AXIS Q17 Front Window Kit A

AXISSKU: 12290545

Price:
Sale price$110.70

Description

AXIS Q17 Front Window Kit A

The AXIS Q17 Front Window Kit A is a premium glass front window spare part engineered to maximize the performance of AXIS Q1785-LE and AXIS Q1786-LE network cameras. This IK08-rated front window provides robust protection against impact and vandalism while preserving the optical clarity needed for precise zooming and sharp imaging across varying lighting conditions. Designed to fit seamlessly with the Q17-series camera enclosure, this spare part helps maintain image quality, reduces distortion, and ensures uninterrupted surveillance with reliable long-term performance.

  • Exact fit for AXIS Q1785-LE and AXIS Q1786-LE cameras, ensuring a secure seal and straightforward replacement without misalignment.
  • Glass construction with IK08 rating offers superior protection against impacts and tampering while maintaining high image fidelity and color accuracy.
  • Optimized to preserve maximum zoom clarity by minimizing refraction, reflections, and surface aberrations at the lens interface.
  • Engineered for easy installation within the existing front window assembly, enabling quick maintenance and reducing camera downtime.
  • Durable, reliable component designed to withstand challenging environments and extend the service life of AXIS Q17-series cameras without compromising performance.

Technical Details of AXIS Q17 Front Window Kit A

  • Product type: Front window spare part (glass)
  • IK08 rating: High-impact protection for vandal resistance and durability
  • Compatibility: AXIS Q1785-LE, AXIS Q1786-LE network cameras
  • Material: Glass window designed to preserve optical clarity and minimize distortion
  • Purpose: Replaces or upgrades the camera’s front window to maintain zoom capability and image quality
  • Manufacturer: AXIS Communications (AXIS)

How to install AXIS Q17 Front Window Kit A

Before starting, ensure you have a safe work environment, proper tools, and that the camera is powered down and disconnected from any network or power sources.

Step 1: Prepare the camera and workspace. Remove any external accessories or cosmetic covers that might obstruct access to the front window area. Verify you have the correct replacement part and that the mounting screws and gasket are available.

Step 2: Remove the existing front window. Using the manufacturer’s recommended tools, carefully detach the front bezel or cover, take note of screw locations, and set aside the screws in a secure tray. Gently lift away the old front window, taking care not to damage the camera housing or gasket seating surface.

Step 3: Clean the gasket seat and mating surfaces. Use a lint-free cloth to remove dust, oils, or residues from the gasket channel and the contact surfaces. A clean surface ensures proper sealing and optical alignment for the new window.

Step 4: Align the AXIS Q17 Front Window Kit A. Position the new glass window so that it sits evenly within the frame and aligns with any alignment marks or features on the housing. Ensure the gasket sits flush and seats evenly to create a weather- and dust-tight seal.

Step 5: Secure the front window. Reinstall screws in a crisscross pattern if applicable, applying even and moderate torque. Avoid over-tightening, which could crack the glass or deform the frame. Double-check that the window is flush with the surrounding surface and that there are no gaps that could compromise seal integrity.

Step 6: Reassemble the camera housing and reconnect power and data. Reattach any covers or bezels you removed. Power up the camera and run a quick functional check, verifying that the image feed is clean, sharp, and that the auto-exposure and white balance respond normally through the new window. If needed, perform a brief calibration to optimize clarity under current lighting conditions.

Step 7: Document the maintenance. Record the replacement in your maintenance log, including date, camera model, part serial, and operator notes. This supports future service planning and ensures traceability in the event of warranty claims or audits.

Notes: Always refer to the camera’s official service manual for torque specifications, gasket replacements, and any model-specific installation guidance. Handling glass components with care minimizes the risk of cracked panes or damaged seals.

Frequently asked questions

  • What is the AXIS Q17 Front Window Kit A? It is a glass front window spare part designed for AXIS Q1785-LE and AXIS Q1786-LE network cameras, built to protect the lens assembly while preserving high optical clarity and robust zoom performance.
  • Which cameras are compatible with this front window kit? The kit is specifically intended for AXIS Q1785-LE and AXIS Q1786-LE network cameras, ensuring a precise fit and proper sealing with the original camera housing.
  • Does the front window affect image quality or zoom? Yes, it is engineered to maintain maximum zoom clarity and minimize distortions, ensuring the camera can fully utilize its optical capabilities without compromise.
  • What does IK08 rating mean for this part? IK08 is a high-level impact resistance rating that helps protect the front window from vandalism and physical damage while preserving image quality and color fidelity.
  • How long does installation take? The installation is designed for efficient replacement with minimal downtime. Depending on experience and access to the camera, it can typically be completed within 15–45 minutes, plus post-installation testing.
  • Are there maintenance considerations after installation? After installation, verify seating and sealing, perform a quick test of image clarity and exposure, and update maintenance records. Replace seals or gaskets if you notice any signs of wear or leakage during inspection intervals.
