Broadcom MegaRAID 9670W-16i SAS Controller

The Broadcom MegaRAID 9670W-16i SAS Controller is a state-of-the-art storage solution tailored for the dynamic requirements of contemporary data centers. Leveraging advanced 9600 series technology, this controller ensures high-performance connectivity for NVMe, SAS, and SATA devices, facilitating effortless integration and superior data protection. Designed for IT professionals and businesses aiming to enhance their storage infrastructure and application performance, the MegaRAID 9670W-16i stands out as a premier choice.

• Unmatched Performance: Experience exceptional bandwidth of 24G, delivering up to 2x the IOPS and more than 3x the RAID 5 IOPS compared to earlier models. Enjoy quicker data access and enhanced application storage performance, ideal for high-demand environments.
• Tri-Mode Capability: This controller employs Broadcom's innovative Tri-Mode SerDes technology, allowing NVMe, SAS, and SATA storage devices to coexist in a single drive bay. This feature ensures seamless performance across diverse protocols without the need for significant system alterations.
• Advanced Data Protection: The MegaRAID 9670W-16i is equipped with T-10 End-to-End Data Protection (EEDP), guaranteeing early detection and recovery from potential data corruption. This means peace of mind while safeguarding crucial business information.
• Flexible Design: Compatibility with SlimSAS 24G SFF-8654 internal and SFF-8674 external connectors, as well as existing PCI Express SFF-8639 Module (U.2) backplanes, ensures easy integration into your current infrastructure while significantly boosting performance.
• Comprehensive Management Features: Benefit from Universal Backplane Management (UBM) readiness, along with unified drivers and utilities, which make controlling and monitoring your storage devices straightforward. Additionally, leverage DataBolt2 technology to maximize performance with existing drives while upgrading to 24Gb/s speeds.

Technical Details of the Product

• Host Interface: x16 and x8 PCIe Gen 4.0
• Data Transfer Rates: SAS at 22.5, 12, and 6Gb/s; SATA at 6Gb/s
• Tri-Mode Storage Interface: Supports NVMe, SAS, and SATA
• End-to-End Data Protection: T-10 EEDP model
• Backward Compatibility: Supports older PCIe standards (5.0/2.5 GT/s)

How to Install

Installing the Broadcom MegaRAID 9670W-16i SAS Controller is a straightforward process. Follow these steps:

1. Power down your server and disconnect it from the power source.
2. Open the server chassis according to the manufacturer’s guidelines.
3. Locate an available PCIe slot on the motherboard.
4. Carefully insert the MegaRAID 9670W-16i into the PCIe slot, ensuring it is properly seated.
5. Secure the controller with screws if required, and close the chassis.
6. Reconnect the power and power on the server.
7. Install the necessary drivers and software provided by Broadcom to configure the controller.

Frequently Asked Questions

• What storage devices are compatible with the MegaRAID 9670W-16i? The MegaRAID 9670W-16i supports NVMe, SAS, and SATA devices, providing flexibility for your storage configuration.
• How can I benefit from the Tri-Mode technology? The Tri-Mode technology allows you to use NVMe, SAS, and SATA devices in a single RAID or eHBA adapter, enabling seamless integration and smooth operation without significant changes to your existing infrastructure.
• What kind of data protection does the MegaRAID 9670W-16i provide? This controller features T-10 End-to-End Data Protection (EEDP) to detect and recover from data corruption, ensuring your data remains secure.
• Can I use older drives with the MegaRAID 9670W-16i? Yes, the MegaRAID 9670W-16i is backward compatible and allows you to use existing 12Gb/s and 6Gb/s drives while taking advantage of the higher 24Gb/s speeds.
• Is the installation process difficult? The installation process is user-friendly and can be completed by following our outlined steps, making it accessible even for users with limited technical knowledge.
