Eaton Tripp Lite 3.8kW 1U Basic PDU for 208/240V — 14 Outlets (12 C13, 2 C19), NEMA L6-20P, 15 ft Cord

Meet the Eaton Tripp Lite Series 3.8kW Single-Phase Basic PDU, a compact yet essential power distribution unit designed for dense rack environments. Delivering 20A at 208/240V, this PDU provides reliable, scalable power to servers, switches, storage, and other critical IT gear housed in racks, network closets, and data centers. With 14 outlets (12 C13 and 2 C19) and a robust 15-foot cord fed by a NEMA L6-20P input, it simplifies cabling and reduces clutter. The detachable mounting flanges enable flexible installation in 1U horizontal or 0U vertical configurations, so you can tailor the setup to your specific rack geometry. Built to endure the rigors of data-center operation, this PDU optimizes space, improves cable management, and keeps uptime steady in demanding environments.

• High-capacity power distribution for rack IT gear: 3.8 kW total load capacity with 20A at 208/240V ensures reliable distribution to a mix of devices, including servers, switches, storage, and other rack-mounted equipment. The 14 outlets (12 C13 and 2 C19) provide ample connectivity for multi-device deployments while keeping individual outlets accessible and organized.
• Flexible input and long cord for adaptable deployment: Features a NEMA L6-20P input and a generous 15 ft (4.57 m) cord, enabling flexible routing around crowded racks and through data-center aisles. The extended cord length helps reach distant power sources without forcing awkward cable arrangements.
• Versatile mounting options for any rack layout: Detachable mounting flanges support both 1U horizontal installation and 0U vertical mounting, giving you the freedom to configure the PDU to your specific rack footprint. This flexibility simplifies installation in varied rack environments and improves airflow and cable management around critical gear.
• Durable, space-efficient design for data centers: Built in a compact 1U form factor with a sturdy enclosure, this Basic PDU minimizes space consumption in crowded racks while delivering dependable power distribution. Its rugged construction is designed to withstand the vibration and heat typical of data-center cabinets, helping to maximize uptime and reduce maintenance needs.
• Ideal for data centers, network closets, and server rooms: A practical choice for IT environments that require scalable, straightforward power distribution with minimal fuss. Whether updating a small server cabinet or outfitting a dense rack with multiple devices, this PDU supports clean cable management and streamlined power delivery for efficient operations.

Technical Details of Eaton Tripp Lite Series 3.8kW Single-Phase 208/240V Basic PDU

• Model / Series: Tripp Lite Basic PDU, 3.8 kW, single-phase, 208/240V
• Power capacity: 3.8 kW total load capability; 20A max at 208/240V
• Outlets: 14 total — 12 x C13, 2 x C19
• Input plug: NEMA L6-20P
• Cord length: 15 ft (4.57 m)
• Rack compatibility: 1U rack-mount with detachable mounting flanges for 1U horizontal or 0U vertical installation
• Enclosure: Durable, compact 1U design optimized for dense rack environments
• SKU / reference: PDUH20HVL6

How to install Eaton Tripp Lite Series 3.8kW Basic PDU

• 1) Plan installation orientation: decide between 1U horizontal mounting or 0U vertical mounting based on your rack layout and airflow considerations. Use the detachable mounting flanges to configure the PDU accordingly.
• 2) Prepare the rack: ensure rails are properly aligned, secure, and capable of supporting the PDU’s weight and loaded devices. Clear the area around the rack for safe cord routing.
• 3) Attach the PDU to the rack: mount the unit at the planned height, level it, and tighten mounting screws until secure. Verify that there is clearance for plug-in outlets and cord management.
• 4) Route and connect the power feed: connect the 15 ft cord to a suitable 208/240V power source using the NEMA L6-20P input. Keep the cord routed away from hot components and hot air exhaust to maintain efficiency and safety.
• 5) Connect devices to outlets: distribute IT equipment across the 14 outlets (12 C13, 2 C19) to balance loads. Avoid overloading any single outlet and maintain a neat, labeled cabling layout for easy maintenance.
• 6) Power up and verify: once connected, power on the rack devices and confirm each device powers up normally. Check for any unusual heat or alert indicators and adjust cable management as needed to preserve airflow.

Frequently asked questions

• What outlets are available on this PDU? It provides 14 outlets: 12 C13 and 2 C19, suitable for a mix of server, switch, and storage devices commonly found in data centers and server rooms.
• What is the input plug type? The unit uses a NEMA L6-20P input plug designed for 208/240V power distribution with a 20A circuit rating.
• How long is the power cord? The PDU ships with a 15 ft (4.57 m) power cord, offering flexible routing options in medium to large rack layouts.
• What rack configurations does it support? Detachable mounting flanges enable 1U horizontal installation or 0U vertical installation, allowing you to tailor the PDU to your rack’s space and airflow needs.
• Where is this PDU best used? It is well-suited for data centers, network closets, server rooms, and other IT environments requiring reliable, scalable power distribution in a compact 1U form factor.
