Eaton Tripp Lite Series 100Gb/120Gb Pass-Through Cassette - (x12) 24-Fiber MTP/MPO ( Female )

Tripp Lite by EatonSKU: 4195722

Price:
Sale price$347.61

Description

Eaton Tripp Lite Series 100Gb/120Gb Pass-Through Cassette - (x12) 24-Fiber MTP/MPO (Female)

Designed for ultra-high-density fiber deployments, the Eaton Tripp Lite N484-12M24 pass-through cassette delivers streamlined 100Gb and 120Gb connectivity in a compact, scalable form factor. Featuring twelve 24-fiber MTP/MPO female connections, this cassette is purpose-built to maximize port density in data centers, network closets, and enterprise backbones. When paired with Tripp Lite’s N484 chassis, it provides a clean, predictable path for multi-lane optical links, enabling quick upgrades and simplified maintenance without sacrificing performance or reliability.

  • Ultra-high density 24-fiber MTP/MPO pass-through per cassette: Each N484-12M24 cassette consolidates 12 individual 24-fiber MTP/MPO channels, delivering a dense, scalable solution ideal for 100Gb/120Gb Ethernet uplinks and future-proof data-center growth. This design reduces footprint in the rack while preserving full channel count for parallel multi-lane architectures.
  • 100Gb/120Gb ready for next-gen networking: Engineered to support high-speed interconnects, the cassette enables efficient aggregation and distribution of 100G and 120G traffic within a modular chassis environment. This makes it an excellent choice for modern data centers migrating to PCIe-based fabrics or high-bandwidth storage networks.
  • Female MTP/MPO connectors for reliable performance: The unit employs female 24-fiber MTP/MPO interfaces, engineered for robust signal integrity across parallel optic channels. Precision alignment and premium termination help minimize insertion loss and back reflection, which are critical for maintaining link reliability at multi-lane speeds.
  • Chassis-compatible and scalable deployment: Specifically designed for Tripp Lite N484-00U and N484-01U chassis, the N484-12M24 supports flexible configurations—up to four cassettes per N484-01U, or one cassette per N484-00U. This scalability makes it easy to tailor fiber density to current needs while preserving headroom for future capacity expansion.
  • Guaranteed compatibility within the Tripp Lite ecosystem: The cassette is engineered to work seamlessly with the recommended N484 chassis and associated cabling, delivering predictable performance and simplified procurement. By staying within the Tripp Lite/Eaton ecosystem, operators benefit from cohesive warranty coverage, streamlined service, and consistent component specifications across the network fabric.

Technical Details of Eaton Tripp Lite N484-12M24

  • Model: N484-12M24 Pass-Through Cassette
  • Type: High-density pass-through cassette for fiber networks
  • Connectivity: 12 x 24-fiber MTP/MPO (Female) connectors
  • Fiber configuration: 24-fiber MTP/MPO channels designed for parallel multi-lane links
  • Chassis compatibility: Designed for use with N484-00U and N484-01U chassis
  • Chassis capacity: Up to 4 cassettes in an N484-01U, or 1 cassette in an N484-00U
  • Applications: Suitable for 100Gb/120Gb Ethernet uplinks, multi-lane data center interconnects, and high-density fiber deployments
  • Connectors: Female MTP/MPO 24-fiber interfaces (12 channels per cassette)
  • Color/finish: Standard Tripp Lite housing compatible with other N484 accessories

How to install Eaton Tripp Lite N484-12M24

  • Prepare the site: Power down equipment per your data center protocol, and ground yourself to prevent electrostatic discharge. Verify that the N484 chassis is properly mounted and that there is adequate space for cable routing and slack management.
  • Open the chassis bay: Access the appropriate bay in the N484-00U or N484-01U chassis and remove any blank panel or dust cover to expose the installation slot.
  • Insert the cassette: Align the N484-12M24 cassette with the bay rails and slide it into place until it seats firmly. Ensure that the connectors are fully mated and that the cassette is secured per the chassis design.
  • Connect trunk fibers: Attach the MTP/MPO trunk cables to the corresponding female connectors on the cassette. Route the fibers to maintain proper bend radii, using cable organizers or ties to prevent strain and tangling.
  • Manage routing and labeling: Label each MTP/MPO channel for easy identification (e.g., channel 1 through 12) and route cables to patch panels or switches as required by your network design. Keep fiber paths clean, avoiding excessive tension or sharp bends.
  • Test and validate: After installation, perform continuity and insertion-loss tests for each channel using appropriate fiber test equipment. Verify that 100Gb/120Gb links initialize correctly and that there is no excessive attenuation across any channel.
  • Close and document: Reinstall any covers or blank panels, secure the cabling, and update your network documentation to reflect the new cassette addition and channel mappings.

Frequently asked questions

  • What is the N484-12M24 designed for?

    The N484-12M24 is a high-density pass-through cassette with twelve 24-fiber MTP/MPO female interfaces. It’s designed to support parallel 100Gb/120Gb Ethernet uplinks and scalable fiber distributions inside Tripp Lite’s N484 chassis framework.

  • How many cassettes can be installed in each chassis?

    In an N484-01U chassis, you can install up to four cassettes. In an N484-00U enclosure, you can install one cassette per unit. This enables flexible, modular expansion as your fiber network grows.

  • Are cables or connectors included with the cassette?

    Typically, the cassette ships as a component of the system and does not include trunk cables or patch cables. See your supplier or product listing for exact inclusions and recommended accessory options.

  • What speed and protocol compatibility does this cassette support?

    Designed for high-bandwidth deployments, the cassette supports 100Gb and 120Gb data paths via parallel 24-fiber MTP/MPO channels. It is intended for data-center fabric applications requiring multi-lane optical interconnects.

  • Is this compatible with non-Tripp Lite equipment?

    While built for seamless integration with Tripp Lite N484 chassis, always verify compatibility with your network equipment and fiber cabling. Using approved chassis and cabling ensures reliable performance and preserves warranty terms.
