Eaton 9PXM 8-Slot External Battery Cabinet for 9PXM UPS – Extend Runtime and Expand Capacity

The Eaton 9PXM 8-Slot External Battery Cabinet is designed to dramatically extend the runtime of your Eaton 9PXM online double-conversion UPS. This external enclosure is purpose-built for colocation facilities, edge data centers, and a broad range of industrial and commercial environments, including retail, financial services, and government deployments. By housing multiple External Battery Modules (EBMs), this cabinet enables scalable backup power that protects critical workloads from outages, ensures seamless system availability, and helps you meet stringent uptime requirements. Whether you are expanding a new installation or upgrading an existing site, the 8-slot battery cabinet provides a flexible, rugged, and procurement-friendly solution that integrates smoothly with Eaton's advanced UPS ecosystem. Expect improved resilience, easier maintenance, and a clear path to meet evolving business continuity objectives.

• Extended runtime with scalable capacity: This 8-slot external battery cabinet works hand-in-hand with the Eaton 9PXM UPS to deliver long-lasting backup power. By housing multiple EBMs, you can tailor runtime to support workloads during electrical disturbances, utility outages, or critical failover scenarios, helping to minimize data loss and service interruptions in edge deployments and large colocation facilities alike.
• Up to 3 EBMs for flexible growth: Planning for future demand is simple with the ability to add up to three External Battery Modules. This modular approach lets you scale backup capacity as your business grows or as workload profiles change, without replacing the core UPS. It also enables staged asset deployment, easier maintenance windows, and a clearer total cost of ownership over time.
• 14U rack/tower compatibility for versatile installation: The cabinet is designed to fit standard 19-inch racks in data centers and can also be configured in a tower orientation for spaces where rack space is at a premium or where temporary deployments are needed. This flexibility supports a range of installation scenarios—from traditional data center racks to remote or edge locations—while keeping cabling tidy and serviceable from the front.
• Intelligent integration for enterprise reliability: When paired with the 9PXM UPS, the external cabinet benefits from Eaton’s robust battery management and diagnostics. Operators can monitor battery health, estimated runtime, and aging status through Eaton’s management tools, enabling proactive maintenance and optimized battery replacements. The system is designed to work seamlessly with Eaton’s IPM (Intelligent Power Manager) ecosystem for centralized control and reporting.
• Government-ready and procurement-friendly (TAA-compliant): The 8-Slot External Battery Cabinet carries TAA compliance, making it suitable for government and public-sector procurement. This expands its applicability across enterprise customers with strict purchasing requirements, while preserving the reliability and performance you expect from Eaton’s power protection solutions.

Technical Details of Eaton 9PXM 8-Slot External Battery Cabinet

• Product: Eaton 9PXM 8-Slot External Battery Cabinet (external enclosure for 9PXM UPS)
• Slot capacity: 8 external battery module slots
• Expansion capability: Supports up to 3 EBMs
• UPS compatibility: Designed to connect with the Eaton 9PXM Online Double-Conversion UPS family
• Footprint: 14U rack/tower configuration for flexible deployment
• Compliance: TAA-compliant for government procurement
• Use cases: Ideal for colocation, edge data centers, and industrial/commercial applications (retail, financial services, government)
• Management and monitoring: Integrates with Eaton energy management tools (IPM and related software) for battery health, runtime, and alert monitoring

How to install Eaton 9PXM 8-Slot External Battery Cabinet

• Confirm compatibility: Ensure your data center installation uses a compatible Eaton 9PXM UPS and that you have the appropriate cabling and mounting hardware for the 14U rack/tower configuration.
• Prepare the site: Choose a clean, ventilated location with adequate rack space. Verify cooling and access paths to the front of the cabinet for maintenance and battery replacement.
• Mount the cabinet: Install the 8-slot external battery cabinet into a standard 19-inch rack or set it up in a tower orientation, following the manufacturer’s mounting guidelines for weight distribution and stability.
• Electrical and data connections: Connect the external cabinet to the 9PXM UPS using the appropriate Eaton communication and power connectors as specified in the installation manual. Ensure all connections are secure and compliant with local electrical codes.
• Install EBMs: Place External Battery Modules into eight available slots, ensuring proper seating and alignment. Verify that each module is correctly seated and detected by the UPS management system.
• Initial power-up and configuration: Power on the system and use Eaton’s Intelligent Power Manager (IPM) or your preferred management tool to verify battery status, runtime estimates, and aging indicators. Run any required battery tests or calibration procedures per the product guidelines.
• Documentation and monitoring: Document the installation and configure alerts for low-capacity or end-of-life batteries. Establish a maintenance schedule aligned with manufacturer recommendations to maximize battery life and uptime.
