APC Maintenance Bypass Cabinet - 15kVA

This APC Maintenance Bypass Cabinet is engineered to protect your uptime by providing a dedicated bypass path around the UPS for maintenance, battery replacement, or firmware updates without interrupting critical loads. With a 15kVA rating, it’s a robust solution for data centers, networking rooms, and industrial facilities that demand reliable power continuity. The cabinet integrates seamlessly with APC (Schneider Electric) systems and is designed to simplify service operations while maintaining safety and compliance in demanding environments.

• Uninterrupted uptime during maintenance: The bypass cabinet creates a secure bypass path that carries the load while the UPS undergoes service, ensuring essential systems stay online and preventing costly downtime.
• Secure, rugged enclosure: Constructed from heavy-duty steel with lockable access, the cabinet is built to withstand demanding environments, resist tampering, and maintain organizational safety standards.
• 3-phase, 208/230V compatibility: Engineered for common data center power architectures, the unit supports standard 3-phase, 4-wire configurations used in modern facilities.
• Safe, compliant operation: Integrated isolation mechanisms and clearly labeled controls provide safer maintenance workflows and clearer fault isolation for technicians.
• Easy integration and serviceability: Front-access design, modular components, and straightforward wiring paths reduce installation time and minimize downtime during service windows.

Techncial Details of APC Maintenance Bypass Cabinet

• Power rating: 15 kVA
• Configuration: 3-phase, 4-wire
• Nominal input/output voltage: 208/230 V AC
• Enclosure: Heavy-duty steel, lockable doors
• Mounting type: Free-standing cabinet designed for data centers and industrial facilities
• Safety features: Isolation switches and clear labeling to support safe maintenance operations

how to install APC Maintenance Bypass Cabinet

• Step 1: Plan and prepare - Review the facility power layout, confirm the UPS compatibility for maintenance bypass, and ensure the site meets clearance requirements for service access and ventilation. Coordinate with facility management and any on-site electrical personnel before proceeding.
• Step 2: Position and secure - Place the cabinet in a stable, well-ventilated area near the UPS and distribution paths. Secure the enclosure to the floor as required by local electrical codes and facility standards.
• Step 3: Connect utility input - Run appropriately rated three-phase conductors from the utility feed to the cabinet’s input lugs or terminal block. Verify correct phase rotation and provide proper grounding per NEC/IEC standards.
• Step 4: Connect UPS input and load output - Connect the bypass cabinet’s output to the UPS input as specified by the APC configuration for your model, and route the load to the data center distribution or critical equipment panel. Ensure all connections are tight and properly insulated.
• Step 5: verify and test - After enclosure doors are closed and secured, power up the system and verify indicator lights. Perform a bypass test with simulated load under supervision, confirming smooth transfer and safe operation throughout the test procedure.

Frequently asked questions

• What is a maintenance bypass cabinet? A maintenance bypass cabinet provides a dedicated, standalone bypass path around the UPS to power critical loads during UPS maintenance, battery replacement, or firmware updates, eliminating downtime for essential systems.
• Why would I need a 15kVA APC maintenance bypass cabinet? If your facility relies on uninterrupted power for critical equipment and you operate a 15 kVA UPS, a maintenance bypass cabinet helps you perform service tasks without interrupting the load, improving reliability and reducing risk during maintenance windows.
• Is it compatible with all APC UPS models? The cabinet is designed to work with APC UPS systems that support external maintenance bypass configurations. Always confirm model compatibility with your specific APC/Schneider Electric UPS and consult the datasheet or an authorized distributor.
• Will installation disrupt power? Properly configured, the bypass path allows service to proceed without interrupting the critical load. A controlled transfer sequence ensures safety, and technicians should follow established commissioning procedures.
• Where can I purchase or get support? This cabinet is sold through APC by Schneider Electric channel partners and authorized distributors. For exact SKUs, UPCs, and availability, contact your local APC representative or approved reseller.
