Eaton 3.7kW Single-Phase 208/230V Monitored PDU - LX Platform

Power reliability and real-time visibility are essential for modern IT environments. The Eaton 3.7kW Single-Phase Monitored PDU on LX Platform delivers scalable, space-efficient power distribution with advanced remote monitoring, making it ideal for data centers, server rooms, and network closets. With 8 C13 outlets, a C20 input plus L6-20P adapter, and a 2.4-meter cord in a compact 1U rack-mount form factor, this PDU provides comprehensive control over critical workloads in a compact footprint. Built to meet the needs of busy IT operations, it combines precise power delivery with proactive alerting to help prevent outages and optimize energy use across devices and applications.

• Real-time remote monitoring of voltage, frequency and load levels via a built-in network connection, so administrators can see power health at a glance and respond before issues become outages.
• LX Platform interface with customizable notifications delivered through email, secure web access, SNMP, Telnet or SSH, enabling multi-channel alerts and centralized power management across the data center.
• Flexible power configuration for global deployments: 8 C13 outlets for distributed IT gear, a C20 input with L6-20P adapter, and a 2.4-meter power cord to simplify rack siting and cable management.
• Space-saving, 1U rack-mount design engineered for dense racks and top-of-rack deployments, delivering scalable power distribution without compromising cabinet space.
• Rugged, compliant design with data-center ready features and TA A (Trade Agreement Act) compliance to support enterprise procurement and global deployments.

Technical Details of Eaton 3.7kW Single-Phase 208/230V Monitored PDU - LX Platform, 8 C13 Outlets, C20 Input with L6-20P Adapter, 2.4m Cord, 1U Rack-Mount, TAA

• Power capacity: 3.7 kW (approximately 16 A at 230 V), suitable for dense server and network gear in small-to-mid-size deployments.
• Voltage and phase: Single-phase operation at 208/230 V to match common data-center and equipment requirements.
• Outlets: 8 C13 outlets to power a mix of servers, storage, and network devices from a single distribution point.
• Input and cord: C20 power input with L6-20P adapter; 2.4 m cord length to accommodate varied rack and cabinet layouts.
• Mounting and form factor: 1U rack-mountable design, optimized for space in standard server racks while keeping cabling neat and accessible.
• Monitoring and management: Real-time power monitoring with LX Platform integration, enabling voltage, frequency and load monitoring along with remote configuration.
• Notification and access: Customizable alerts and management through email, secure web, SNMP, Telnet and SSH for flexible, secure remote administration.
• Compliance and compatibility: TA A-compliant unit designed for enterprise procurement and global deployments with appropriate safety certifications for data center environments.

How to Install Eaton 3.7kW LX Platform Monitored PDU

Install this PDU quickly and safely in a standard 19-inch rack to begin benefiting from real-time power visibility. Follow these steps to ensure a solid, reliable setup that supports scalable IT operations:

• Mount the PDU in a 1U rack space using the included rails or mounting kit. Align the unit with other equipment to minimize cabinet vibration and ensure accessible front-panel outlets for maintenance.
• Connect the power input: attach the 2.4-meter cord to the C20 input, then connect the L6-20P adapter to a compatible power source. Ensure the supply voltage matches the PDU’s 208/230 V rating and that the circuit can handle up to 3.7 kW of load.
• Populate outlets: plug servers, storage, and network devices into the 8 C13 outlets, balancing loads across outlets to avoid overloading any single circuit.
• Establish network connectivity: connect the PDU’s built-in network interface to your management network (Ethernet is typical). This enables LX Platform remote monitoring and multi-protocol access for alerts and configuration.
• Configure LX Platform: access the secure web interface or use SNMP/Telnet/SSH to set up voltage and load thresholds, notification recipients, and alert policies. Validate connectivity by generating a test alert and confirming receipt on configured channels.

Frequently asked questions

• What outlets does the PDU provide? The unit features 8 C13 outlets for flexible distribution to a range of IT equipment.
• What type of input power does it require? It uses a C20 input with an L6-20P adapter and includes a 2.4-meter cord, supporting 208/230 V single-phase environments.
• What management features are included? The LX Platform provides real-time monitoring of voltage, frequency and load, plus customizable alerts via email, secure web, SNMP, Telnet and SSH for comprehensive remote management.
• Is this PDU suitable for data centers and enterprise IT? Yes. It is designed for rack-mounted deployments with data-center-grade monitoring capabilities and TA A compliance to support enterprise procurement and global deployments.
• How do I verify the PDU is functioning correctly? After installation, connect to the LX Platform, verify live readings for voltage and load, and trigger a test alert to ensure notification channels are working as configured.
