Eaton 9PX 11kVA 208V Online Double-Conversion UPS

Power reliability is essential for IT infrastructure, edge networks, and data centers. The Eaton 9PX 11kVA 10kW 208V Online Double-Conversion UPS delivers industry-leading battery backup and power conditioning to protect servers, storage, networking gear, and virtualization platforms from outages, surges, and noisy power lines. Built for rack-mount deployment, this 9U UPS combines online double-conversion technology with efficient operation, advanced management features, and scalable runtime options. With hardwired input, 8x 5-20R outlets, 2x L14-30R outlets, and a Cybersecure Network Card, it provides secure, flexible power protection for critical workloads in both data centers and edge environments. Extended Run capabilities let you tailor uptime to your business needs, ensuring graceful shutdowns and continuity even during extended outages.

• Robust power capacity and protection: 11 kVA / 10 kW online double-conversion topology delivers a pristine output waveform, maintaining consistent voltage and frequency even during utility disturbances, so sensitive IT equipment stays protected and available.
• Flexible outlet configuration with hardwired input: Features 8x NEMA 5-20R receptacles and 2x NEMA L14-30R outlets for critical loads, paired with a hardwired input connection for clean integration into dedicated 208V circuits in racks or cabinets.
• Secure remote management included: Comes with a Cybersecure Network Card for secure remote monitoring, alerting, and control through standard management software, enabling proactive power quality management from anywhere on the network.
• Extended Run and scalable runtime options: Ready for Extended Run configurations with external batteries, allowing longer backup times for essential systems during outages and avoiding data loss or abrupt shutdowns.
• Rugged 9U rack-mount design for data centers and edge deployments: The compact 9U footprint fits standard 19-inch racks, with front-accessible components and hot-swappable batteries to minimize downtime during maintenance and battery replacement.

Technical Details of Eaton 9PX 11kVA 10kW 208V Online Double-Conversion UPS

• Capacity: 11 kVA / 10 kW, suitable for protecting multiple servers, storage devices, virtualization hosts, and network gear in enterprise and edge environments.
• Output voltage: 208 VAC, delivering a clean, stable power waveform to connected equipment regardless of input fluctuations.
• Topology: Online double-conversion with automatic voltage regulation (AVR) to isolate critical loads from input voltage irregularities and ensure consistent output quality.
• Outlets and connectivity: 8x NEMA 5-20R receptacles and 2x NEMA L14-30R outlets, plus a hardwired input configuration for flexible deployment in racks and IT closets.
• Management and security: Includes a Cybersecure Network Card for secure remote monitoring, alerting, and control; compatible with Eaton’s IPM software suite for centralized power management.
• Runtime options: Supports Extended Run configurations with external battery modules to extend uptime for critical workloads during longer outages.
• Form factor and mounting: 9U rack-mountable chassis designed for 19-inch racks, with front-accessible maintenance features and hot-swappable battery packs for rapid serviceability.
• Protection features: Comprehensive protection against blackouts, brownouts, surges, line noise and spikes, preserving data integrity and preventing unexpected shutdowns.
• Environment and efficiency: Optimized for data centers and edge deployments, delivering reliable performance with energy-efficient operation and reduced total cost of ownership.

How to Install Eaton 9PX 11kVA 10kW 208V Online Double-Conversion UPS

• Plan your rack layout and verify the installation site supports a 9U footprint, proper ventilation, and adequate clearance for maintenance and battery replacement.
• Mount the UPS securely in a standard 19-inch rack using the supplied rails, ensuring the front panel remains accessible for monitoring and maintenance.
• Connect the input power to a dedicated 208V circuit with the appropriate breaker sizing and wiring, using a hardwired connection as specified by your facility’s electrical code.
• Distribute your IT loads across the outlets: place mission-critical devices on the 2x L14-30R outlets for high-priority equipment and use the 8x 5-20R outlets for other essential gear, maintaining a balanced load to optimize runtime.
• Install the Cybersecure Network Card in the designated management slot and connect the UPS to your network infrastructure. Configure IP settings through the web interface or Eaton’s management software, set up alerts, and enable secure remote access.
• Power up the UPS, perform a self-test, calibrate output sensors, and verify communication with connected devices and monitoring software. Validate battery health periodically and schedule firmware updates as needed.
• If you plan to extend runtime, connect optional External Battery Modules (EBMs) and configure Extended Run settings in the management software to meet your uptime targets.

Frequently Asked Questions

• Q: What loads can the Eaton 9PX 11kVA protect? A: With an 11 kVA / 10 kW rating, it can back up multiple servers, virtualization hosts, storage, and networking equipment. Always perform a load calculation to ensure the critical load stays within the UPS’s capacity for the desired runtime.
• Q: Can runtime be extended? A: Yes. The UPS supports Extended Run configurations with External Battery Modules (EBMs) to deliver longer backup times for essential services during outages.
• Q: Is remote management secure? A: Yes. The included Cybersecure Network Card provides secure remote monitoring and control, with support for encrypted communication and authenticated access through Eaton’s software suite.
• Q: Is this unit rack-mountable? A: Absolutely. The 9U rack-mount design fits standard 19-inch racks commonly used in data centers and edge installations, with front access for easy maintenance.
• Q: How do I connect my devices? A: Connect critical IT equipment to the two L14-30R outlets for higher-priority loads and distribute other essential gear across the eight 5-20R outlets. Ensure the total connected load does not exceed the UPS rating.
• Q: What about battery maintenance? A: The UPS supports hot-swappable batteries on the front, enabling field replacement without powering down critical workloads. Regular battery health checks are recommended to maintain runtime readiness.
