Chief PNR Reaction Universal Dual Swing Arm Wall Mount
The Chief PNR Reaction Universal Dual Swing Arm Wall Mount is the premier mounting solution for large flat-panel displays that demand both reach and precision. Engineered as a robust dual swing arm system, this mount offers an impressive extension of up to 24 7/8 inches, giving you flexible viewing from multiple seating or standing positions while maintaining a slim, professional wall profile when retracted. The PNR variant is specifically designed for installations that require a solid, dependable dual swing arm with a shorter extension, making it an ideal choice for conference rooms, classrooms, home theaters, or any space where space efficiency and clean cable management matter. With a secure mounting system that simplifies installation and frequent repositioning, you can adjust connectors quickly and confidently without compromising stability. Built to endure the rigors of daily use, it combines industrial-grade construction with a sleek finish to complement modern interiors while keeping cables neatly tucked away.
- Universal compatibility: Crafted to accommodate large-format displays with standard VESA hole patterns, ensuring broad compatibility across a wide range of TVs and monitors while delivering dependable, long-term performance.
- Generous extension: Extends up to 24 7/8 inches from the wall, providing flexible viewing angles and easy access for cable management, maintenance, and repositioning in busy environments.
- Solid dual swing arms: Dual-arm design delivers sturdy support with smooth, controlled movement, allowing independent adjustment of each arm for precise positioning and alignment of even oversized panels.
- Easy installation and management: Designed for quick setup with a secure mounting system and integrated cable management to keep cords organized and out of sight for a clean, professional look.
- Secure, durable construction: Built to withstand the demands of daily use in commercial spaces, with rugged materials and a durable finish that resist wear while maintaining a low-profile aesthetic.
Technical Details of Chief PNR Reaction Universal Dual Swing Arm Wall Mount
- Extension range: Up to 24 7/8 inches (63 cm) from the wall to maximize viewing flexibility.
- Arm configuration: Dual swing arms designed to provide solid support and independent adjustment for large displays.
- Display compatibility: Intended for large flat-panel displays with standard mounting patterns; compatible with common VESA configurations used by many manufacturers.
- Construction and finish: Heavy-duty steel components with a durable finish built to endure frequent adjustments and daily use.
- Weight capacity: Not specified in the provided data; verify exact load rating on official specifications for your particular display model.
- UPC/SKU: Not provided in the data; retrieving official specifications requires reference to ec.synnex.com using the product's UPC or SKU.
How to install Chief PNR Reaction Universal Dual Swing Arm Wall Mount
Installing the Chief PNR Reaction Dual Swing Arm Wall Mount is a straightforward process designed to deliver a secure, professional setup with minimal downtime. Follow these general steps to achieve optimal performance and safety for your display:
Step 1 – Plan and locate the mounting area: Select a solid wall location that can support the combined weight of the mounted display and the arms. Use a stud finder to locate wall studs or appropriate anchors for your wall type. Consider sightlines, reach, outlet placement, and cable routing before marking the wall for the mounting plate.
Step 2 – Attach the wall plate and anchors: Secure the wall plate to the wall using fasteners that match your wall construction (studs or anchors as required). Ensure the plate is perfectly level, as any deviation could affect display alignment and movement. Tighten fasteners evenly to avoid warping and verify that the plate sits flush against the surface.
Step 3 – Assemble the dual swing arms: Attach the two swing arms to the wall plate according to the manufacturer’s instructions. Check that each arm moves smoothly and has the intended range of motion. If the design incorporates quick-release connectors or adjustment points, verify they function properly and lock securely in place.
Step 4 – Mount the display: Attach the display to the arms using the appropriate VESA mounting pattern and hardware supplied with the mount. Align the mounting holes on the back of the display with the arm attachment points, then tighten all fasteners in a crisscross sequence to ensure even seating. Route power and signal cables through built-in cable channels to maintain a clean appearance, and leave slack for movement without pinching.
Step 5 – Test, adjust, and secure: Power on the system and test the full range of motion, including extension, retraction, tilt, and swivel if supported by the mount. Make any necessary adjustments to balance and tension to prevent drift over time. Confirm that cables have adequate clearance during movement and that there are no obstructions behind the wall or along the path of motion. Finally, perform a safety check to ensure all connections are secure and the display remains stable through typical daily use.
Frequently asked questions
-
Q: What size and weight of displays can the Chief PNR Reaction Dual Swing Arm Wall Mount support?
A: The mount is designed for large flat-panel displays with standard mounting patterns and is built to support heavy-duty installations. Specific weight and size limits depend on the exact model and installation conditions; consult the official specifications for your device’s exact VESA pattern, weight, and load rating.
-
Q: How far does this mount extend from the wall?
A: It offers an extension of up to 24 7/8 inches (63 cm), providing substantial reach for flexible viewing angles while still maintaining a secure, low-profile appearance when retracted.
-
Q: Is the mounting system universal for different displays?
A: The PNR Reaction Dual Swing Arm is designed to be compatible with a wide range of large-format displays that use common VESA patterns. Always verify your specific VESA hole pattern and weight requirements against the mount’s specifications before installation.
-
Q: Does it include cable management features?
A: Yes, the design typically includes integrated cable management to keep power and data cables organized and out of sight, contributing to a cleaner, safer wall display setup.
