Description
Black Box Matrix Switch I/O Module
The Black Box Matrix Switch I/O Module is a strategic expansion for your DKM FX HD Video and Peripheral Matrix switch chassis. Engineered to deliver scalable fiber connectivity in demanding environments, this eight-port I/O module lets you add eight fiber inputs/outputs to a single slot in the DKM FX chassis, dramatically increasing your matrix routing capacity without expanding your footprint. Designed for professional video distribution, multimedia peripherals, and high-performance KVM workflows, this module provides reliable, flexible fiber-based connections that help you route, switch, and manage critical signals with precision. When integrated into a DKM FX system, it delivers seamless performance, real-time status visibility, and robust matrix intelligence—empowering IT professionals, broadcasters, and data center teams to design, deploy, and manage large-scale fiber networks with confidence.
- Eight fiber inputs/outputs to a single slot in the DKM FX chassis, enabling expanded routing capacity for HD video and peripheral signals within a compact, space-efficient platform.
- Eight SFP transceiver ports with duplex LC connectors, offering versatile fiber-based connectivity for long-haul or short-reach matrix deployments and compatibility with a broad range of SFP modules.
- LED indicators provide immediate visibility into the module’s operating status and per-port link status, supporting quick diagnostics, proactive maintenance, and reduced downtime in mission-critical environments.
- Designed for seamless integration with the DKM FX High Performance KVM Matrix Switch Chassis, maintaining system coherence and streamlined cabling while expanding input/output capability.
- Ideal for professionals who require scalable, reliable fiber I/O for HD video routing, peripheral distribution, and multi-workstation environments across broadcast, enterprise, and data-center settings.
Technical Details of Black Box Matrix Switch I/O Module
- Ports: Eight SFP transceiver ports with duplex LC connectors for fiber connectivity.
- I/O Expansion: Eight fiber inputs/outputs to a DKM FX slot, boosting matrix routing capacity.
- Status Indicators: LEDs display the module’s operating status and per-port link status for quick, at-a-glance health checks.
- Compatibility: Fits into the DKM FX High Performance KVM Matrix Switch Chassis, enabling cohesive system architecture.
- Form Factor: Slot-based I/O expansion module designed to integrate with the DKM FX chassis lineup for a streamlined deployment.
How to install Black Box Matrix Switch I/O Module
- Power down the DKM FX chassis before installation to ensure safe handling and proper seating of the new I/O module.
- Identify an available slot in the DKM FX chassis and align the module with the slot connectors.
- Insert the I/O module firmly into the slot until it seats fully and any retention mechanism engages (if applicable).
- Connect fiber cables to the eight SFP ports using appropriate fiber transceivers and duplex LC cables, routing signals as required by your matrix layout.
- Power on the chassis and verify that the module LEDs illuminate to indicate proper operation and port links, then test a sample signal path to confirm full functionality.
Frequently asked questions
- What is the Black Box Matrix Switch I/O Module? It is an eight-port fiber I/O expansion module that adds fiber inputs/outputs to a single slot in the DKM FX HD Video and Peripheral Matrix Switch Chassis, expanding your matrix routing capacity within the DKM FX system.
- Do I need separate SFP modules? Yes. The eight SFP transceiver ports use fiber modules compatible with duplex LC connectors; you will need appropriate SFP transceivers for your fiber network specifications and distance requirements.
- Which chassis is it compatible with? It is designed for use with the DKM FX High Performance KVM Matrix Switch Chassis, providing a cohesive, scalable solution for fiber-based matrix routing.
- How many fibers can I route with this module? The module provides eight fiber inputs/outputs, enabling eight distinct fiber signal paths to be added to your DKM FX matrix.
- What environments benefit most from this module? Broadcast facilities, data centers, enterprise IT environments, and other professional setups that require high-capacity, reliable fiber I/O for HD video and peripheral distribution within a KVM matrix framework.
