Eaton 1.9kW Single-Phase Switched PDU — LX Platform, 24 x NEMA 5-15/20R, 0U 120V, L5-20P, TAA

Introduce precision power management into your IT environment with the Eaton 1.9kW Single-Phase Switched PDU. Designed for data centers, server rooms, and high-demand labs, this LX Platform PDU delivers reliable, scalable distribution at 120V with real-time visibility and control. Its compact 0U footprint makes it ideal for tight spaces inside standard 19-inch racks, while its rugged construction and industry-leading efficiency help you manage uptime, improve energy efficiency, and simplify administrative tasks. With 24 NEMA 5-15/20R outlets, a single L5-20P input, and outlet monitoring, this PDU combines powerful distribution with granular insight for proactive maintenance and smarter load balancing.

• High-capacity 1.9 kW at 120V provides ample headroom for servers, switches, storage devices, and other rack-mounted equipment without overloading the circuit, helping to prevent nuisance outages and allowing for growth in busy data centers.
• LX Platform with outlet monitoring delivers real-time visibility into the status and energy usage of each outlet. This per-outlet monitoring enables precise capacity planning, alerting, and powerful insights that reduce energy waste and support proactive maintenance.
• Switched power control enables remote power cycling and on/off control of individual outlets, improving mean time to repair for devices, simplifying reboot processes, and allowing advanced load management without onsite visits.
• 0U rack-mount form factor fits cleanly into standard 19-inch racks while occupying no horizontal rack space, preserving valuable rack units for IT gear and reducing cabling clutter in dense environments.
• 24 outlets at 120V (NEMA 5-15/R and 5-20R) support mixed devices across the data center floor, with a robust L5-20P input plug for reliable, dedicated 20A power, and a TAA-compliant build for federal and commercial procurement requirements.

Technical Details of Eaton 1.9kW Single-Phase Switched PDU

• Power rating: 1.9 kW at 120V (single-phase)
• Outlets: 24 NEMA 5-15R / 5-20R receptacles for versatile device compatibility
• Input plug: L5-20P (120V, 20A) for a strong, reliable connection to a dedicated power source
• Form factor: 0U, designed for unobtrusive installation in standard 19-inch racks
• Platform: LX platform with outlet monitoring for real-time per-outlet data
• Control: Switched outlets for remote power cycling and management
• Build: TAA-compliant construction suitable for government and enterprise procurement

How to Install Eaton 1.9kW Single-Phase Switched PDU

• Plan the installation in a standard 19-inch rack and identify a suitable location with adequate ventilation and cable access. Confirm that the rack slot supports a 0U device and that the available power circuit can handle the 20A input required by the L5-20P plug.
• Mount the PDU using the supplied hardware, ensuring secure engagement with the rack rails. The 0U form factor means installation is designed to minimize space while delivering stable support for a dense rack setup.
• Connect the L5-20P input plug to a compatible 120V power source rated for 20A. Verify the circuit can handle the anticipated continuous load to avoid tripping breakers or voltage drop under peakDemand.
• Route and connect your devices to the 24 NEMA 5-15R/5-20R outlets. Consider labeling critical devices and grouping IT equipment by function to maximize outage impact assessment and maintenance planning.
• Configure the LX platform management settings to enable outlet monitoring, define alert thresholds, and establish remote switching policies. Validate per-outlet status, run a controlled power cycle on select outlets, and confirm devices respond correctly to remote commands.

Frequently asked questions

• Q: How many outlets does this PDU provide? A: 24 outlets using NEMA 5-15R and 5-20R receptacles, suitable for mixed IT devices in a rack environment.
• Q: What is the input power specification? A: The PDU uses a 120V, L5-20P input plug rated for 20A, delivering up to 1.9 kW of power.
• Q: What does “0U” mean for installation? A: 0U indicates the PDU does not occupy any vertical rack space, allowing you to maximize the number of standard vertical rack units available for IT equipment.
• Q: What is outlet monitoring? A: Outlet monitoring provides real-time visibility into each outlet’s status and energy usage, enabling proactive power management and precise capacity planning.
• Q: Is this PDU compliant with procurement standards? A: Yes, it is TAA-compliant, making it suitable for government and enterprise purchasing programs.
• Q: Can I remotely switch outlets? A: Yes, the LX platform enables remote power cycling and control of individual outlets to simplify reboot workflows and improve uptime.
