Eaton Tripp Lite Series 1.9-3.8kW Single-Phase Basic PDU — 14 Outlets, 16A Input, 1U Rack-Mount

Introducing a reliable, space-saving power distribution solution for modern IT environments. The Eaton Tripp Lite Series 1.9-3.8kW Single-Phase Basic PDU is designed to deliver clean, organized power to racks and enclosures, supporting 120-240V single-phase output with a total of 14 outlets. With 12 C13 receptacles and 2 C19 receptacles, this 1U rack-mount PDU accommodates a wide mix of servers, storage devices, switches, and networking gear. An IEC-320 C20 input inlet supports up to 16A, ensuring a robust feed from your power source or UPS. Built to endure demanding data-center conditions, this PDU features an all-metal housing, RoHS compliance, and a reassuring 5-year warranty. Whether upgrading a single rack or standardizing a row of enclosures, this basic PDU provides dependable power distribution that simplifies cabling, reduces clutter, and improves overall rack efficiency.

• Versatile voltage and outlet configuration: Supports 120-240V single-phase power with a total of 14 outlets — 12 C13 and 2 C19 — enabling a single PDU to power a diverse mix of IT equipment, from servers to storage arrays and network devices, while helping to balance loads across devices and outlets.
• Compact, rack-friendly design: The 1U form factor fits standard 19-inch racks, making it ideal for dense data centers, IT closets, and lab environments where space is at a premium. Its slim profile helps maintain airflow and tidy cable management behind gear cages.
• Durable construction and protection: An all-metal enclosure provides rugged protection in active data-center atmospheres; the PDU is RoHS compliant, and includes a circuit breaker to help guard connected equipment from overloads and electrical faults.
• Reliable power input for mission-critical loads: Equipped with an IEC-320 C20 inlet rated for 16A, this PDU accepts feed from compatible power sources or UPS outputs, supporting steady operation of critical devices even during brief power disturbances.
• Warranty and support you can trust: Part of the trusted Eaton Tripp Lite family, this basic PDU combines dependable performance with a 5-year warranty, giving IT teams confidence for ongoing service and long-term deployments.

Technical Details of Eaton Tripp Lite Series 1.9-3.8kW Single-Phase Basic PDU

• Output voltage: 120-240V (single-phase)
• Outlets: 14 total (12 x C13, 2 x C19)
• Input: IEC-320 C20 inlet, 16A
• Form factor: 1U rack-mount
• Enclosure: All-metal housing
• Compliance: RoHS compliant
• Circuit protection: Built-in circuit breaker
• Warranty: 5-year limited warranty
• Series: Eaton Tripp Lite

How to install Eaton Tripp Lite Series 1.9-3.8kW Single-Phase Basic PDU

Follow these steps to install and deploy this PDU in a rack environment quickly and safely:

• Prepare the rack: Verify that your rack is a standard 19-inch enclosure with at least 1U of vertical space and adequate clearance for cable management and cooling. Ensure you have a suitable power source capable of delivering up to 16A.
• Mount the PDU: Use the included mounting hardware to secure the PDU in the desired 1U slot. Align the chassis with the rack rails, tighten fasteners securely, and confirm the PDU sits firmly without any wobble.
• Connect the input: Attach the IEC-320 C20 inlet to a compatible power source or UPS output rated for 16A. Route the power cord neatly to avoid interference with airflow or other equipment.
• Distribute loads: Connect devices to the 14 outlets (12 C13, 2 C19) according to your power plan. Distribute high-draw equipment across multiple outlets when possible to prevent overloading a single circuit.
• Test operation: Power on connected equipment, verify that outlets are delivering voltage within the expected 120-240V range, and confirm that the PDU’s protection features remain operational. Document the setup for maintenance and future capacity planning.

Frequently asked questions

Q: What voltages does this PDU support?

A: The PDU supports single-phase 120-240V output, suitable for most data centers, servers, and network equipment in diverse regions.

Q: How many outlets does it have and what types are included?

A: It provides 14 outlets in total: 12 C13 receptacles for standard IT devices and 2 C19 receptacles for higher-power equipment, enabling flexible distribution for mixed workloads.

Q: What is the input connection?

A: The unit uses an IEC-320 C20 inlet rated for 16A input, designed to connect to compatible power sources or UPS outputs.

Q: Is the PDU RoHS compliant and is there a warranty?

A: Yes. The enclosure is RoHS compliant, and the PDU is covered by a 5-year limited warranty for long-term reliability.

Q: Does it include any protection features?

A: The PDU includes an integrated circuit breaker to help protect connected devices from overloads and electrical faults, contributing to safer operation in busy racks.

Q: Is this PDU suitable for 1U rack installations with dense cabling?

A: Yes. Its 1U footprint and balanced outlet configuration support efficient cable management and airflow, making it a solid choice for space-constrained racks and high-density deployments.
