APC Symmetra LX 16kVA Rack-Mount UPS – N+1 Redundancy, 208/240V

High-performance, redundant power protection with scalable power and runtime for space-constrained server rooms, and voice and data networks. The APC Symmetra LX 16kVA is engineered to deliver reliable power for critical workloads while maximizing uptime and efficiency. Built for data centers that demand modularity, easy maintenance, and intelligent management, this rack-mount UPS offers flexible configuration options to fit growing workloads and tight floor plans.

• Scalable power and runtime—a modular design that grows with your needs. Add power modules and battery cabinets to expand capacity and runtime without replacing the entire system, protecting investment as IT demand scales.
• N+1 redundancy for high availability—architected to keep critical loads online during maintenance or component failures, delivering enterprise-grade continuity for essential services.
• Modular, hot-swappable design—power modules and batteries can be swapped without powering down connected equipment, minimizing maintenance windows and reducing downtime risk.
• 208/240V input and rack-mount form factor—space-efficient footprint designed for dense server rooms while delivering robust UPS protection for mid-to-large deployments.
• Advanced management and monitoring—integrated management interfaces and remote monitoring enable proactive control, reporting, and capacity planning for IT teams managing distributed environments.

Technical Details of APC Symmetra LX 16kVA

• Power rating: 16 kVA nominal, scalable with N+1 redundancy to support continuous operation of connected loads.
• Input voltage: 208/240 VAC input configuration suitable for enterprise rack installations.
• Output voltage: 208/240 VAC configurable to match IT equipment requirements.
• Form factor: Rack-mount modular UPS with hot-swappable power modules and battery packs to minimize downtime.
• Management: Integrated monitoring with network-ready interfaces and compatibility with APC management software for remote visibility and control.

How to install APC Symmetra LX 16kVA

• Plan the installation by confirming rack space, ventilation, electrical capacity, grounding, and cable paths. Ensure the environment meets the UPS’s airflow and clearance requirements for optimal cooling and maintenance access.
• Mount the UPS chassis in the rack, secure with the included hardware, and verify stability before proceeding with electrical connections.
• Connect the input power to a suitable 208/240V feed that matches the UPS configuration. Ensure all input breakers, cables, and protective devices are rated for the load and comply with local electrical codes.
• Install any additional power modules and battery cabinets required for the initial capacity and desired runtime. Connect modules and batteries following the manufacturer’s wiring diagrams, and secure all connections.
• Connect critical loads to the UPS output and verify proper labeling and circuit protection on each branch. Confirm grounding integrity and perform a basic load balance check to prevent overloads.
• Power up the system and configure management settings via the built-in interface or via APC’s remote management software. Run the recommended self-tests, calibration, and battery health checks to validate operation before placing the system into service.

Frequently asked questions

Q: What applications is the Symmetra LX 16kVA best suited for?

A: It is ideal for data centers, server rooms, and network backbones that require scalable, redundant power protection with a compact footprint and flexible runtime options for growing IT environments.

Q: Does the Symmetra LX support N+1 redundancy?

A: Yes. The system is designed to operate with N+1 redundancy, providing uninterrupted protection for critical workloads during maintenance or component failures.

Q: Can I manage the UPS remotely?

A: Absolutely. The Symmetra LX includes integrated management interfaces and supports remote monitoring, alerts, and reporting through APC’s management software and standard network protocols.

Q: Are power modules and batteries hot-swappable?

A: Yes. The modular architecture enables hot-swapping of power modules and battery cabinets without powering down protected loads, minimizing downtime and enabling faster maintenance.

Q: Is the UPS compatible with 208V and 240V IT environments?

A: Yes. The unit is designed to operate with both 208V and 240V configurations to accommodate common enterprise IT deployments and regional electrical standards.
