Electro-Voice ELX200-10 2-Way Wall Mountable Speaker - 300 W RMS - White

Designed for professional installations and demanding live environments, the Electro-Voice ELX200-10 2-Way Wall Mountable Speaker in White delivers clear, powerful sound with reliable durability. This compact, high-output system is engineered to perform in venues such as clubs, houses of worship, theaters, corporate spaces, and install settings where space is at a premium. The ELX200-10 combines a true 2-way design with a high-frequency titanium compression driver and a robust 10-inch woofer to deliver crisp vocals, detailed instruments, and tight bass with minimal distortion at high output. With a peak power rating of 1200 W and 127 dB peak SPL, this speaker offers ample headroom for loud environments while maintaining clean, transparent sound across the entire frequency range. The enclosure is finished in white, making it suitable for discreet installations that blend into interiors or architectural decor. Beyond performance, Electro-Voice emphasizes reliability with extensive abuse and endurance testing, exceeding typical industry practices by more than four times. This emphasis on durability translates to long-term consistency, reduced maintenance, and a lower total cost of ownership in busy install settings. Whether mounted high on a wall for distributed sound or used as a dependable stage monitor, the ELX200-10 is engineered to deliver dependable, sonically accurate results under demanding conditions.

• 2-way design with a 1.4 inch DH-1C titanium compression driver (1 inch exit) delivering extended, transparent high-frequency response for vocals, cymbals, and delicate instrument detail. The titanium diaphragm provides stiffness and speed, minimizing distortion at elevated sound pressure levels and preserving intelligibility in speech and performance contexts.
• EVS-10M woofer for tight, controlled bass and solid low-end output across the listening field. The woofer pairing is optimized to maintain punchy kick and musical warmth without overwhelming the midrange, making it suitable for both music and spoken-word applications.
• 300 W RMS continuous power handling with up to 1200 W peak power, delivering impressive headroom for live performances, DJ sets, corporate events, and multimedia presentations. This headroom helps maintain clarity during dynamic passages and ensures the system remains linear under demanding programs.
• 127 dB peak SPL enables projection in larger rooms or noisy environments without harshness or compression. Built to maintain fidelity at high output, it supports intelligible vocals and precise instrument definition even in challenging listening spaces.
• White finish and wall-mountable enclosure for discreet, flexible installation in fixed venues or portable setups. The design emphasizes aesthetics and room integration, allowing professional audio to blend with interiors while delivering dependable performance.

Technical Details of Electro-Voice ELX200-10 2-Way Wall Mountable Speaker - 300 W RMS - White

• Model: ELX200-10
• System Type: 2-way wall-mountable speaker
• Power Handling (RMS): 300 W
• Peak Power: 1200 W
• Maximum SPL: 127 dB peak
• HF Driver: 1.4 in DH-1C titanium compression driver (1" exit)
• LF Driver: EVS-10M woofer
• Enclosure Finish: White
• Durability & Testing: Over 500 hours of abuse and endurance testing (4x typical industry practices)
• Mounting: Wall-mountable design for versatile installation

how to install Electro-Voice ELX200-10 2-Way Wall Mountable Speaker

• 1. Plan placement: Choose a secure mounting location with solid wall support and consider reach, coverage, and avoidance of obstructions to ensure even sound distribution.
• 2. Prepare hardware: Use a certified, rated wall-mount bracket appropriate for the ELX200-10. Verify weight ratings and compatibility with your mounting surface before proceeding.
• 3. Attach mounting bracket: Mount the bracket to the wall using appropriate fasteners. Ensure the hardware is tightened securely and the bracket is level before mounting the speaker.
• 4. Mount the speaker: Align the enclosure with the bracket, attach securely, and adjust the tilt or angle as needed to achieve the desired coverage. Avoid over-tightening to prevent damage.
• 5. Connect and test: Connect the speaker to your amplifier or mixer with the proper cable, power on gradually, and perform a careful audio check at a low level. Verify balance and absence of rattles, then raise levels gradually to final operating volume.

Frequently asked questions

• Q: What makes the ELX200-10 different?

  A: The ELX200-10 is a high-output, 2-way wall-mountable speaker that combines a titanium DH-1C high-frequency driver with a robust EVS-10M woofer. It delivers strong output with clear highs and tight bass, optimized for install scenarios where space and sound quality matter. It also carries a strong reliability story, validated by extensive abuse and endurance testing well beyond typical industry practices.

• Q: What are the main performance specs?

  A: The system handles 300 W RMS with up to 1200 W peak, and it reaches a 127 dB peak SPL. This combination provides ample headroom for loud environments while preserving fidelity at high output levels. The device is designed as a 2-way system in a white, wall-mountable enclosure.

• Q: Is the ELX200-10 suitable for installed applications?

  A: Yes. It is specifically designed for wall-mount installations and professional-use environments such as venues, clubs, houses of worship, theaters, and corporate spaces, where discreet installation and reliable performance are important.

• Q: Do mounting hardware and accessories come with the speaker?

  A: The specifications emphasize wall-mount capability and compatible mounting practices, but do not specify included mounting hardware. Use standard, rated brackets appropriate for the speaker and installation location.

• Q: How should I position the ELX200-10 for best results?

  A: For optimal coverage, mount the speaker at an elevation that aligns with the audience’s ears and angle the cabinet to account for room acoustics and seating layout. Always ensure secure mounting and proper cable management to minimize vibrations and signal interference.
