Eaton 5PX Extended Battery Module for 1000/1500/2200 VA 5PX UPS 48V TAA 2U
The Eaton 5PX Extended Battery Module (EBM) is the ultimate upgrade for your 5PX uninterruptible power supply, delivering scalable runtime, reliable performance, and practical, maintenance-free energy storage. Specifically designed to work with Eaton’s 5PX UPS models in the 1000, 1500, and 2200 VA range, this 48V EBM is a compact, 2U solution that expands backup time without compromising space in tight data center racks or server rooms. Built to meet the demands of modern IT environments, the EBM combines high-quality battery technology with Eaton’s renowned reliability, helping you keep critical systems online during outages and brief power disturbances.
- Extended runtime for critical loads: When paired with compatible 5PX UPS units, the Extended Battery Module significantly increases available runtime. This makes it ideal for servers, networking equipment, and storage devices that require longer staying power during outages or voltage sags, ensuring essential services stay online while power is restored.
- 2U rack-mount form factor for efficient deployment: The EBM is engineered in a compact 2U chassis that integrates neatly into standard rack environments. Its slim profile leaves room for other critical equipment while still delivering substantial runtime improvements. This design helps IT teams maximize cabinet space and maintain tidy, scalable power protection infrastructure.
- TAA-compliant for procurement flexibility: The Extended Battery Module adheres to Trade Agreements Act (TAA) requirements, making it a preferred choice for government, defense, and other regulated procurement environments. This compliance helps simplify sourcing and reduces procurement friction for organizations with strict purchasing policies.
- High-quality SLA battery technology for long life and reliability: The EBM uses sealed lead-acid (SLA) battery technology optimized for longevity, stable performance, and low maintenance. This yields dependable energy storage with consistent discharge characteristics, helping protect sensitive equipment from sudden outages and power quality issues.
- Seamless integration with Eaton management tools: The Extended Battery Module works in concert with Eaton’s monitoring and management capabilities, allowing you to view battery health, runtime estimates, and environmental conditions from compatible software interfaces. This centralized visibility simplifies maintenance, reduces guesswork, and supports proactive power protection planning.
Technical Details of Eaton 5PX Extended Battery Module for 1000/1500/2200 VA 5PX UPS 48V TAA 2U
- Compatibility: Designed for Eaton 5PX UPS models in the 1000, 1500, and 2200 VA range and 48V battery configurations. The EBM provides scalable runtime when used with appropriate 5PX units, enabling a tailored protection profile for varied workloads.
- Form Factor: 2U rack-mountable Extended Battery Module, engineered to fit standard server room racks and preserve valuable rack space while delivering extended power protection.
- Voltage and Battery Type: 48V DC battery system housed in a sealed lead-acid (SLA) module designed for long life, reliable performance, and straightforward maintenance. The SLA chemistry supports predictable discharge behavior and stable UPS operation under load.
- Compliance and Certification: TAA-compliant, suitable for federal, state, and local procurement programs that require compliance with trade and sourcing standards. Typical safety and performance certifications align with industry expectations for mission-critical power protection equipment.
- Installation and Interoperability: Integrates with Eaton 5PX UPS units via standard EBM connectors and mounting interfaces. The module supports hot-swap capability in many configurations, enabling you to extend runtime without powering down the protected equipment (availability depends on UPS model and configuration).
- Physical and Environmental Considerations: Engineered for rack deployment in data centers and IT closets, with attention to stable operation under typical data center temperatures and humidity levels. The EBM’s robust construction supports daily use in environments requiring reliable, long-lasting battery support.
How to Install Eaton 5PX Extended Battery Module
Installing the Eaton 5PX Extended Battery Module is a straightforward process designed to minimize downtime and disruption to active workloads. Follow these steps to add an EBM to your 5PX UPS setup and immediately begin benefiting from extended runtimes:
Prepare the space and equipment: Ensure you have a clean, dry workspace around the UPS and rack. Verify that the UPS is powered off and unplugged from the wall outlet, and if possible, disconnect any connected devices to avoid accidental power-on during installation.
Verify compatibility: Confirm that your 5PX UPS model is listed as compatible with the Extended Battery Module and that you’re using the appropriate 48V EBM for your unit. This ensures proper communication, monitoring, and runtime scaling.
Power down and unlock the rack: If the UPS is installed in a rack, use standard rack safety practices. Remove any front cover panels if necessary to access the UPS’s EBM bay, following the manufacturer’s service guidelines.
Connect the EBM: Carefully align the EBM with the UPS’s hot-swap or slot interface. Insert the module firmly until it seats with a solid click. If screws or retention hardware are required for securing the module, install them according to the UPS documentation, ensuring the EBM is firmly in place for stable operation.
Power up and configure: Restore power to the UPS and enable the unit. Access the UPS management interface to verify that the EBM is detected and reporting battery health. Run a self-test or battery test as recommended by Eaton to confirm proper operation and to initialize the extended runtime calculations.
Monitor and validate: Use Eaton’s monitoring software or the UPS’s built-in display to confirm battery status, estimated runtime, and any alerts. Ensure the EBM is recognized as part of the overall power protection strategy and that the runtime increases align with load profiles.
Notes for installation success: Always follow your organization’s electrical safety policies and the Eaton installation guide. If you encounter any issues with recognition, battery health readings, or runtimes, consult Eaton support or your authorized reseller for guidance. While the EBM is designed for straightforward installation, certain configurations or enterprise environments may have specific requirements for firmware updates or management software compatibility.
Frequently asked questions
Q: What does the Eaton 5PX Extended Battery Module do?
A: The EBM extends the runtime of compatible 5PX UPS units by adding additional 48V battery capacity. It is ideal for protecting critical IT equipment during power outages, allowing longer operation without switching to generator power and reducing the risk of data loss or service interruption.
Q: Is the EBM hot-swappable?
A: Yes. The Extended Battery Module is designed for easy installation and removal, enabling maintenance and replacements with minimal downtime. Do follow proper safety procedures and UPS shutdown requirements when performing maintenance.
Q: Which 5PX models are compatible?
A: The EBM is designed for Eaton 5PX UPS units in the 1000, 1500, and 2200 VA range. Always verify compatibility with your specific UPS model and firmware version before purchase and installation.
Q: Is the EBM compliant with government procurement?
A: Yes. The EBM is TAA compliant, making it suitable for government and other organizations with strict purchasing requirements.
Q: How does the EBM affect energy efficiency and total cost of ownership?
A: By extending runtime and protecting equipment from unexpected outages, the EBM helps reduce data loss risks and downtime expenses. While there is an upfront cost for the module, the improved uptime and protection can lower maintenance and replacement costs over the life of the UPS system.
Q: How do I verify battery health and runtime after installation?
A: Use the Eaton management interface or compatible software to check battery health indicators, estimated runtime at current load, and temperature readings. Regular monitoring helps ensure the EBM delivers the expected performance and allows proactive replacement as needed.
