Chief Fusion and Thinstall 4.3" Hardware Kit - High/Low VESA Offset Bracket

Elevate your display setup with the Chief Fusion and Thinstall 4.3" Hardware Kit, a purpose-built High/Low VESA offset bracket designed to deliver precise alignment, secure mounting, and a clean, professional look for commercial conference rooms, classrooms, and home theaters. This 4.3-inch offset bracket is engineered to complement Chief’s Fusion and Thinstall mounting systems, enabling quick, accurate positioning of compatible displays. Constructed from durable components and tuned for reliability, the kit ensures a rigid hold even in high-traffic environments, while preserving the aesthetic integrity of your installation. With screws and spacers specifically matched to FHB3XXX, FHB5XXX, and FHB7XXX TV mounts, you gain a turnkey solution that reduces on-site guesswork and helps you achieve optimal viewing height with minimal effort.

• High/Low VESA offset allows precise vertical alignment to achieve optimal viewing height across seating areas and room layouts.
• Includes screws and spacers specifically matched to FHB3XXX, FHB5XXX, and FHB7XXX TV mounts for streamlined, on-site prep.
• 4.3-inch offset bracket delivers secure mounting with a slim profile that minimizes bulk behind the display while maximizing stability.
• Durable construction uses high-strength steel with a powder-coated finish for corrosion resistance and long-term reliability in busy spaces.
• Designed for quick, tool-friendly installation with clearly labeled hardware and seamless compatibility with Chief Fusion and Thinstall arms.

Technical Details of Chief Fusion and Thinstall 4.3" Hardware Kit

• Product family: Chief Fusion and Thinstall 4.3" Hardware Kit (High/Low VESA Offset Bracket)
• Offset specification: 4.3 inches (maximum vertical adjustment to fine-tune screen height)
• Included hardware: Screws and spacers selected for FHB3XXX, FHB5XXX, and FHB7XXX mounting configurations
• Material: High-strength steel designed to resist bending and ensure durable performance
• Finish: Powder-coated coating for scratch resistance and corrosion protection in varied environments
• Compatibility: Works with Chief Fusion and Thinstall mounting systems to support a wide range of displays and sizes
• Installation footprint: Compact 4.3-inch offset footprint maintains a low profile while providing robust support
• Weight considerations: Weight ratings depend on the corresponding Chief mount and display; consult your installation guide for precise limits
• Included content note: Hardware kit includes the necessary fasteners and spacers tailored to the supported TV mount families

how to install Chief Fusion and Thinstall 4.3" Hardware Kit

• Prepare the installation area by verifying the mounting surface is sturdy, free of obstructions, and compliant with the weight of the display and mount.
• Identify the correct FHB3XXX, FHB5XXX, or FHB7XXX fasteners from the kit and select spacers that match your display’s VESA pattern and desired offset.
• Attach the offset bracket to the display using the appropriate VESA holes and included screws, ensuring each fastener is tightened evenly to spec.
• Mount the display assembly to the Chief Fusion or Thinstall arm or wall mount using the supplied spacers, then align the height to achieve the target viewing position.
• Check alignment and security by gently testing the display’s tilt and level, then perform a final torque check on all fasteners and re-secure any cable management features.

Frequently asked questions

• Q: What is the purpose of the 4.3" offset hardware kit?
• A: It provides a precise high/low vertical offset to achieve optimal screen height when using Chief Fusion and Thinstall mounts, ensuring consistent, comfortable viewing across seating arrangements.
• Q: Which mount families are compatible with this kit?
• A: The kit is designed for Chief Fusion and Thinstall systems and includes hardware tailored for FHB3XXX, FHB5XXX, and FHB7XXX mounting configurations.
• Q: What is included in the package?
• A: The package includes the 4.3" offset bracket hardware set with screws and spacers specifically matched to the supported TV mount families, ready for installation with Chief solutions.
• Q: Is there a specific weight rating or load limit for this kit?
• A: Weight ratings depend on the combined performance of the display, mount, and wall structure; consult the official Chief installation guides and the product manual for precise specifications related to your configuration.
