Chief Fusion PAC800K Camera Mount for Video Conferencing

The Chief Fusion PAC800K is a premium camera mounting solution engineered for demanding video conferencing environments. It is designed to work harmoniously with the Vaddio ConferenceSHOT ePTZ camera for large displays, delivering precise camera positioning, clean aesthetics, and reliable performance in boardrooms, training rooms, classrooms, and corporate collaboration spaces. With the PAC800K, you can position the camera above or below the display to optimize sightlines, framing, and lighting, ensuring every meeting participant is captured with exceptional clarity. The integrated 14 x 14" (P-series) Q-Latch shelf provides secure, tool-free mounting for the camera shelf, enabling fast setup and reconfiguration. Built to endure daily use in busy environments, this mount combines rugged construction with refined design, offering a scalable solution that adapts from compact huddle rooms to expansive conference halls while maintaining a professional, cable-managed appearance.

• Flexible above-or-below display mounting: The PAC800K is purpose-built to sit either above or below your display, allowing you to tailor your room layout for optimal camera framing, reduced glare, and improved peripheral vision for participants in the room and on video.
• Q-Latch 14 x 14" shelf system for secure mounting: The camera shelf uses the 14 x 14" P-series Q-Latch setup, delivering fast, tool-free installation and dependable support for the PAC and connected equipment. This design keeps your camera steady even during frequent room reconfigurations or maintenance.
• Optimized for Vaddio ConferenceSHOT ePTZ: Engineered to complement the ConferenceSHOT ePTZ camera, the PAC800K ensures precise alignment, smooth pan/tilt/zoom performance, and consistent framing across varying room sizes and seating arrangements.
• Rugged, clean-looking construction and cable management: Built from durable materials with a black finish, the PAC800K provides a professional look that blends with modern conference rooms. Integrated cable channels help route power and data cables neatly, reducing clutter and potential trip hazards.
• Modular, scalable design with application-dependent dimensions: Dimensions and specifications adapt to your installation type. Whether you’re outfitting a small meeting room or a large auditorium, the PAC800K supports flexible configurations, easy upgrades, and straightforward serviceability for long-term ROI.

Technical Details of Chief Fusion PAC800K

• Model: PAC800K
• Finish: Black powder-coated steel for durability and a professional finish
• Construction: Heavy-duty steel chassis with integrated mounting features
• Compatibility: Optimized for the Vaddio ConferenceSHOT ePTZ camera; supports cameras and accessories that fit the 14 x 14" P-series Q-Latch shelf footprint
• Mounting orientation: Designed to sit above or below the display; suitable for wall- and some ceiling-mount configurations depending on installation
• Shelf system: 14 x 14" P-series Q-Latch compatible shelf for fast, secure camera placement
• Dimensions: Varies by application type and room configuration; designed to adapt to different display sizes and mounting surfaces
• Weight considerations: Dependent on chosen configuration and installed components; consult installation guide for exact values
• Cable management: Integrated pathways to neatly route power and data cables for a clean, professional install

How to Install Chief Fusion PAC800K

Install the PAC800K with an emphasis on stability, alignment, and cable management to ensure a lasting, professional result. Here is a practical, step-by-step approach to a typical installation:

• Plan the layout: Determine whether the camera will sit above or below the display and assess the mounting surface (wall or compatible ceiling mount). Confirm that you have access to power and video cabling and that there is adequate clearance for camera movement.
• Prepare the shelf and mounting hardware: Assemble the 14 x 14" P-series Q-Latch shelf as specified in the product guide. Gather all required screws, brackets, and any stand-offs appropriate for your wall or display mount.
• Attach the PAC800K base: Secure the base of the PAC800K to the chosen mounting surface or to the compatible display mount platform using the recommended hardware. Ensure the base is plumb and level to prevent misalignment of the camera position.
• Install the camera shelf: Mount the 14 x 14" Q-Latch shelf onto the PAC800K assembly and verify that it is firmly attached. This shelf serves as the anchor for the Vaddio ConferenceSHOT ePTZ camera and any accompanying accessories.
• Mount the camera and align: Place the Vaddio ConferenceSHOT ePTZ camera on the shelf and align it with the desired framing. Perform a tilt, pan, and zoom test to confirm that the camera captures the intended room and audience seating positions.
• Route cables and power: Run power, data, and control cables through the built-in cable management channels. Keep cables tidy and avoid tension or sharp bends that could degrade performance or create wear over time.
• Finalize calibration: Power up the system, run a framing check, and fine-tune camera positioning to achieve consistent subject framing across the room. If needed, adjust tilt and orientation to optimize sightlines for all participants.
• Document configuration: Record the installation details, including mounting type, shelf position, and camera alignment settings, to simplify future maintenance or reconfiguration.

Frequently asked questions

• What cameras are compatible with the PAC800K? The PAC800K is designed to work with the Vaddio ConferenceSHOT ePTZ camera and supports the 14 x 14" P-series Q-Latch shelf system for secure mounting. Other cameras that fit the shelf footprint and mounting pattern may be compatible; verify dimensions and mounting requirements for your specific camera.
• Can the PAC800K be mounted above and below the display? Yes. The design supports placement above or below the display to accommodate different room layouts, sightlines, and lighting conditions, ensuring optimal framing for all participants.
• Does it include cable management? Yes. The mount features integrated cable channels to route power, video, and control cables cleanly, reducing clutter and protecting cables from wear.
• Is installation tool-free? The Q-Latch shelf enables tool-free camera placement, but some steps (such as securing the base, aligning the camera, and routing cables) may require standard hand tools in accordance with the installation guide.
• Where can I find technical specifications for my configuration? Specifications vary by application. Refer to the product guide and the installation documentation for your chosen configuration to obtain exact dimensions, weight limits, and mounting guidance.
