Eaton ATS Rack PDU 1U – Dual Input with Automatic Transfer Switch, 2x L6-20P / 2x C20 Input, 8x C13 + 1x C19, 3.33 kW, 200-240V, 16A, 8 ft Cord, Single-Phase

The Eaton ATS rack PDU combines high-density power distribution with intelligent automatic transfer switch (ATS) technology, specifically designed to keep critical equipment powered even when two non phase-synchronized AC power sources are in play. This 1U, single-phase power distribution unit provides a robust solution for data centers, server rooms, and IT closets where uptime is non-negotiable. With dual input capability and fast, seamless switching between sources, it protects essential servers, storage systems, and network devices from interruptions caused by power source failures or disturbances. The built-in monitoring and switching circuitry continuously analyzes input quality, source availability, and load distribution, allowing for near-instantaneous transfer between primary and secondary power sources without impacting connected equipment. In short, it is engineered to maximize uptime, minimize risk, and simplify power management in demanding environments.

• Intelligent automatic transfer switch (ATS) that monitors two input sources and performs rapid, seamless transfer to the secondary source when the primary source is compromised, helping to prevent downtime for critical IT gear.
• Flexible dual-input configuration with (2) L6-20P or (2) C20 input options, enabling reliable redundancy and safer load balancing in data centers, edge locations, and rack rooms.
• Versatile output suite featuring (8) C13 outlets and (1) C19 outlet, providing broad compatibility for servers, storage arrays, network switches, and other essential devices while maintaining tidy cable management.
• Compact 1U rack-mount form factor with an 8 ft power cord, designed to maximize rack density without sacrificing accessibility or airflow for cooling efficiency.
• Reliable, single-phase operation at 200-240V and up to 16A (3.33 kW), delivering consistent power quality to critical equipment while simplifying integration with existing data center infrastructure and Eaton ePDU ecosystems.

Technical Details of Eaton ATS Rack PDU

• Model: Eaton ATS Rack PDU (1U)
• Inputs: (2) L6-20P input connectors and (2) C20 input connectors
• Outputs: (8) C13 outlets and (1) C19 outlet
• Power rating: 3.33 kW
• Voltage: 200–240V
• Current: 16A
• Phase: Single-phase
• Cord length: 8 ft
• Form factor: 1U rack-mountable, 19 in. rack width
• Protection/transfer: Automatic transfer switch designed for switching between non phase-synchronized power sources with minimal interruption
• Intended use: Ideal for IT closets, servers, networking gear, and data center applications requiring redundant power and reliable uptime

How to install Eaton ATS Rack PDU

• Confirm rack compatibility: Ensure your enclosure has standard 19-inch rack mounting rails and adequate clearance for air flow and cable management. The 1U form factor fits neatly into dense rack arrays without compromising access to rear I/O or cooling.
• Prepare mounting: Align the PDU with the rack rails and secure it using the provided mounting hardware. Tighten screws evenly to prevent any flex or misalignment that could affect plug accessibility.
• Connect dual inputs: Attach the two input power sources to the appropriate ports—L6-20P and/or C20 inputs as configured for your facility. Ensure that both sources are synchronized with your electrical distribution plan and that circuit breakers are sized to support the combined load.
• Connect IT equipment: Plug servers, storage devices, and network gear into the 8 C13 outlets and 1 C19 outlet. Plan outlet layout to minimize cable clutter and ensure adequate airflow around devices.
• Power-up and verify ATS operation: Restore power and observe indicator LEDs or monitoring software to confirm normal operation. If the primary source fails, verify that the ATS switches to the secondary source smoothly and that connected equipment remains powered without interruption.
• Documentation and testing: Label all power connections, document the dual-source setup, and conduct periodic failover tests as part of routine disaster recovery or uptime testing regimes.

Frequently asked questions

• Q: What is an ATS PDU and why is it important? A: An ATS PDU uses an automatic transfer switch to monitor two independent power sources and seamlessly switch to the secondary source if the primary source becomes unstable or fails, helping maintain continuous power to critical IT equipment.
• Q: How many outlets and what types are available? A: The unit provides eight C13 outlets and one C19 outlet, offering broad compatibility for typical data center and IT gear such as servers, storage, and networking devices.
• Q: Can I use dual inputs for redundancy? A: Yes. The PDU supports dual input configurations via two L6-20P connectors and two C20 inputs, enabling reliable redundancy for mission-critical applications.
• Q: What is the voltage and current rating? A: The PDU is designed for 200–240V, single-phase operation, with a maximum current of 16A and a power rating up to 3.33 kW.
• Q: Is this PDU suitable for rack mounting? A: Absolutely. It is a 1U, 19-inch rack-mountable PDU intended to optimize space in data centers, server rooms, and network closets while maintaining performance and airflow.
• Q: How do I ensure proper uptime? A: Implement regular ATS tests, verify dual-source wiring, and monitor the PDU via built-in indicators or compatible management software to detect and respond quickly to power disturbances.
