Asus RS500A-E12-RS12U-12W12B Barebone System — AMD EPYC 9004 1U Rack-Mount Server

Experience unparalleled density and performance in a compact 1U chassis with the Asus RS500A-E12-RS12U-12W12B Barebone System. Built for data centers, virtualization clusters, AI inference, and resource-intensive workloads, this AMD EPYC 9004-based platform delivers the core power, memory bandwidth, and flexible I/O you need to scale efficiently. Designed around a single Socket SP5 LGA-6096 socket, it accommodates the demanding workloads of modern enterprise environments while leaving room for your memory, storage, accelerators, and network options to grow. With up to 96 Zen 4 cores, 24 DIMMs of DDR5 memory across 12 channels, and generous NVMe and PCIe 5.0 expansion, the RS500A-E12-RS12U-12W12B is a versatile foundation for high-performance infrastructure in a compact form factor.

• High-performance CPU and memory architecture: Powered by the AMD EPYC 9004 processor with up to 96 Zen 4 cores, this 1U barebone delivers exceptional multi-thread performance for virtualization, databases, AI workloads, and dense compute tasks. It supports 12-channel DDR5 memory at speeds up to 4800 MT/s, enabling wide memory bandwidth and fast data access across up to 24 DIMMs for large in-memory databases, virtualized environments, and memory-intensive applications.
• Exceptional storage and memory capacity: Configure a data-centric platform with up to 24 DIMMs and up to 16 NVMe drives, plus two M.2 slots for OS, cache, or scratch storage. The combination of abundant DDR5 RAM, NVMe, and M.2 options ensures fast boot times, rapid data access, and responsive applications, while giving you ample headroom to handle peak workloads and future growth.
• Robust expansion and GPU readiness: The RS500A-E12-RS12U-12W12B provides three PCIe 5.0 expansion slots for accelerators, high-speed NICs, or other add-in cards, and supports OCP 3.0 network adapters for flexible data center networking. Two single-slot GPUs can be installed to accelerate AI inference, graphics processing, or specialized workloads, while maintaining a streamlined 1U footprint for efficient rack density.
• Enterprise management and reliability: Seamless remote management is enabled by ASUS ASMB11-iKVM, enabling secure remote console access, monitoring, and management. The 1U rack-mountable barebone design emphasizes serviceability and efficient deployment in data centers and server rooms, helping IT teams install, monitor, and maintain the system with ease.
• Flexible, OS-agnostic deployment: This barebone platform is engineered for broad compatibility across operating systems and virtualization environments. Its modular design and expansive I/O make it easy to tailor the RS500A-E12-RS12U-12W12B to diverse workloads — from virtualization hosts and private clouds to data analytics and high-performance computing clusters — while enabling straightforward upgrades as your infrastructure evolves.

Technical Details of Asus RS500A-E12-RS12U-12W12B

• Form Factor: 1U Rack-Mountable Barebone System
• Processor Socket: Socket SP5 LGA-6096
• CPU: AMD EPYC 9004 (single-processor configuration)
• Core Count: Up to 96 Zen 4 cores
• Memory: Up to 24 DIMMs, DDR5, 12-channel, up to 4800 MT/s
• Storage Options: Up to 16 NVMe drives and 2x M.2 slots
• Expansion Slots: 3 x PCIe 5.0 slots
• Networking Expansion: OCP 3.0 support for flexible NICs
• Graphics: Supports two single-slot GPUs
• Management: ASUS ASMB11-iKVM
• Other: Designed for enterprise workloads with dense performance in a compact 1U form factor

how to install Asus RS500A-E12-RS12U-12W12B

Follow these steps to assemble and deploy the Asus RS500A-E12-RS12U-12W12B barebone system in a data center rack. This guide assumes you are installing a single AMD EPYC 9004 processor and configuring memory, storage, and expansion cards as part of a standard enterprise deployment. Always consult your data center policies and safety guidelines before starting.

• Prepare the rack and chassis: Ensure the rack rail kits are installed and aligned. Verify power availability and grounding. Confirm that the chassis is clean, free of obstructions, and positioned for easy access to the front and rear panels.
• Install the processor into Socket SP5 LGA-6096: Open the processor socket, align the AMD EPYC 9004 CPU to the indicated orientation, and secure the latch. Apply an appropriate amount of thermal paste if required and attach the heatsink or cooling solution per the included guidelines. Ensure proper seating and clearance for airflow.
• Populate memory modules (up to 24 DIMMs): Insert DDR5 memory modules into the DIMM slots across the channels, following the manufacturer’s recommended population order for optimal performance. Verify that each module is fully seated and that memory is detected by the system during POST.
• Install storage devices: Add up to 16 NVMe drives in the designated NVMe bays and place up to 2 M.2 drives for OS or cache storage. Secure drives according to the chassis’ guidelines and ensure correct drive hot-swap or non-hot-swap configurations as required by your deployment.
• Install PCIe add-ins and GPUs (if used): Insert PCIe 5.0 expansion cards into the available slots. If using GPUs, mount single-slot GPUs as supported and secure with screws. Attach any required power or auxiliary connectors and verify physical clearance for airflow and cables.
• Connect power, networking, and management: Attach the power cables, connect OCP NICs if used, and ensure remote management features are accessible via the ASMB11-iKVM. Power on the system and enter the BIOS/UEFI setup to configure boot order and device recognition as needed.
• Initial boot and validation: Run POST checks, verify CPU, memory, storage, PCIe devices, and GPUs are detected, and apply any firmware or BIOS updates from ASUS support if available. Confirm that remote management is functioning correctly for ongoing administration.
• Software deployment and monitoring: Install your preferred operating system or hypervisor, configure networking, and begin deploying workloads. Use ASMB11-iKVM for ongoing remote monitoring, firmware updates, and health checks to ensure reliable operation.

Frequently asked questions

• Q: What processor does the ASUS RS500A-E12-RS12U-12W12B support? - A: It is designed for a single AMD EPYC 9004 processor in the Socket SP5 LGA-6096 socket.
• Q: How many memory modules can the system accommodate? - A: Up to 24 DIMMs, using a 12-channel DDR5 memory configuration with speeds up to 4800 MT/s.
• Q: What storage options are available? - A: The platform supports up to 16 NVMe drives and 2 M.2 slots for OS, cache, or additional storage.
• Q: How many PCIe 5.0 expansion slots are there, and can GPUs be used? - A: There are three PCIe 5.0 slots, and the system supports two single-slot GPUs for AI, HPC, or virtualization workloads.
• Q: Is remote management available? - A: Yes, via ASUS ASMB11-iKVM for secure remote console access and management.
• Q: Is OS compatibility specified for this barebone system? - A: OS compatibility details are not specified in the provided product information; the platform is designed to be versatile across common enterprise operating systems and virtualization environments.
