Description
Da-Lite Model C CSR Projection Screen — 96" x 96" Square, Wall or Ceiling Mounted Manual Screen
The Da-Lite Model C CSR is a premium manual projection screen designed for larger rooms where image clarity, quiet operation, and dependable performance matter. Featuring Controlled Screen Return (CSR), this screen delivers a smooth, controlled retraction back into its case, reducing noise and ensuring a tidy, unobtrusive install. Designed for both wall and ceiling mounting, the Model C CSR maximizes space efficiency without sacrificing screen quality or ease of use. With a generous 96" x 96" square viewing surface, it provides a versatile canvas for presentations, classrooms, training facilities, and home theaters alike. Built for straightforward installation and durable long-term operation, this screen blends robust engineering with practical features that installers and end users will appreciate.
- Controlled Screen Return (CSR): A quiet, controlled retraction mechanism keeps the screen neatly tucked away after use, minimizing noise and distraction in any room.
- Wall or Ceiling Mounting: Flexible installation options allow you to mount the screen in the most convenient location for your space, whether overhead from the ceiling or flush against a wall.
- Large Square Viewing Surface: 96" x 96" dimensions provide ample projection area, enhancing visibility for audiences in mid-to-large rooms while maintaining a compact housing profile.
- Manual Operation: Simple, reliable manual operation ensures you can deploy and retract the screen with minimal effort, even in spaces without power accessibility.
- Space-Efficient Design: The compact housing and square format maximize usable room space, making it ideal for boardrooms, classrooms, and media rooms where wall or ceiling real estate is at a premium.
Technical Details of Da-Lite Model C Projection Screen
- Screen size: 96" x 96" square viewing area
- Mounting options: Wall-mounted or ceiling-mounted manual operation
- Operate via: Manual pull-down mechanism with CSR for controlled retraction
- Screen surface: Matte white projection surface suitable for standard business and education projectors
- Design: Integrated case and housing designed for durable use in active environments
How to install Da-Lite Model C Projection Screen
Installing the Model C CSR screen is straightforward and designed to accommodate both wall and ceiling configurations. Follow these steps to ensure a secure, level installation that delivers optimal projection performance and long-term reliability.
- Choose your installation location: Decide whether the screen will be mounted on a wall or from the ceiling. Ensure there is a clear projection path and enough space for full extension of the 96" x 96" surface.
- Locate structural supports: Use a stud finder to identify wall studs or ceiling joists where the mounting brackets will be anchored. This ensures a sturdy mount capable of supporting the screen’s weight during use.
- Mark and drill mounting holes: Align the mounting brackets with the stud centers and mark the screw holes. Drill pilot holes appropriate for your hardware, then attach the brackets securely to the wall or ceiling.
- Attach the screen housing: With a helper, elevate the screen housing to the mounting position and secure it to the brackets. Verify that the housing is level to guarantee even screen operation and full vertical travel.
- Verify CSR operation and alignment: Slowly extend the screen to full height to confirm smooth deployment and the quiet, controlled return during retraction. Adjust alignment if required to ensure the edge is perfectly square for an even projection.
Note: Fully extendable CSR screens require the screen to be fully extended before retraction features engage. Proper mounting and level alignment are key to achieving the quiet, controlled return that CSR is designed to provide.
Frequently asked questions
- Q: What does CSR stand for and why is it important? A: CSR stands for Controlled Screen Return. It provides a quiet, controlled retraction of the screen into its housing, reducing noise and maintaining a clean, professional appearance in meeting rooms, classrooms, and home theaters.
- Q: Can the Model C CSR be mounted on a wall or ceiling? A: Yes. The Model C CSR is designed for both wall-mounted and ceiling-mounted installations, offering flexible placement to suit your room layout and viewing angle.
- Q: What size is the projection surface? A: The screen surface measures 96 inches by 96 inches, creating a square viewing area suitable for medium to large rooms and a variety of projector throw distances.
- Q: Is this screen suitable for classroom or corporate use? A: Absolutely. The large square surface, dependable manual operation, and CSR mechanism make it well-suited for educational environments, corporate training rooms, conference spaces, and home theater setups requiring a robust, quiet screen.
- Q: Do I need power for the CSR mechanism? A: No. The Model C CSR operates manually. The CSR feature only affects the retraction mechanism and does not require electrical power.
- Q: What maintenance does the screen require? A: Routine inspection to ensure the housing and mounting hardware remain secure is recommended. If the screen becomes difficult to extend or retract smoothly, check for obstructions and confirm the housing is level and securely fastened.
