APC KVM Sun Server Module - RJ-45 Female, HD-15 Male, mini-DIN Male

The APC KVM Sun Server Module is a purpose-built interface designed to streamline control of Sun-based servers within modern KVM environments. This compact accessory brings together three essential connectors—RJ-45 Female, HD-15 Male, and mini-DIN Male—so you can bridge keyboard, video, and mouse signals with ease. Built for reliability in data centers, server rooms, and IT closets, this module delivers signal integrity, rugged durability, and plug-and-play convenience. Whether you’re upgrading legacy Sun hardware or integrating older servers into a contemporary APC KVM setup, this module makes it simple to maintain precise control, reduce downtime, and keep your operations running smoothly.

• Versatile connector trio for legacy and modern systems: The RJ-45 Female, HD-15 Male, and mini-DIN Male configuration is designed to support Sun keyboard, monitor, and mouse signaling within KVM environments. This combination enables you to connect Sun-era peripherals to current KVM switches without purchasing multiple adapters, simplifying cable management and reducing clutter in crowded racks.
• Reliable video and peripheral signaling: The HD-15 Male interface handles standard VGA-style video, ensuring compatibility with a wide range of monitors and KVM displays. Paired with the RJ-45 and mini-DIN connections, it provides a cohesive pathway for keyboard, video, and mouse signals to travel cleanly between server hardware and control consoles.
• Durable, rack-ready construction: Built for data-center use, this module features shielded connectors and rugged housing designed to withstand frequent plug-and-unplug cycles, temperate rack environments, and the rigors of daily IT operations. Expect long-term reliability even under dense cabling and high-traffic cross-connections.
• Ease of installation and maintenance: This module is engineered for quick, tool-free setups. Simply align the RJ-45, HD-15, and mini-DIN connectors with their corresponding ports on your KVM switch and Sun server, then secure connections. The result is a stable, low-latency link that minimizes downtime during maintenance windows or server migrations.
• Broad compatibility for mixed environments: While tailored for APC KVM ecosystems, the module supports cross-brand configurations that require Sun-era signaling. This flexibility helps IT teams consolidate management across diverse server fleets, protect existing investments, and create scalable control points without replacing older hardware.

Technical Details of APC KVM Sun Server Module

• Connector types: RJ-45 Female, HD-15 Male, mini-DIN Male—precisely arranged to carry keyboard, video, and mouse signals in a single, compact interface.
• Product category: KVM cable/adapter module designed for Sun server connections within APC KVM environments.
• Material and build: High-quality, shielded connectors with a robust housing to endure daily rack usage and cable manipulation.
• Compatibility notes: Intended for use with APC KVM switches and Sun-based servers requiring these connector configurations; suitable for mixed hardware setups where legacy Sun peripherals must work alongside modern KVM infrastructure.
• Condition: New, unused, and sourced to meet APC accessory standards and performance expectations.
