Dell Networking 40GbE QSFP+LR4 Transceiver with 10km Reach on SMF

Experience uncompromising high-speed fiber connectivity with the Dell Networking 40GbE QSFP+LR4 transceiver. Engineered for use in qualified Dell Networking switches, this compact, hot-swappable module delivers robust 40 Gigabit Ethernet performance over single-mode fiber (SMF) with a reach of up to 10 kilometers. Whether you’re building a data center backbone, connecting campus sites, or enabling high-bandwidth server-to-server links, this LR4 transceiver combines Dell reliability with LR4’s efficient multi-lane design to maximize port density, minimize latency, and simplify network scaling. With four parallel 10G lanes and a 1310 nm wavelength profile, you gain the bandwidth you need while maintaining signal integrity across longer distances. It’s an ideal choice for organizations seeking resilient, future-ready connectivity that remains straightforward to deploy and manage within Dell Networking ecosystems.

• 40GbE, four-lane QSFP+ LR4 architecture: Delivers aggregate data rates of 40 Gbps through four parallel 10G channels, enabling high-throughput workloads such as virtualization, big data analytics, and storage area networks while preserving low latency and consistent performance.
• Long-reach LR4 design for SMF: Optimized for single-mode fiber with an effective reach of up to 10 kilometers, supporting data center interconnects, campus backbones, and remote server clusters without repeaters or additional amplification.
• Dell Networking compatibility: Specifically qualified for use in Dell Networking switches, ensuring reliable operation, plug-and-play deployment, and streamlined management within your Dell environment.
• LR4 wavelength technology with LC duplex connectors: Utilizes four 1310 nm channels multiplexed for high-efficiency long-haul transmission, paired with standard LC duplex fiber connections for straightforward fiber routing and maintenance.
• Hot-swappable, plug-and-play convenience: Designed for easy installation with minimal downtime, enabling quick upgrades or replacements in active networks while maintaining service continuity.

Technical Details of Dell Networking Transceiver, 40GbE QSFP+LR4, 10km Reach on SMF

• Product form factor: QSFP+ hot-pluggable transceiver module
• Technology: 40GBASE-LR4 (four 10G lanes multiplexed for 40 Gbps)
• Data rate: 40 Gbps total (40GbE)
• Reach: Up to 10 kilometers on single-mode fiber (SMF)
• Fiber type: Single-mode fiber
• Connector: LC duplex (per lane, four lanes in total)
• Wavelength: 1310 nm per lane
• Compatibility: Qualified for Dell Networking switches

How to install Dell Networking Transceiver, 40GbE QSFP+LR4

• Prepare the work area: ensure you have clean, properly rated single-mode fiber cables, an appropriate fiber cleaning kit, and your Dell Networking switch documentation on hand.
• Verify compatibility: confirm your Dell switch model is on the qualified list for this QSFP+ LR4 transceiver to guarantee supported operation and optimal performance.
• Handle with care: hold the transceiver by its edges; avoid touching the optical connectors to prevent contamination that could degrade link quality.
• Install the module: align the QSFP+ LR4 module with the switch’s QSFP+ port, slide it in firmly until the retention mechanism latches, and ensure it is seated securely.
• Connect the fiber: remove protective cap from each LC connector, inspect fiber ends for cleanliness, and connect the four LC duplex fibers as required by your topology. Route fibers to prevent excessive bending or tension.
• Power and verify: if your network allows hot-swapping, you can install the module with power on; otherwise, power down the switch before insertion. After installation, check the port status in the switch management interface; confirm a stable 40GbE link and verify traffic flow using a quick throughput test or loopback test as appropriate.

Frequently asked questions

• Q: What is the primary use case for the Dell Networking 40GbE QSFP+LR4 transceiver? A: It provides high-bandwidth, long-reach 40GbE connectivity over SMF, ideal for data center interconnects, campus backbones, and high-performance server or storage networking within qualified Dell Networking environments.
• Q: How far can this transceiver transmit? A: Up to 10 kilometers on single-mode fiber, enabling span connections between distant data center racks, rooms, or buildings without repeaters.
• Q: What type of fiber and connectors are used? A: It uses single-mode fiber with LC duplex connectors; four lanes are multiplexed within the LR4 scheme to achieve 40 Gbps total bandwidth.
• Q: Is the transceiver hot-swappable? A: Yes. The QSFP+ LR4 module is designed for hot-swappable installation in compatible Dell Networking switches, allowing minimal downtime during upgrades or maintenance.
• Q: Is this transceiver compatible with non-Dell devices? A: It is intended for Dell Networking switches and qualified environments; performance and support on non-Dell hardware are not guaranteed.
• Q: What does LR4 mean in this context? A: LR4 refers to the long-reach variant of 40GBASE-LR4, which uses four 1310 nm laser channels to achieve 40Gbps over longer distances on SMF.
