Eaton Tripp Lite 1x4 HDMI over Cat6 Splitter for Medical Applications — 4K 60 Hz, HDR, 4:4:4, PoC, 230 ft

The Eaton Tripp Lite B127M-004-H delivers reliable, hospital-grade HDMI distribution from a single source to four displays over standard Cat6 cabling. Engineered for demanding medical environments, this 1x4 HDMI over Cat6 splitter supports true 4K video at 60 Hz with HDR and 4:4:4 chroma, ensuring crisp, color-accurate medical imaging across multiple monitors. When paired with the B127M-100-H receiver (sold separately), it extends high-quality video up to 230 feet (70 meters) to patient rooms, exam suites, operating rooms, and other clinical spaces while meeting stringent procurement requirements with TAA compliance.

• 4K at 60 Hz with HDR and 4:4:4 delivers vivid, life-like medical imagery with accurate color fidelity and detail essential for diagnostics and precision workflows.
• 1x4 HDMI distribution over Cat6 enables a single source to drive up to four displays or monitors, simplifying room layouts and reducing cable clutter in clinical settings.
• Extended reach up to 230 ft (70 m) over standard Cat6 cabling ensures flexible installation across hospital corridors, clinics, and patient care areas without sacrificing signal integrity.
• PoC (Power over Cable) design reduces the need for multiple power adapters along the installation path, supporting cleaner, safer, and easier deployments in medical facilities.
• Medical-environment readiness with hospital-grade design and TAA compliance makes it suitable for hospitals, clinics, and physician offices, with compatibility for the B127M-100-H receiver to complete the system.

Technical Details of Eaton Tripp Lite Series 1x4 HDMI over Cat6 Splitter for Medical Applications

• Model: B127M-004-H
• Receiver compatibility: B127M-100-H (sold separately)
• Video performance: 4K resolution at 60 Hz; HDR; 4:4:4 chroma sampling
• Transmission distance: Up to 230 ft (70 m) over Cat6
• Power design: PoC (Power over Cable) capable
• Application: Designed for medical environments (hospitals, clinics, physicians' offices)
• Compliance: TAA compliant

How to install Eaton Tripp Lite Series 1x4 HDMI over Cat6 Splitter for Medical Applications

To deploy this HDMI over Cat6 splitter in a healthcare setting, follow these steps:

Step 1: Connect your HDMI source (such as a medical imaging device or computer) to the B127M-004-H input port.

Step 2: Run up to four Cat6 cables from the B127M-004-H outputs to the B127M-100-H receivers placed near each display in the facility.

Step 3: Ensure the Cat6 cabling complies with standard Ethernet cabling guidelines to support 4K60 HDR with 4:4:4 picture quality.

Step 4: If using PoC, verify that the receivers are powered via the Cat6 link where applicable; otherwise connect any required local power per your installation plan.

Step 5: Verify each connected display shows the source content with the expected 4K60 HDR and color accuracy; adjust any display-specific settings if needed to maintain consistent imaging across rooms.

Frequently asked questions

• Q: What is the maximum distance between the transmitter and receivers? A: Up to 230 ft (70 m) over Cat6 cabling.
• Q: Does this require external power supplies? A: It uses PoC (Power over Cable); external power may be required only for certain installation configurations or receivers, depending on the setup.
• Q: Is this suitable for medical environments? A: Yes. It is designed for medical applications and is TAA compliant, making it appropriate for hospitals, clinics, and physician offices.
• Q: Which receiver should be paired with the transmitter? A: Pair with the B127M-100-H receiver (sold separately).
• Q: What video formats are supported? A: 4K at 60 Hz with HDR and 4:4:4 chroma sampling.
