold separately) for space-efficient deployments in dense office or equipment rooms.
• Compliance and footprint: RoHS-compliant design delivering a compact, energy-conscious footprint suitable for busy networks requiring dependable performance without compromising environmental standards.

Technical Details of Allied Telesis Transceiver/Media Converter

• Port configuration: 1 x Network (RJ-45) port (Gigabit Ethernet 1000Base-T) and 1 x SC fiber port (1000Base-X).
• Standards supported: 1000Base-T (copper) and 1000Base-X (SC fiber).
• Power: AC powered power input (external power supply not specified in the provided details).
• Form factor: Desktop unit with optional wall-mount capability using AT-DMCWLMT (sold separately).
• Compliance: RoHS compliant for safer, environmentally responsible deployment.
• Key features: Auto Negotiation, Auto MDI/MDI-X, Smart Link Restoration, Link Test, Smart MissingLink, and Transparent operation to ensure compatibility with a wide range of switches, NICs, and fiber modules.
• Applications: Ideal for mixed-media networks requiring copper-to-fiber bridging, distance extension, or segmentation between LAN segments without replacing existing cabling infrastructure.

How to install Allied Telesis Transceiver/Media Converter

• Power down the network devices you will connect to the transceiver/media converter to prevent any electrical damage during installation.
• Connect your copper device (switch, router, or NIC) to the RJ-45 port on the transceiver/media converter using a Category 5e/6 Ethernet cable rated for Gigabit speeds.
• Attach the fiber link to the SC port using the appropriate 1000Base-X fiber module and fiber type (single-mode or multi-mode) as required by your network design and the connected equipment. Ensure the transceiver and fiber module are compatible and properly seated.
• Power on the unit and the connected devices. Check the LED indicators on the transceiver/media converter to confirm link status, activity, and power. If a link is not established, verify cable quality, port speed settings, and fiber module compatibility.
• Place the device on a stable surface or mount it using the AT-DMCWLMT wall-mount accessory (sold separately) for secure, space-efficient installation. Maintain adequate ventilation and avoid enclosing the unit in confined spaces that could lead to overheating.
• Allow Auto Negotiation to synchronize speeds and duplex modes with connected devices. Because Auto MDI/MDI-X is enabled, the unit will automatically adjust the cable type needed for correct communication, reducing the need for manual crossover cables.

Frequently asked questions

• What does the Allied Telesis Transceiver/Media Converter do? It bridges copper Ethernet networks (RJ-45) with fiber networks (SC), providing a single device that supports 1000Base-T on copper and 1000Base-X on fiber for seamless data transfer between media types.
• Does it support auto negotiation? Yes. Auto Negotiation allows the device to automatically select the optimal speed and duplex mode for connected equipment, simplifying installation and ensuring compatibility.
• Is wall-mounting possible? Yes, the unit is desktop-ready and can be wall-mounted using the AT-DMCWLMT accessory (sold separately) to fit various workspace layouts and rack-free environments.
• Is the device RoHS compliant? Yes. The transceiver/media converter adheres to RoHS standards, aligning with modern environmental and safety requirements.
• What kind of fiber should I use? The SC port supports 1000Base-X, which requires a compatible 1000 Mbps fiber module and appropriate single-mode or multi-mode fiber depending on your network distance and design. Always verify compatibility with your fiber transceiver and network equipment before deployment.
