Broadcom BCM957504-N425G Quad-Port 25 Gb/s SFP28 Ethernet PCI Express 4.0 x16 OCP 3.0 SFF Network Adapter

The Broadcom BCM957504-N425G is a high-performance, quad-port network adapter engineered for modern data centers, hyperscale deployments, and open compute environments. Built to the Open Compute Project (OCP) 3.0 design specification, this compact SFF (small form factor) card delivers 4 independent 25 Gb/s SFP28 network channels in a single PCIe 4.0 x16 slot, providing scalable bandwidth for demanding workloads. Whether you’re consolidating storage networks, fueling virtualized environments, or accelerating server-to-server traffic, the BCM957504-N425G is designed to maximize throughput, minimize latency, and simplify dense server configurations.

• Quad-port 25 Gb/s performance with four SFP28 network connectors, enabling high aggregate bandwidth and flexible topology for data centers and cloud deployments.
• Supports both SFP28/SFP+ optical modules and copper direct-attach cables (DACs), giving you the option to deploy fiber for long-range links or inexpensive copper for short, cost-effective connections.
• PCI Express 4.0 x16 host interface provides substantial headroom for data-intensive workloads while maintaining efficient CPU utilization and low I/O latency.
• Open Compute Project (OCP) 3.0 design specification in a compact, small form factor (SFF) card, ideal for dense rack configurations and streamlined server integration.
• Designed to deliver reliable, flexible Ethernet connectivity across diverse data-center scenarios—from virtualization and clustering to high-performance storage networks—without locking you into a single module ecosystem.

Technical Details of Broadcom BCM957504-N425G

• Model: Broadcom BCM957504-N425G
• Ports: 4 x SFP28 network connectors (25 Gb/s per port)
• Interface: PCI Express 4.0 x16 host interface
• Form Factor: Open Compute Project (OCP) 3.0 small form factor (SFF) design
• Connectivity Options: Supports SFP28/SFP+ optical modules and copper direct-attach cables (DACs)
• Data Rate: 25 Gb/s per port with full-duplex operation
• Compliance: Built to the OCP 3.0 specification for open, modular, and scalable data-center networking
• Purpose: Designed to enable dense, scalable 25 GbE networking in modern servers and data centers

How to Install Broadcom BCM957504-N425G

• Power down your server and disconnect all power sources before beginning installation.
• Open the chassis and locate an available PCIe x16 slot that supports PCIe 4.0/3.0, then remove the slot cover if needed.
• Insert the BCM957504-N425G into the PCIe x16 slot firmly until the retention latch engages securely.
• Secure the card to the chassis with a screw to ensure stable operation and prevent movement during operation.
• Connect your network interfaces using either SFP28/SFP+ optical modules for fiber links or copper direct-attach cables (DACs) for short-range, cost-effective connections. Ensure the transceivers or DACs are compatible with SFP28 ports.

Frequently asked questions

• What is the port configuration of the Broadcom BCM957504-N425G? It features four independent SFP28 ports capable of 25 Gb/s per port for a total potential aggregated bandwidth of up to 100 Gb/s.
• What types of modules or cables are supported? The card supports SFP28/SFP+ optical modules and copper direct-attach cables, offering flexible options for fiber and copper infrastructures.
• What interface and form factor does it use? It uses a PCI Express 4.0 x16 host interface in an Open Compute Project (OCP) 3.0 small form factor card, designed for dense server configurations.
• Is this card suitable for data-center deployments? Yes. The quad-port 25 Gb/s design, combined with OCP 3.0 compliance and flexible optics/copper support, makes it well-suited for data centers requiring scalable, high-performance networking.
• Does it support multiple workloads and virtualization scenarios? The four independent 25 Gb/s ports provide ample bandwidth for virtualization, clustering, and storage networking—allowing traffic segmentation, NIC teaming, and scalable network topologies.
