APC Galaxy VS Maintenance Bypass Cabinet — Single Unit, 10–100 kW, 77.6 in Tall

The APC by Schneider Electric Galaxy VS Maintenance Bypass Cabinet is engineered to keep critical power protection systems available for service without compromising uptime. Designed as a single-unit maintenance bypass solution, this cabinet provides complete isolation of the Galaxy VS UPS during maintenance operations, enabling technicians to perform routine checks, component replacements, or firmware updates with minimal risk to the protected load. Standing tall at 77.6 inches, the cabinet pairs seamlessly with Galaxy VS modular UPS configurations, delivering a robust, scalable, and secure bypass path that aligns with data center and enterprise facility standards.

• Complete UPS isolation during maintenance: The maintenance bypass cabinet creates a safe bypass path so technicians can service the Galaxy VS UPS without interrupting critical loads, preserving uptime and protecting sensitive equipment.
• Flexible 10–100 kW compatibility: Engineered to accommodate Galaxy VS UPS configurations in the 10–100 kW range, this cabinet supports a broad spectrum of mission-critical environments and load profiles.
• Rugged, data-center-grade construction: Built to withstand the rigors of demanding data center environments with a durable, cabinet-style enclosure that integrates with standard rack layouts and cable management systems.
• Included installation guide for a streamlined setup: The cabinet ships with a comprehensive installation guide, helping technicians assemble, wire, and commission the bypass system quickly and safely.
• Optimized vertical footprint for efficient space use: At 77.6 inches tall, the cabinet maximizes vertical space while maintaining accessibility for service and maintenance tasks within data halls and dedicated maintenance areas.

Technical Details of APC Galaxy VS Maintenance Bypass Cabinet

• Product family: APC Galaxy VS Maintenance Bypass Cabinet
• Configuration: Single-unit maintenance bypass cabinet
• Power rating support: 10–100 kW Galaxy VS UPS configurations
• Height: 77.6 inches
• Purpose: Provides complete isolation of the Galaxy VS UPS during service operations
• Included documentation: Installation guide included
• Compatibility: Designed for use with Galaxy VS modular UPS family

How to install APC Galaxy VS Maintenance Bypass Cabinet

Installing the APC Galaxy VS Maintenance Bypass Cabinet is a disciplined, safety-focused process that should follow the guidance in the included installation guide. The cabinet is intended to be integrated with Galaxy VS UPS units in the 10–100 kW range, delivering a reliable bypass path that enables maintenance operations without compromising the protection of connected loads. Before beginning, verify that all appropriate safety procedures are in place, and ensure you have access to the required tools and cabling per the documentation.

• Prepare the installation area by ensuring adequate clearance for service access, cable routing, and ventilation. Confirm that the floor is rated to support the cabinet’s weight and that grounding is in place according to local electrical standards.
• Position the cabinet in a location that provides convenient access to the bypass switch, input and output connections, and maintenance interfaces. Align the unit with the Galaxy VS UPS and adjacent equipment to minimize cable length and optimize airflow.
• Mount and secure the cabinet according to the installation guide. Verify that the cabinet is level and that all mounting points are fastened to maintain structural integrity during maintenance operations.
• Connect the electrical interfaces following the wiring diagrams in the documentation. This includes input power, bypass path, and load connections, ensuring conductors are appropriately sized and protected with the correct devices as specified for the Galaxy VS configuration.
• Perform a controlled commissioning sequence. Validate interlocks, confirm the bypass path actuates correctly, and verify that the UPS can be isolated and reconnected to the load without adverse effects. Document the test results and retain the installation records for future reference.

Frequently asked questions

• Q: What is the primary purpose of the Galaxy VS Maintenance Bypass Cabinet?

  A: Its primary purpose is to provide a safe, isolated bypass path around the Galaxy VS UPS during maintenance operations, allowing technicians to service the UPS without interrupting critical loads.

• Q: Is this cabinet compatible with Galaxy VS UPS in the 10–100 kW range?

  A: Yes. The cabinet is designed to work with Galaxy VS UPS configurations within the 10–100 kW power range and is sized for a single-unit installation.

• Q: What are the key physical characteristics?

  A: The cabinet is a single-unit maintenance bypass enclosure with a height of 77.6 inches, designed to integrate with standard data center rack environments and service spaces.

• Q: What documentation accompanies the cabinet?

  A: An installation guide is included to assist with assembly, wiring, and commissioning, ensuring a safe and compliant setup.

• Q: How does maintenance bypass impact uptime?

  A: By allowing safe isolation of the UPS for service activities, it minimizes the risk of unplanned downtime and helps ensure continual power protection for critical loads during maintenance.
