Cisco 55A1 Router Chassis

The Cisco 55A1 Router Chassis is a state-of-the-art networking solution that has been meticulously engineered to meet the escalating demands of the zettabyte era. Building on the proven success of the Cisco Network Convergence System 5501, the NCS-55A1-24Q6H-S and NCS-55A1-24Q6H-SS models boast enhanced performance features suitable for a diverse range of applications. From managing 5G mobile backhaul to deploying top-of-rack solutions, this router chassis is designed to provide the flexibility and efficiency required to optimize your network infrastructure.

• High-Speed Connectivity: Experience seamless data transfer with dense 1G/10G/25G/40G/100G functionality, ensuring robust connectivity across various network types.
• Advanced Security Features: Safeguard your network with line-rate MACsec support at 10G/25G/40G/100G speeds, enhancing operational integrity and protecting against unauthorized access.
• Precision Timing: The chassis comes equipped with Precision Time Protocol (PTP), Synchronous Ethernet (SyncE), and 1588 Class B timing to ensure accurate time synchronization for modern applications.
• Energy Efficiency: Designed with ultralow per-bit power consumption, the Cisco 55A1 Router Chassis helps reduce operational costs while maintaining high performance, making it an eco-friendly choice for your network infrastructure.
• Expandable Architecture: The Cisco 55A1 Router Chassis allows for the installation of multiple modules, providing flexibility to enhance your router’s capabilities as your network evolves and expands.

Technical Details of the Cisco 55A1 Router Chassis

• Model: NCS-55A1-24Q6H-S / NCS-55A1-24Q6H-SS
• Dimensions: 1 Rack Unit (1RU)
• Data Rate: Supports up to 100 Gbps via 100GBase-X technology
• Power Supply: Built-in power supply for reliable voltage and performance
• Protocol Support: MACsec, PTP, SyncE, and 1588 Class B

How to Install the Cisco 55A1 Router Chassis

Installing the Cisco 55A1 Router Chassis is a straightforward process. Follow these steps for a successful setup:

1. Ensure you have a compatible rack available for mounting the chassis.
2. Unbox the chassis and verify that all components are included as per the package list.
3. Locate the rack-mounting brackets and attach them to the chassis using the provided screws.
4. Carefully lift the chassis and position it in the desired rack location, ensuring it is level.
5. Secure the chassis to the rack using the screws supplied with the mounting brackets.
6. Connect the built-in power supply to an appropriate power source and ensure all connections are secure.
7. Install any additional modules as required for your network setup.
8. Power on the chassis and configure using Cisco IOS XR for optimal performance.

Frequently Asked Questions

• What is the maximum data transfer rate of the Cisco 55A1 Router Chassis? The chassis supports data transfer rates of up to 100 Gbps over supported network cabling.
• Can I expand the functionality of the Cisco 55A1 Router Chassis? Yes, the chassis allows for the installation of multiple modules, giving you the flexibility to expand as needed.
• Is the Cisco 55A1 Router Chassis energy-efficient? Absolutely! It features ultralow per-bit power consumption, which helps reduce operational costs.
• What kind of security features does the chassis offer? The chassis includes line-rate MACsec support to ensure that your network is secure from unauthorized access.
• Does the Cisco 55A1 Router Chassis support advanced timing protocols? Yes, it supports Precision Time Protocol (PTP) and Synchronous Ethernet (SyncE) for accurate time synchronization.
