Eaton Basic Rack PDU HotSwap MBP 1U

The Eaton FlexPDU Basic Rack PDU with HotSwap Maintenance Bypass is a compact, dependable power distribution solution designed for close mounting to a UPS. Built for reliability in busy data centers, server rooms, and network closets, this 1U PDU delivers clean, organized power to a range of rack-mounted equipment while minimizing cable clutter. With a short power cord, a straightforward input and outlet configuration, and an optional HotSwap Maintenance Bypass to boost uptime, it’s the practical choice for keeping essential gear powered where space is at a premium. This Eaton PDU is purpose-built to support efficient energy management, simplifying deployment and service while helping you optimize rack density and airflow in your IT environment.

• Compact 1U rack-mount design with a short power cord. This slim, space-saving form factor is ideal for close mounting to a UPS, reducing cable runs and improving airflow within the rack. The short cord simplifies cable management, minimizes clutter, and enables a tidy installation in tight data-center spaces or edge deployments. The 1U height accommodates standard 19-inch racks, allowing you to integrate the PDU seamlessly with other equipment, power distribution, and cooling components. Perfect for delivering reliable power to servers, storage devices, switches, and other critical devices without sacrificing rack density.
• Input and outlet configuration tailored for North American equipment. The PDU features a NEMA 5-15P input plug and six NEMA 5-15R receptacles, providing broad compatibility with most standard IT equipment. With six outlets, you can distribute power to multiple devices in a single, organized package, simplifying cable routing and reducing the need for multiple power strips. The configurable receptacles support a diverse range of devices, from servers and routers to KVMs and network appliances, making it a practical choice for mixed racks and multi-vendor environments.
• Electrical specs optimized for performance and safety. This Eaton PDU is rated for 110–125V operation with a 12A maximum current, delivering up to 1.44 kW of power. These specifications align with typical data-center loads while preserving efficiency and minimizing heat load, especially when paired with a balanced mix of equipment. The combination of voltage range, current rating, and power capacity supports dependable distribution for common rack-mount devices, providing straightforward, predictable performance under peak workloads.
• HotSwap Maintenance Bypass to maximize availability. The HotSwap Maintenance Bypass feature enhances overall system availability by allowing maintenance or replacement of the PDU without interrupting power to connected equipment. This capability is particularly valuable in environments requiring high uptime, where technicians can service or replace the PDU while critical loads remain energized through a safe bypass path. This reduces downtime during maintenance cycles and simplifies routine upgrades, contributing to improved serviceability and operational efficiency in data centers and large-scale networks.
• Versatile, reliable power distribution for a range of equipment. The FlexPDU family is designed to support a variety of output receptacles, enabling flexible connections to a wide range of equipment. This basic PDU delivers essential power distribution with a focus on simplicity and reliability, making it suitable for a broad spectrum of IT gear in both new installations and retrofits. Its durable construction and straightforward configuration help IT teams standardize power distribution across racks, streamline maintenance procedures, and optimize space usage without compromising safety or performance.

Technical Details of Eaton Basic Rack PDU HotSwap MBP 1U 110-125V 12A 1.44 kW NEMA 5-15P and 6 5-15R

• Voltage and phase: 110–125V, single-phase
• Current rating: 12A maximum
• Power capacity: up to 1.44 kW
• Input plug: NEMA 5-15P
• Outlets: 6 × NEMA 5-15R
• Form factor: 1U rack-mount
• Cord: Short power cord designed for close mounting to a UPS
• Compatibility: Part of Eaton FlexPDU family with a variety of receptacle options

how to install Eaton Basic Rack PDU HotSwap MBP 1U

Installing the Eaton Basic Rack PDU is a straightforward process designed for reliability and minimal downtime. Follow these general steps to ensure a proper, safe installation that maximizes the PDU’s performance and lifespan:

• Prepare the rack space. Identify a suitable 1U slot in an equipment rack with sufficient clearance for cables and airflow. Ensure the area around the rack is clear of obstructions and that you have access to a nearby UPS or appropriate power source. Verify that the rack serves the intended devices and that the mounting surface is clean and free from debris.
• Mount the PDU in the rack. Position the PDU in the chosen 1U space and secure it using standard rack screws or mounting hardware compatible with your rack system. Align the PDU with the rails to ensure proper support and stability. Confirm the unit remains level and firmly fastened to prevent movement or vibration during operation.
• Connect the input power. Plug the NEMA 5-15P input connector into a suitable UPS outlet or dedicated branch circuit, following your facility’s electrical guidelines. Ensure the UPS can handle the intended load and that the circuit is not already overloaded. Route the input power away from data-cables to minimize interference and maintain proper cable management.
• Distribute power to equipment. Connect devices to the six NEMA 5-15R outlets, distributing loads evenly to avoid overloading a single outlet. Maintain airflow around devices and keep the cables organized to reduce heat buildup and improve serviceability. If you are using the HotSwap Maintenance Bypass feature, familiarize yourself with the bypass procedure and ensure it is engaged only when performing maintenance per the device manual.
• Verify operation and configure as needed. Power on the UPS and verify that connected devices receive power through the PDU. Confirm that any local indicators, alarms, or monitoring interfaces respond as expected. If your facility includes power management software or Eaton’s remote monitoring tools, integrate the PDU to track load, energy usage, and outlet-level monitoring for ongoing optimization and uptime tracking.

Frequently asked questions

• Q: What is the HotSwap Maintenance Bypass and how does it improve uptime?
  A: The HotSwap Maintenance Bypass provides a safe, dedicated path to keep critical equipment powered while you service or replace the PDU. This capability minimizes downtime during maintenance by isolating the PDU module and routing power through the bypass while loads remain energized.
• Q: How many devices can I power with this PDU?
  A: The Eaton Basic Rack PDU offers six NEMA 5-15R outlets, allowing you to distribute power to multiple rack-mounted devices within the unit’s 1U footprint. Be sure to balance loads so no single outlet or output path is overloaded.
• Q: Is this PDU compatible with all UPS brands?
  A: The PDU is designed for close mounting to a UPS and uses a standard NEMA 5-15P inlet with six NEMA 5-15R outlets. It is suitable for use with compatible UPS systems and standard IT equipment that accepts NEMA 5-15 connections. Always verify compatibility with your specific UPS model and power requirements.
• Q: What environments are ideal for this PDU?
  A: This compact, 1U PDU is well-suited for data centers, server rooms, edge deployments, and telecommunications closets where space efficiency and reliable power distribution are critical. It’s designed to simplify power management in racks with limited space while supporting a broad range of devices.
• Q: Can I mix this PDU with other Eaton FlexPDU configurations?
  A: Yes. The FlexPDU family is designed to provide flexibility for varied power distribution needs. The Basic Rack PDU with HotSwap MBP can be integrated with other Eaton PDU configurations to create a power distribution strategy that aligns with your rack architecture and uptime requirements.
