AXIS Power Supply - DIN Rail

The AXIS Power Supply for DIN Rail is a compact, reliable power solution engineered to power Axis surveillance devices, network cameras, sensors, and other 24V DC loads housed in industrial control panels. Built for professional deployments, this DIN-rail mountable power supply delivers clean, stable power with robust protection features that guard against common electrical disturbances in monitoring environments. Its efficient design minimizes heat generation in enclosed cabinets, helping you maximize cabinet space and reduce energy costs. Whether you’re expanding a security system, upgrading an industrial control rack, or equipping a smart building with dependable, ready-to-use power, this AXIS unit provides the dependable backbone your devices rely on. Designed to meet stringent safety standards and engineered for 24/7 operation, it blends performance with ease of installation, making it a trusted component in professional AV, CCTV, and automation ecosystems.

• Power stability and efficiency: The AXIS Power Supply delivers a regulated 24 V DC output with a wide input range of 100–240 VAC, 50/60 Hz, enabling seamless worldwide use. With a steady supply capable of delivering up to 2 A of current, it maintains low output ripple and tight voltage regulation even as loads fluctuate, protecting cameras and other 24V devices from instability that can cause image degradation, reset cycles, or erratic sensor behavior. Built for reliability, it keeps critical components online during peak demand and transient events, reducing maintenance calls and service interruptions. Its efficiency profile helps minimize heat within the cabinet, extending the life of neighboring equipment and lowering cooling requirements in compact enclosures.
• DIN rail mounting and compact footprint: Engineered for quick, tool-free installation in standard electrical enclosures, the AXIS DIN rail power supply snaps securely onto 35 mm DIN rails (TS35) and occupies minimal cabinet real estate. This design streamlines cabinet layouts, simplifies cable management, and accelerates deployment in multi-device installations. The compact housing is purpose-built to fit alongside other power, networking, and I/O modules without compromising accessibility for wiring, troubleshooting, or future expansions. Its modular footprint also helps technicians organize power distribution in a neat, scalable way, supporting clean layouts essential for professional surveillance and automation installations.
• Advanced safety and protective features: This power supply is equipped with comprehensive protection to safeguard both the unit and connected devices. Short-circuit protection rapidly limits current in fault conditions, while overcurrent and overvoltage protections prevent damage to cameras, controllers, and sensors caused by unexpected surges. Overtemperature protection monitors internal thermal conditions and will adjust performance or shut down safely to avert thermal runaway. With these layered safeguards, the AXIS power supply contributes to higher uptime, reduces the risk of cascading failures, and provides peace of mind in demanding environments where ambient temperatures and loads can vary significantly.
• Industrial-grade reliability and resilience: Built for demanding environments, the AXIS DIN rail power supply supports extended operation across a broad temperature range and in vibration-prone settings typical of industrial facilities. The rugged enclosure, coupled with solid electrical insulation and durable internal components, contributes to a long service life suitable for 24/7 operation. The unit’s design minimizes downtime due to component fatigue, while its stable 24V output ensures consistent device performance, from IP cameras to access control readers, even in cabinets subjected to dust, humidity, or occasional shock. This resilience lowers total cost of ownership by reducing maintenance cycles and replacement frequency.
• Versatility and ecosystem compatibility: While tuned for Axis devices, the AXIS Power Supply is a versatile 24V DC source that powers a wide range of CCTV, sensor, and automation loads. Its standard 24V output and reliable regulation make it ideal for multi-device racks, where a single supply can support several cameras, encoders, or peripheral controllers. The power supply’s compliance with common safety certifications ensures compatibility within professional installations and ease of integration with other AXIS and third-party equipment, enabling scalable surveillance and automation solutions in office buildings, campuses, retail spaces, and industrial facilities.

Technical Details of AXIS Power Supply

• Model: AXIS Power Supply - DIN Rail
• Input: 100–240 VAC, 50/60 Hz
• Output: 24 V DC, up to 2 A
• Power Rating: 48 W (maximum)
• Efficiency: Typical 85–89% (model dependent)
• Protections: Short-circuit, overcurrent, overvoltage, overtemperature
• Mounting: 35 mm DIN rail (TS35) compatible
• Operating Temperature: approximately -20°C to 60°C (typical)
• Certifications: CE, UL, RoHS
• Dimensions (approx.): Compact enclosure designed for DIN rail cabinets

How to install AXIS Power Supply

• 1. Power down the entire cabinet and lockout/tagout as required per local electrical codes. Confirm there is no residual voltage before handling internal components.
• 2. Mount the AXIS power supply onto a standard 35 mm DIN rail (TS35) inside the equipment rack or electrical enclosure. Ensure the unit clicks securely into place and has unobstructed airflow for cooling.
• 3. Connect the AC mains input to the L and N terminals, and connect the protective earth (PE) conductor to the ground terminal. Use properly rated cables and strain reliefs to prevent movement or heat buildup. Follow local wiring practices and ensure the power is switched off during connection.
• 4. Attach the DC output leads to the 24 V DC loads (devices powered by the supply) with correct polarity. Verify that the total current draw does not exceed the 2 A maximum rating. Use appropriate wire gauge and secure terminals to prevent loosening over time due to vibration.
• 5. Double-check all connections, re-check insulation and clearance from other hot or sharp edges, restore mains power, and test the system. Measure the output with a multimeter to confirm a stable 24 V DC within tolerance and confirm that connected Axis devices initialize and operate correctly.

Frequently asked questions

• Q: What output voltage does the AXIS Power Supply provide? A: It provides a regulated 24 V DC output suitable for Axis devices and other 24V loads in surveillance and automation systems.
• Q: What is the maximum current rating? A: The unit is rated for up to 2 A of continuous current, delivering up to 48 W of power. Actual available current may vary by model variant and temperature conditions.
• Q: Is this power supply suitable for outdoor use? A: This model is designed for indoor cabinet installations in controlled environments. For outdoor or harsh environments, use an appropriate enclosure with weather protection and ensure the unit operates within its specified temperature and humidity range.
• Q: What protections are included? A: The AXIS power supply includes short-circuit, overload/current limit, overvoltage, and overtemperature protections to safeguard both the power supply and connected devices.
• Q: Can I daisy-chain multiple power supplies or create redundancy? A: This unit is designed for single-device power delivery. For larger installations or redundancy, consider dedicated power distribution solutions or consult Axis technical resources for recommended configurations.
