Cisco SM-X EtherSwitch SM, Layer 2/3 Switching, 16 GE Ports, PoE+ Capable

The Cisco SM-X EtherSwitch Service Module is designed to bring high-performance Layer 2 and Layer 3 switching directly into Cisco ISR platforms, delivering a compact, power-efficient, and cost-conscious solution for modern networks. By integrating 16 Gigabit Ethernet ports with PoE+ capability into Cisco 4451-X, 3900, and 2900 Series Integrated Services Routers, this module creates a scalable LAN edge that simplifies deployment, reduces equipment footprint, and lowers total cost of ownership (TCO). It is an ideal choice for organizations seeking to consolidate switching functionality within their existing router infrastructure, while preserving the reliability, security, and management capabilities that come with Cisco IOS software and Cisco hardware ecosystem. This description blends common use cases, benefits, and technical strengths to help buyers understand how the SM-X EtherSwitch can fit into a wide range of network architectures, from branch offices to distributed enterprise campuses.

• 16 Gigabit Ethernet ports with PoE+ support. Seamlessly power and connect a mix of IP phones, wireless access points, cameras, and other PoE-capable devices directly from the ISR edge, reducing the need for separate switches and simplifying wiring closet design.
• Layer 2 and Layer 3 switching capabilities. Provides robust switching within VLANs, supports advanced traffic management, and enables routing features at the edge to optimize performance and segment networks efficiently.
• Integrated into Cisco ISR platforms. The EtherSwitch module sits in compatible Cisco routers, delivering centralized management through familiar Cisco IOS Software tools, policies, and security features for easy administration and consistent operations.
• Space-saving, energy-efficient design. By consolidating switching and routing functions into a single device, organizations gain valuable rack space and simplify power management while maintaining scalable performance as network demands grow.
• Reliable, enterprise-grade security and management. Leverage Cisco’s proven security features, QoS capabilities, and monitoring tools to protect data, prioritize critical applications, and maintain visibility across the network edge.

Technical Details of Cisco SM-X EtherSwitch SM

• Ports: 16 x Gigabit Ethernet ports with PoE+ capability, designed for high-density edge connectivity.
• Layer support: Layer 2 switching with Layer 3 routing features to support efficient inter-VLAN routing and scalable network design at the edge.
• Power over Ethernet: PoE+ capable to deliver power to compatible devices directly over Ethernet cables, enabling simpler deployments of IP phones, cameras, and wireless access points.
• Compatibility: Integrates with Cisco 4451-X, 3900 Series, and 2900 Series Integrated Services Routers for unified network architecture and centralized management.
• Management: Managed through Cisco IOS Software on the ISR platform, providing familiar CLI, GUI, QoS, security policies, and monitoring tools.
• Form factor and installation: Service module designed to slot into supported Cisco routers, enabling a compact, integrated edge solution without separate switch cabinets.

How to Install Cisco SM-X EtherSwitch SM

• Power down the Cisco ISR chassis and locate a supported slot for the SM-X EtherSwitch Service Module, then carefully install the module according to Cisco hardware guidelines.
• Secure the module in place and reconnect power to the router, ensuring that any required cooling is unblocked and airflow is not obstructed.
• Connect PoE+ devices to the 16 GE ports as needed. Use appropriately rated PoE devices to take full advantage of PoE+ capabilities while monitoring power budgets on the ISR.
• Power on the router and access the Cisco IOS Software CLI or GUI to initialize the EtherSwitch module. Verify that the module is recognized in the hardware inventory and that ports come online.
• Configure VLANs, QoS, security policies, and any required routing features. Create a cohesive edge policy set that matches your organization’s network design, with attention to DHCP, ACLs, and routing protocols as appropriate for your topology.
• Test connectivity and performance by simulating typical work scenarios—IP phones booting, APs stabilizing, and traffic flowing across the edge—to ensure that PoE power delivery, port forwarding, and routing behave as intended.

Frequently asked questions

• What is the Cisco SM-X EtherSwitch SM used for? It is a service module that adds 16 Gigabit Ethernet ports with PoE+ to Cisco ISR routers, enabling Layer 2/3 switching at the network edge while leveraging the router’s management and security capabilities.
• Is PoE+ supported on all ports? PoE+ capability is available to power PoE-enabled devices on supported ports, helping to simplify deployments of IP phones, cameras, and wireless access points.
• Which routers are compatible with this EtherSwitch module? The SM-X EtherSwitch is designed to integrate with Cisco ISR platforms such as the 4451-X, as well as certain models in the 3900 and 2900 Series, enabling a unified, scalable edge solution.
• Does it provide Layer 3 routing features? Yes, the module supports Layer 2 switching and Layer 3 routing capabilities at the edge, allowing efficient inter-VLAN routing and optimized traffic paths within the router ecosystem.
• How do I manage the EtherSwitch module? Management is performed through Cisco IOS Software on the ISR, using CLI or the Cisco management interfaces, which preserves consistent configurations, security policies, and monitoring across the network.
• What are the benefits of integrating switching into the ISR? Consolidating switching and routing into a single hardware platform reduces equipment footprint, simplifies cable plant, lowers total cost of ownership, and centralizes policy enforcement and monitoring for improved reliability and operational efficiency.
