Eaton Tripp Lite Series 3.8kW Single-Phase Dual-Circuit 120V Basic PDU

The Eaton Tripp Lite Series 3.8kW Single-Phase Dual-Circuit 120V Basic PDU is a rugged, high-capacity power distribution solution built to support demanding networking, telecom, security, audio/video, and sound reinforcement deployments. With dual-circuit 120V inputs and a robust 3.8 kW capacity, this compact 0U PDU delivers reliable power distribution to a wide range of equipment while maximizing rack space efficiency. It’s engineered for fast deployment in data centers, labs, and professional AV environments where clean, dependable power across multiple devices is essential.

• High-capacity, single-phase distribution: Supports up to 3.8 kW of load, making it ideal for dense equipment racks and multi-device deployments in IT, telecom, security, and AV setups.
• Versatile outlets and dual inputs: 40 x NEMA 5-15/20R outlets paired with dual inputs (NEMA L5-20P and NEMA 5-20P) to accommodate diverse power sources and maximize outlet availability.
• Long reach, ready for deployment: Includes 10 ft (3.05 m) cords to give you flexible placement options within the rack or equipment room, reducing the need for additional extension cabling.
• Space-saving 0U form factor: Engineered to sit unobtrusively in a rack or equipment area, preserving rack space for active equipment while delivering consolidated power distribution.
• Ideal for multiple applications: Perfect for IT networks, security systems, telecom installations, professional audio/video setups, and sound reinforcement environments that require organized, reliable power distribution.

Technical Details of Eaton Tripp Lite Series 3.8kW Single-Phase Dual-Circuit 120V Basic PDU

• Power rating: 3.8 kW
• Voltage: 120V
• Phase: Single-Phase
• Circuit configuration: Dual-Circuit
• Outlet count and type: 40 x NEMA 5-15/20R outlets
• Input connectors: NEMA L5-20P and NEMA 5-20P
• Cord length: 10 ft (3.05 m)
• Mounting: 0U form factor for rack or equipment-room deployment

how to install Eaton Tripp Lite Series 3.8kW Single-Phase Dual-Circuit 120V Basic PDU

• Plan the installation by mapping the load to the two input circuits and distributing devices across the 40 outlets to avoid overloading a single circuit.
• Power down equipment and ensure the installation environment complies with 120V single-phase wiring requirements.
• Position the PDU in a suitable rack space or equipment area that supports 0U form factors, ensuring accessibility to all outlets and inputs.
• Connect the PDU inputs to appropriate power sources using the L5-20P and 5-20P connectors as required by your facility’s electrical configuration.
• Route and organize power cords to the 40 NEMA 5-15/20R outlets, then power on the PDU and verify each outlet is delivering power to connected devices.

Frequently asked questions

• Q: What devices is this PDU designed for? A: It supports networking, telecom, security, AV, and sound reinforcement equipment that require reliable, centralized power distribution.
• Q: How many outlets does it have and what outlet type? A: It provides 40 x NEMA 5-15/20R outlets for versatile device connections.
• Q: What is the length of the power cords? A: The PDU includes 10 ft (3.05 m) cords for flexible installation.
• Q: What are the input connectors? A: Dual inputs with NEMA L5-20P and NEMA 5-20P to accommodate different power sources.
• Q: What is the overall power capacity and voltage? A: The unit handles up to 3.8 kW at 120V in a single-phase configuration.
• Q: Is this PDU rack-mountable? A: Yes, it features a 0U form factor designed to save rack space while providing centralized power distribution.
