Description
Extreme Networks 1000BASE-BX-U SFP
The Extreme Networks 1000BASE-BX-U SFP is a high-performance, hot-swappable optical transceiver designed to deliver reliable 1 Gbps connectivity within Extreme Networks IO modules and switches. Thoroughly tested and qualification-approved, this BX-U SFP ensures end-to-end optical compatibility and a seamless upgrade path for enterprise and data-center networks. Built for long-term reliability, it enables bi-directional single-fiber communications with industry-standard wavelengths, delivering consistent performance and simplified fiber management for organizations that demand uptime and scalability.
- Certified compatibility for Extreme Networks systems. This SFP is qualified to work with Extreme IO modules and switches, providing plug-and-play integration, predictable performance, and a streamlined warranty path across your Extreme Networks deployment.
- Bi-directional single-fiber 1000BASE-BX-U operation. Leverage a single optical fiber link to carry both transmit and receive signals using wavelength division multiplexing, typically 1310 nm for one direction and 1550 nm for the opposite direction, reducing fiber footprint and cabling complexity without compromising duplex data transmission.
- Compact, hot-swappable design for minimal downtime. The SFP form factor enables easy insertion and removal without powering down equipment, supporting hot-swapping in busy networks and enabling fast upgrades or replacements with minimal disruption.
- Standard LC connectors and broad ecosystem support. Featuring a standard LC connector, this transceiver is compatible with diverse fiber infrastructures and simplifies fiber patching, testing, and maintenance across existing data-center and campus deployments.
- Rigorous testing and end-to-end optical reliability. Extreme Networks optics undergo extensive qualification to ensure stable performance within IO modules and switches, giving you confidence in long-term operation and compatibility with other components in the optical path.
Technical Details of Extreme Networks 1000BASE-BX-U SFP
- Data rate: 1.0 Gbps compatible SFP transceiver for reliable Fast Ethernet-compatible uplink performance.
- Fiber type: Single-mode fiber (SMF) recommended to achieve proper bi-directional 1000BASE-BX-U operation over the standard BX wavelengths.
- Wavelengths: Bi-directional link using 1310 nm and 1550 nm wavelengths (BX-U configuration) to enable single-fiber duplex communication between devices.
- Connector: LC duplex optical connector (SFP standard) for straightforward field deployment and patching.
- Reach and link budgeting: The actual link distance depends on fiber quality, SNR, and optical budget; designed to support typical enterprise-scale deployments with flexibility across campus and data-center fabrics.
- Compatibility: Engineered to be compatible with Extreme Networks IO modules and switches, ensuring reliable operation within Extreme Network environments.
- Compliance and quality: Built to industry standards for optical transceivers, with quality controls aligned to support durable, long-life performance in enterprise deployments.
How to install Extreme Networks 1000BASE-BX-U SFP
Installing the Extreme Networks 1000BASE-BX-U SFP is a straightforward process designed to minimize downtime and maximize reliability. Follow these steps to ensure proper seating, alignment, and operation within your Extreme Networks environment:
- Power down the connected device only if recommended by your equipment guidelines, or verify that hot-swapping is supported for the specific IO module or switch model in use.
- Identify the correct SFP port on the Extreme Networks IO module or switch where the BX-U transceiver will be installed, and ensure the port is enabled in the device management interface if required.
- Carefully insert the SFP module into the SFP port with the connector oriented correctly. Push gently until it seats firmly and you hear a click indicating proper engagement.
- Connect the fiber patch cord using an LC-LC single-mode patch cable. Ensure the transmitter and receiver fiber ends align with the corresponding wavelengths and that the fiber is clean and free of contaminants before insertion.
- Power up the device (if powered down) and verify link status via the device management interface. Confirm that the SFP shows an active link and that the corresponding interfaces reflect the expected data rate and duplex settings.
Frequently asked questions
- Is the Extreme Networks 1000BASE-BX-U SFP compatible with non-Extreme devices? This transceiver is specifically qualified for Extreme Networks IO modules and switches. While it adheres to standard SFP form factors and BX-U signaling, compatibility with third-party equipment can vary and should be validated in your network environment before deployment.
- What type of fiber should I use? For BX-U SFP operation, single-mode fiber (SMF) is typically recommended to maximize reach and performance. Always refer to your specific Extreme Networks hardware documentation for guidance on fiber type and patching practices.
- What wavelengths are used by this transceiver? The BX-U configuration relies on bi-directional operation using complementary wavelengths, commonly 1310 nm and 1550 nm, to transmit and receive over a single fiber. The exact pairing depends on the opposing device's BX-D/BX-U implementation.
- How do I verify the SFP is functioning correctly? Use the device management interface to check link status, data rate, and SFP health indicators. Look for an active link, correct negotiation, and stable error statistics. If issues arise, re-seat the module and inspect the fiber patch for cleanliness.
- Is there a warranty or support for this transceiver? As part of Extreme Networks optics, the product typically benefits from vendor-specific warranty and support aligned with your procurement agreement. Contact your vendor representative for detailed warranty terms and support options.
