Eaton ATS Rack PDU 1U 3.3 kW 16A 110-125V | 2 C20 Inputs, 8 C13, 1 C19 Outputs

The Eaton ATS Rack PDU is a compact, high-density power distribution unit designed for critical IT environments. Engineered to maximize uptime and streamline maintenance in data centers, server rooms, and network closets, this 1U rack-mountable PDU delivers dependable power distribution with dual input options and a versatile mix of IEC outlets. Built to support modern, power-hungry IT gear, it combines robust electrical design with practical rack integration to keep equipment running smoothly under demanding workloads. With 2 C20 inputs and a combination of 8 C13 outlets plus 1 C19 outlet, this Eaton PDU helps IT managers simplify cabling, improve airflow, and ensure reliable delivery of power to racks full of servers, storage devices, and networking hardware.

• Redundancy and uptime: The Eaton ATS Rack PDU provides dual C20 power inputs, enabling connections to two independent power sources. This configuration helps maintain operations during a single-source power disruption and supports automatic transfer switch (ATS) functionality to minimize downtime for critical IT equipment.
• High-density outlet mix: Designed for versatile IT deployments, it offers 8 C13 outlets and 1 C19 outlet, allowing you to power a wide range of servers, storage devices, switches, and other rack-mount equipment from a single, centralized distribution point. This mix accommodates both modest and demanding loads while keeping power distribution organized in a 1U footprint.
• 1U, rack-mountable efficiency: With a compact 1U form factor, this PDU preserves valuable rack space while providing robust power distribution. Its standard 19" rack compatibility makes installation straightforward in most data centers and offices, enabling streamlined cable management and improved airflow around equipment.
• IEC 60320 compatibility and safety: The PDU uses industry-standard IEC 60320 connectors, including C20 inputs, C13 outlets, and a C19 outlet. This ensures broad compatibility with a wide range of IT devices and power cords, while supporting safe, reliable power delivery in regulated environments.
• Designed for reliability in demanding environments: Built to withstand the rigors of continuous operation, the Eaton PDU combines quality construction with precise electrical engineering to help reduce maintenance needs and extend equipment life. It’s ideal for data centers, collocation facilities, and enterprise IT rooms that require dependable, scalable power distribution.

Technical Details of Eaton ATS Rack PDU

• Power rating: 3.3 kW, 110–125 V, 16 A (as stated in the product title and description).
• Apparent power: 1.92 kVA.
• Form factor: 1U rack-mountable.
• Inputs: 2 x IEC 320 EN 60320 C20 sockets.
• Outputs: 8 x IEC 320 EN 60320 C13 sockets, 1 x IEC 320 EN 60320 C19 socket.
• Outlet/receptacle types: C13 and C19 compatibility for broad IT equipment support.
• Mounting standard: 19" rack compatibility, optimized for space-constrained deployments.
• Primary use: power distribution for servers, storage, networking gear, and other data center equipment requiring reliable, centralized power.

How to install Eaton ATS Rack PDU

• Prepare your rack: Verify you have a standard 19" rack with at least 1U of vertical space and sufficient rear clearance for cabling. Confirm that the rack can accommodate dual C20 power feeds and the outlet arrangement.
• Mount the PDU: Align the Eaton ATS Rack PDU with the rack’s vertical rails, slide it into place, and secure it using the mounting screws provided. Ensure the unit is level and firmly fastened to prevent movement during cable management or maintenance.
• Connect power inputs: Attach two independent power cords to the two IEC 60320 C20 inputs. Connect the other ends to two separate power sources or distribution paths as required by your redundancy strategy. If you’re using ATS functionality, follow your facility’s guidelines for automatic source switching to ensure seamless transfer should one source fail.
• Route and connect equipment: Plan your cable management carefully by grouping power cords and labeling outlets. Connect your servers, storage devices, and network gear to the C13 and C19 outlets. Aim for clean, organized cabling to improve airflow and simplify future maintenance.
• Power up and verify: Turn on the PDU and verify indicator LEDs (if present) illuminate as expected. Check that each outlet delivers power to connected devices and that redundancy features engage correctly when multiple power sources are used. Perform a basic load test to ensure balanced loading across available outlets and sources.

Frequently asked questions

• Q: What outlets does the Eaton ATS Rack PDU provide?
  A: It provides 8 C13 outlets and 1 C19 outlet, with 2 C20 inputs for power.
• Q: What is the purpose of the ATS feature?
  A: ATS stands for Automatic Transfer Switch, enabling seamless transfer between redundant power sources to maximize uptime in critical IT environments.
• Q: Is this PDU suitable for a standard 19" rack?
  A: Yes. It is a 1U, 19" rack-mountable PDU designed to fit most standard data center racks while conserving space for other equipment.
• Q: Can I use this PDU with higher voltage systems?
  A: The described configuration is for 110–125 V. For 208–240 V systems, use a PDU model that matches your facility voltage or use appropriate transformers and installation planning per your data center’s electrical design.
• Q: Does the PDU provide any protection features?
  A: The PDU is built for reliable power distribution with IEC 60320 compatibility; always refer to the official product documentation for details on surge protection, overload protection, and safety certifications.
