Black Box Shielded CAT5e EZ-RJ45 Modular Plugs – 100-Pack

Meet the Black Box Shielded CAT5e EZ-RJ45 Modular Plugs, a high-performance termination solution engineered for reliability in shielded cabling environments. Whether you’re a professional technician laying down a data-center backbone or a DIY enthusiast upgrading a home or small-office network, these plugs deliver fast, consistent terminations without compromising shield integrity. The EZ-RJ45 design is built to streamline installations, reduce rework, and keep performance consistent from the first connector to the last. Shielded construction helps mitigate electromagnetic interference (EMI) and optical cross-talk, preserving signal integrity in busy environments where networks contend with noise from power supplies, motors, or fluorescent lighting. The 100-pack provides ample quantity for bulk deployments, spares, and large projects, helping you stay on schedule and on budget. Crafted with a durable metal shell and gold-plated contacts, these plugs offer corrosion resistance and dependable reuse over time, ensuring a long service life even in challenging installation scenarios. Use them with shielded Cat5e cables, shielded jacks, and compatible enclosures to maximize shielding continuity and overall network performance. These plugs align with industry standards for Cat5e terminations, supporting gigabit Ethernet, PoE, and other high-speed applications that modern networks demand. In short, you get a trusted, efficient, and scalable termination solution that keeps your cabling clean, organized, and performing at peak levels.

• The EZ-RJ45 termination design speeds up installations. These plugs are engineered to simplify the crimping process, reducing the time and effort required to terminate each cable while retaining a secure, repeatable connection. Field technicians will appreciate the reduced rework and consistent seating that comes with a well-engineered EZ-RJ45 plug, especially on long runs or dense patch fields where time saved per termination compounds into meaningful project savings.
• Shielded performance to combat EMI and cross-talk. The metal sheath of the plug provides a continuous shield path that couples with the cable shield, preserving signal quality in environments with high electrical noise. This is particularly valuable in data centers, medical facilities, audio/visual installations, and manufacturing floors where power lines and RF energy can interfere with network transmissions. By maintaining a pristine signal, these plugs help ensure stable gigabit Ethernet and reliable PoE delivery across the network.
• Durable, corrosion-resistant contacts. The gold-plated contact surfaces resist tarnishing and corrosion, maintaining low contact resistance across thousands of mating cycles. The robust housing supports repeated connections and disconnections in field deployments, reducing failure-prone symptoms such as intermittent connectivity, high bit-error rates, or inconsistent PoE delivery. The overall build inspires confidence in both temporary installations and long-term network infrastructure.
• Cat5e-compatible performance for modern networks. These plugs are designed to meet or exceed Cat5e specifications, with careful control of impedance and conductor alignment to minimize reflections and maximize data integrity at gigabit speeds. They’re suitable for a wide range of applications, including basic office networks, small data centers, and home-theater setups that rely on stable, high-throughput connections. When paired with shielded Cat5e cable and properly grounded hardware, you’ll experience improved signal reliability in demanding environments.
• High-volume value with reliable availability. A 100-pack gives you the bulk quantity needed for multi-run projects, spare terminations, and ongoing maintenance cycles. This helps installers manage procurement more efficiently and reduces the need for rushed reorders that can disrupt timelines. The balance of cost-per-termination and dependable performance makes these plugs an economical choice for professional contractors and large-scale installations alike.

Technical Details of Black Box Shielded CAT5e EZ-RJ45 Modular Plugs

• Product type: Shielded CAT5e EZ-RJ45 modular plugs
• Color/finish: Black
• Package quantity: 100 plugs per box
• Cable compatibility: Shielded CAT5e cable; typically supports 24 AWG – 26 AWG conductors
• Contact material: Gold-plated phosphor bronze for reliable, corrosion-resistant terminations
• Contact arrangement: 8-position, 8-conductor (8P8C) RJ45 footprint
• Impedance/bandwidth: Cat5e-compliant with controlled impedance suitable for gigabit Ethernet and PoE
• Shielding: Full metal shell to maintain shield continuity with shielded jacks and enclosures
• Termination method: Crimp-style plug designed for standard RJ45 termination tools
• Operating temperature range: Approximately -20°C to 75°C, depending on installation and environment
• Standards alignment: TIA/EIA-568-B compliant, designed to meet common industry performance requirements

How to Install Black Box Shielded CAT5e EZ-RJ45 Modular Plugs

• Prepare the cable correctly. Begin by stripping back the outer jacket to expose the shielded pair and conductors, taking care not to nick the shielding or insulation. Maintain as much conductor length and twist as possible up to the termination point to preserve impedance and reduce crosstalk. It helps to use a cable stripper designed for shielded cables to avoid damaging the conductors.
• Organize the conductors in the correct order. Align the eight conductors according to the network standard you’re implementing (commonly TIA/EIA-568-B). Use the plug’s marking guides or a trusted reference to ensure each conductor lands in the correct slot. Proper order is essential for reliable operation and to prevent miswiring, which can lead to non-functional links or intermittent performance.
• Trim to the proper length. Ensure each conductor is trimmed evenly to the recommended insertion depth. Uneven or excess conductor length can cause poor seating, reduced contact integrity, and signal degradation. A clean, level cut helps the pins engage fully and consistently during crimping.
• Insert conductors into the plug. With the conductors in order, slide them into the plug’s termination slots carefully. Stop once each conductor is fully seated and visible beyond the plug’s front edge if the design requires it. Do not force the conductors; if a conductor doesn’t seat, remove and reinsert in the proper order and position.
• Crimp to terminate. Use a standard RJ45 crimping tool compatible with EZ-RJ45 plugs. Apply steady, even pressure to ensure a solid mechanical hold and a reliable electrical contact across all eight conductors. Confirm the pins have properly crimped to the conductors and that the plug seats firmly on the cable jacket.
• Inspect shielding continuity and seating. After crimping, check that the shield path remains continuous from cable shield through the plug shell. If you have access to a shield integrity tester or impedance tester, run a quick check to verify there are no gaps or weak points in the shield that could compromise EMI protection.
• Test the finished assembly. Use a network cable tester to verify continuity, pair integrity, and proper insulation. Confirm that the plug has formed a complete circuit with all eight conductors and that data transmission appears stable under normal load. If issues arise, re-terminate on a fresh section of cable to avoid latent defects.

Frequently Asked Questions

• Q: Are these plugs compatible with unshielded CAT5e networks?
  A: They are specifically designed for shielded CAT5e cables and shielded installations. For unshielded networks, standard RJ45 plugs are typically used, and shielding advantages may be diminished or unnecessary depending on the environment.
• Q: Do I need a special crimp tool?
  A: These plugs are designed for standard RJ45 crimp tools. Ensure your tool supports EZ-RJ45 terminations and the plug sizing used by Black Box.
• Q: Will these plugs work with all shielded CAT5e brands?
  A: They are compatible with typical shielded CAT5e cables that use standard conductor sizes (around 24 AWG). Always verify with the cable manufacturer’s guidelines to ensure proper seating and shielding continuity.
• Q: Are these plugs suitable for PoE deployments?
  A: Yes, the combination of Cat5e compliance and shielded design supports PoE applications when used with compatible cables, connectors, and power budgets. Follow PoE best practices for your installation to maintain performance and safety.
• Q: What warranty coverage is included?
  A: Warranty terms vary by distributor. Check the packaging or vendor policy for specifics on coverage duration and what is included in the warranty for these plugs.
