Description
APC by Schneider Electric PDRDPF10U-R 28.8kVA PDU
Maximize data-center uptime and streamline power management with the APC by Schneider Electric PDRDPF10U-R 28.8kVA PDU. This high-performance, scalable power distribution unit delivers real-time branch current monitoring, configurable threshold settings, and both local and advanced remote notifications to keep you informed wherever you are. Designed for critical IT environments, the PDRDPF10U-R helps data centers optimize energy use, prevent overloads, and simplify operations through a configure-to-order (CTO) process that supports factory-installed breakers, branch circuit monitoring boards, load-test ports, and more. With its robust monitoring capabilities and seamless integration with the broader Schneider Electric EcoStruxure ecosystem, this PDU is an essential component for any data center, network room, or high-density server rack.
- Real-time branch current monitoring and proactive alerts: Stay on top of power usage with continuous, precise monitoring of each branch circuit. The PDRDPF10U-R provides actionable data and threshold-based alerts, enabling rapid response to overloads and voltage sags before they impact critical workloads. This capability reduces downtime, protects equipment, and supports proactive capacity planning in mixed-load environments. The system supports local indicators and remote notifications, so administrators can act quickly from on-site or off-site locations.
- Configure-to-Order (CTO) for factory-installed options: The CTO process enables APC to tailor the PDU to your exact needs, with factory-installed breakers, branch circuit monitoring boards, load-test ports, and related hardware tested before shipment. This reduces on-site installation time, minimizes field assembly, and ensures correct wiring and calibration, delivering a more reliable deployment from day one. CTO configurations help you align the PDU with your network architecture and contingency plans, ensuring consistent performance under peak demand.
- Advanced notification and role-based access: The PDRDPF10U-R supports both local and advanced remote notification, delivering alerts via email, SNMP traps, or secure dashboards. Operators, facilities teams, and IT administrators can set alert thresholds for current, voltage, power factor, and temperature, ensuring everyone has the right visibility for their role. With centralized monitoring, you can correlate PDU data with rack density, cooling metrics, and workload patterns to optimize overall data-center efficiency.
- Rugged design for demanding IT environments: Built to withstand the rigors of modern data centers, the PDRDPF10U-R integrates a robust enclosure, reliable switchgear, and rigorous testing to ensure consistent performance under continuous load. Its design supports hot-swappable components and scalable configurations, making it suitable for growing IT environments, high-density racks, and deployments that demand dependable power distribution with minimal maintenance.
- Seamless integration with Schneider Electric EcoStruxure and ecosystem tools: The PDU is designed to work within Schneider Electric’s comprehensive energy-management ecosystem. It integrates with EcoStruxure IT, data-center infrastructure management (DCIM) platforms, and familiar IT workflows, enabling unified visibility across power, cooling, and IT assets. This integration simplifies reporting, capacity planning, and automation, helping you maximize energy efficiency and optimize investment in infrastructure over the long term.
Technical Details of APC by Schneider Electric PDRDPF10U-R 28.8kVA PDU
- Brand: APC by Schneider Electric
- Model: PDRDPF10U-R
- Power rating: 28.8 kVA
- Type: Power Distribution Unit with branch current monitoring
- Monitoring: Real-time branch current monitoring with threshold alerts
- Notification: Local and remote alerting (email/SNMP/tray dashboards)
- Configure-to-Order (CTO): Factory-installed breakers, branch monitoring boards, load-test ports
- Networking: Supports integration with EcoStruxure IT and DCIM tools
- Application: Data centers, server rooms, telecommunications closets, and other critical IT environments
- Certifications: Intended to meet industry standards for reliability and safety (specific certifications vary by configuration)
how to install APC by Schneider Electric PDRDPF10U-R 28.8kVA PDU
- Plan placement and rack compatibility: Verify you have adequate rack space and a compatible mounting surface for the 10U form-factor PDU. Confirm clearance for cable management and access to monitoring ports.
- Prepare rack and cabling: Power down the relevant equipment as needed, and route power distribution cables to the PDU. Use proper cable-management practices to minimize strain on connectors and maintain airflow.
- Install and secure the PDU: Mount the unit securely in the rack, ensuring stable installation to withstand typical data-center vibrations and movement. Tighten mounting screws, verify alignment, and confirm there is no interference with other equipment or cooling paths.
- Configure CTO options and monitoring: If your configuration includes CTO-installed breakers or monitoring boards, verify their connections and perform initial calibration. Configure branch-current thresholds, alert recipients, and notification methods through the PDU’s interface or your DCIM/EcoStruxure portal.
- Test and validate: Power up the PDU and connected equipment. Validate real-time monitoring data, test alert delivery, and confirm that load-test ports and any remote-management features operate correctly. Document the configuration for future audits and maintenance.
Frequently asked questions
- What is the APC PDRDPF10U-R 28.8kVA PDU? It is a high-capacity power distribution unit designed for data centers and IT environments, featuring real-time branch current monitoring, threshold-based alerts, and remote notification. It supports CTO options for factory-installed breakers, monitoring boards, and load-test ports to tailor the unit to your specific deployment needs.
- What advantages does branch current monitoring provide? Branch current monitoring gives visibility into the load on each circuit, enabling early detection of overloading, improved capacity planning, and better overall power management in dense rack environments.
- How does the CTO process benefit my deployment? The CTO process allows APC to pre-install and test required components (breakers, monitoring boards, load-test ports) at the factory, reducing on-site complexity, shortening installation times, and ensuring correct configuration from the outset.
- Can this PDU integrate with EcoStruxure IT and DCIM tools? Yes. The PDRDPF10U-R is designed to work within Schneider Electric’s EcoStruxure ecosystem and supports common DCIM integrations for centralized monitoring and analytics.
- What kind of notifications will I receive? The unit supports local indicators and remote notifications, including email and SNMP traps, so you can alert facilities and IT staff as soon as a parameter exceeds its threshold.
- Is installation difficult for non-technical staff? While the CTO options simplify many steps, it is recommended to have a qualified technician perform rack installation, electrical connections, and initial configuration to ensure safety and compliance with local codes.
