Eaton Basic PDU 1U 3.33 kW Max 100-240V 16A C20 Input Single-Phase PDU C13

The Eaton Basic PDU is a compact, high-value power distribution solution engineered for reliability in data centers, server rooms, and network closets. Built to fit a single 1U rack space, this horizontal PDU delivers a clean, organized, and scalable way to distribute power to multiple IEC 60320‑coded devices. With 16 IEC 60320 C13 outlets and a robust C20 input, it supports a wide range of IT equipment—from servers and switches to storage arrays and backup devices—while maintaining a tidy, low‑profile footprint in dense rack environments.

• Compact 1U form factor for dense racks: This horizontal PDU is designed to maximize space in 19" server racks, enabling efficient use of vertical real estate while keeping cables and devices organized for optimal airflow and cooling.
• 16 x IEC 60320 C13 outlets for broad IT compatibility: The PDU provides a generous number of C13 receptacles, making it easy to power multiple devices with a single, centralized distribution unit. C13 outlets are a standard across servers, switches, and many network equipment models.
• Flexible, single‑phase input with wide voltage range: The C20 inlet accepts 100–240V AC, enabling operation in different regions and data centers without the need for a voltage conversion. This flexibility supports global deployments and reduces the need for regional variants.
• High power capacity in a compact footprint: With a maximum load of 3330 W (3.33 kW) and a 16 A current rating, the Eaton Basic PDU is well-suited for mid‑range IT deployments where multiple devices require reliable, uninterrupted power distribution.
• Simple, reliable design for IT environments: Built for durability in rack ecosystems, the PDU emphasizes straightforward installation, predictable performance, and easy integration into existing power distribution strategies—ideal for data centers, colocation spaces, and growing IT closets.

Technical Details of Eaton Basic PDU 1U 3.33 kW Max 100-240V 16A C20 Input Single-Phase PDU C13

• Height: 1U
• Mounting: Horizontal 19" rack‑mountable PDU
• Outlets: 16 x IEC 60320 C13 receptacles
• Input connector: IEC 60320 C20 inlet
• Input voltage range: 100–240 V AC
• Nominal voltage: 230 V AC
• Maximum power: 3330 W (3.33 kW)
• Current rating: 16 A
• Phase: Single‑phase
• Configuration: 16 x C13 outlets for IT equipment

how to install Eaton Basic PDU

• Prepare the rack: Ensure your 19" rack is clean, level, and capable of supporting the 1U height. Check available space and plan cable routing to minimize obstruction to airflow.
• Mount the PDU: Attach the Eaton Basic PDU to the rack rails using the included mounting hardware. Align the unit securely, then tighten screws to ensure stability and prevent movement during operation.
• Power down equipment: Before connecting any devices, power down the IT equipment to be connected and verify that the local power source matches the 100–240V AC range supported by the PDU.
• Connect input power: Use a compatible C20 power cord or inlet lead to connect the PDU’s IEC 60320 C20 inlet to the building power supply. Ensure the circuit can safely handle up to 16 A and that voltage is within the 100–240V range.
• Distribute IT devices: Plug servers, switches, storage, and other equipment into the C13 outlets. Balance the load across outlets to avoid overloading any single circuit and to maintain stable performance for critical devices.
• Manage cables and airflow: Route cables neatly, using ties or channels to minimize clutter. Keep intake and exhaust paths clear to support efficient cooling and reduce thermal hotspots within the rack.
• Test and label: Power on the rack and verify that all connected devices receive power. Label each outlet group or branch if you implement a separation by function or device type to streamline maintenance and future upgrades.

Frequently asked questions

• What is the Eaton Basic PDU? A single‑phase, 1U power distribution unit designed to deliver reliable AC power to multiple devices in a 19" rack, consolidating outlets and simplifying cable management.
• How many outlets does it have? It provides 16 IEC 60320 C13 outlets, suitable for powering a range of servers, storage devices, and networking equipment.
• What input does it require? The PDU features an IEC 60320 C20 inlet and accepts 100–240 V AC, enabling operation across many regions and data centers with standard single‑phase power.
• What is the maximum load? The unit supports up to 3330 W (3.33 kW) with a 16 A current rating, making it capable of powering several mid‑range IT devices simultaneously.
• Is it 19-inch rack‑mountable? Yes. The Eaton Basic PDU is designed for horizontal mounting in 19" racks (1U height), making it a practical choice for space‑constrained data centers and IT closets.
• Is it suitable for data centers? Yes. Its compact 1U form factor, 16 C13 outlets, and 100–240 V input range make it a versatile option for distributing power to a mix of servers, switches, and storage equipment in data centers and network rooms.
