Extreme Networks 1200W Power Supply

The Extreme Networks 1200W Power Supply sets a new standard for reliability and flexibility in network infrastructure. Designed for seamless operation in data centers, campuses, and enterprise environments, this PSU supports both 120 V AC and 230 V AC inputs, enabling global deployment without compromise. Built to deliver a steady, uninterruptible source of power to Extreme Networks switches and appliances, it combines rugged construction, smart protection, and efficient performance to minimize downtime and operating costs. Whether you’re refreshing a fleet of devices, expanding capacity for growing traffic, or deploying in a mixed IT environment, this 1200W power supply provides the headroom and resilience your network demands while keeping energy usage in check. Its dual-voltage capability, robust protection features, and hot-swappable design make it a strategic asset for modern network deployments that prioritize uptime, scalability, and operational efficiency.

• Global compatibility with 120 V AC and 230 V AC inputs and 50/60 Hz operation for straightforward installation in any regional data center or office environment.
• High-capacity 1200W continuous power delivery to sustain peak traffic, support high-throughput switches, and provide ample headroom for future expansions without replacing the unit.
• Hot-swappable, modular design that enables maintenance or replacement without lengthy downtime, preserving service continuity for critical network services.
• Comprehensive protection features including overcurrent, overvoltage, short-circuit, and thermal safeguards to shield both the power supply and connected network devices from fault conditions.
• Compact, rack-mountable form factor with enterprise-grade reliability and clean cable management, designed for easy integration into standard 19-inch racks and chassis layouts.

Technical Details of Extreme Networks 1200W Power Supply

• Model: Extreme Networks 1200W Power Supply
• Input Voltage Range: 100–240 VAC
• Input Frequency: 50/60 Hz
• Power Rating: 1200 W
• Output: +12 V DC, up to 100 A (to support high-demand network equipment)
• Efficiency: High-efficiency power conversion designed to reduce energy waste and cooling requirements
• Protection Features: Overcurrent protection (OCP), Overvoltage protection (OVP), Short-Circuit protection (SCP), Thermal protection (OTP)
• Protection Indicators: LED status indicators and management interface alerts for quick fault isolation
• Protection Type: Redundant-ready and hot-swappable compatible with Extreme Networks chassis and backplanes
• Certifications: Industry safety and EMC certifications (CE/UL equivalent where applicable)
• Operating Temperature Range: 0°C to 50°C (industry-grade operating window for data center environments)
• Humidity Range: 5% to 95% non-condensing
• Mounting: 1U rack-mountable form factor compatible with standard 19-inch racks
• Form Factor Notes: Designed for easy insertion and removal, with secure latching mechanisms to prevent accidental disconnection
• Warranty and Service: Manufacturer-backed warranty with enterprise-level support options (based on regional policies)

How to Install Extreme Networks 1200W Power Supply

Installing the Extreme Networks 1200W Power Supply is designed to be straightforward, safe, and quick, so you can minimize downtime and keep critical services online. Before you begin, ensure you have access to the chassis and that the site meets the environmental requirements for electronics, including adequate airflow, temperature control, and dust prevention. If your organization requires, shut down non-essential systems and follow your standard change-management procedures to minimize impact on operations.

1) Prepare the chassis and workspace. Confirm that the chassis supports hot-swappable power supplies and that the rack has proper ventilation. Have anti-static wrist straps available and disconnect power from the adjacent equipment to avoid any inadvertent short circuits during installation.

2) Remove the existing unit (if replacing). If you are upgrading or performing maintenance, carefully release any retention latch or slider on the current PSU, and slide it out of the bay. Place the old unit on an anti-static surface until it is fully disconnected and stowed for disposal or recycling in accordance with your facility’s policies.

3) Align the new PSU with the bay. Take the new 1200W Power Supply and align its connectors and chassis guides with the bay’s edges. Ensure the unit sits evenly in the drive bay and that any hot-swap latches line up with the chassis slots.

4) Slide the PSU into the chassis and engage the latch. Push firmly until you hear or feel a secure latch engage. This ensures the power supply is seated and ready to deliver power to the backplane and attached devices. Do not force the unit; if it does not seat, remove it and reinsert with careful alignment.

5) Reconnect power and cables. Attach the appropriate AC power cords to the PSU’s input connections, ensuring cords are securely seated and routed to prevent strain. If your system uses a redundant power configuration, connect the second PSU into the other bay and configure the redundancy policy in the chassis management interface.

6) Power on and verify operation. Restore power to the chassis and monitor the front-panel indicators or management software for a healthy status. Look for a steady power-OK indication, absence of fault LEDs, and normal fans operation. Run a basic self-test if your device supports it and confirm that the connected devices power on correctly and report no error conditions.

7) Perform post-install validation. Confirm that the system recognizes the PSU, verify voltage rails at representative points, and check the system log for any alerts. Ensure that cooling airflow remains unobstructed and that cabling is neatly organized to avoid heat buildup and interference with fans or vents.

Tips for optimal operation: Maintain a clean, climate-controlled environment, avoid obstructing air intakes and exhausts, and schedule periodic inspections to check for dust buildup or loose connections. If you operate at extreme ambient temperatures or in environments with high humidity, consider additional environmental controls to sustain PSU longevity and performance. Keep spare units on-hand for rapid replacement to minimize downtime in mission-critical networks.

Frequently Asked Questions

• What input voltages does the Extreme Networks 1200W Power Supply support?
  The PSU is designed to operate with both 120 V AC and 230 V AC inputs, along with standard 50/60 Hz frequency, enabling global deployment without the need for multiple power supplies.
• Is this power supply hot-swappable?
  Yes. The design supports hot-swapping, allowing you to replace or upgrade the unit without shutting down the entire system in most Extreme Networks chassis configurations. Always follow proper maintenance procedures and health-check steps when performing hot-swaps.
• What protection features are included?
  The unit includes multiple protections to safeguard both the power supply and connected equipment, including overcurrent protection (OCP), overvoltage protection (OVP), short-circuit protection (SCP), and thermal protection (OTP). These protections help prevent damage during electrical faults or abnormal operating conditions.
• What is the typical output specification?
  The power supply delivers DC output at +12 V with a high-capacity rating suitable for powering demanding network hardware. Specific maximum current depends on the chassis design and load, but the unit is engineered to provide up to 1200 W of continuous power under normal operating conditions.
• How do I know this PSU is compatible with my Extreme Networks gear?
  Compatibility is established by chassis design and the PSU’s form factor. The 1200W Power Supply is configured for Extreme Networks hardware that supports hot-swappable, modular power options and 19-inch rack mounting. Always consult your device’s documentation or support resources to confirm compatibility and installation procedures for your specific model.
• What maintenance or warranty support is available?
  Most Extreme Networks power supplies come with a manufacturer’s warranty and access to enterprise-level support. Coverage and terms vary by region, so check the local policy for details on replacement timelines, spare-part availability, and service options.
