Extreme Networks 40GBASE-LR4 QSFP+ Transceiver

Unlock the full potential of your data center with the Extreme Networks 40GBASE-LR4 QSFP+ transceiver. Designed for long-range, high-density 40 Gigabit Ethernet deployments, this optical module blends industry-leading interoperability with robust performance. Ideal for spine-and-leaf architectures, data center interconnect, and enterprise networks, it delivers reliable, high-speed connectivity over single-mode fiber (SMF) using four parallel 10G lanes. Whether you’re upgrading an aging infrastructure or building a new backbone, this QSFP+ LR4 module offers the efficiency, scalability, and diagnostics that modern networks demand.

• High-performance 40G uplinks over SMF — The 40GBASE-LR4 QSFP+ module enables simultaneous transmission of four 10 Gbps channels, delivering a total aggregate bandwidth of 40 Gbps across single-mode fiber. This makes it an ideal choice for data center spines, core-to-core links, or inter-building connections, where distance and capacity are critical considerations.
• Long-range, single-mode fiber compatibility — Built for single-mode fiber, the LR4 interface supports longer reach compared with multi-mode solutions. This enables efficient interconnects across campus or between data centers, reducing the need for optical repeaters or extra amplification while preserving signal integrity over extended distances.
• IEEE 802.3ba 40GBASE-LR4 compliant — This QSFP+ transceiver adheres to the 40 Gigabit Ethernet standard, ensuring interoperability with a wide range of switch platforms and optical infrastructure that support LR4 optics. Absolute compatibility with IEEE specifications helps simplify upgrades and maintenance across mixed-vendor environments.
• Hot-swappable, dense, and easy to deploy — The QSFP+ form factor is designed for hot-swapping within compatible network devices, enabling seamless field upgrades and minimal downtime. Its compact footprint supports high port densities in data center switches, helping you maximize rack space and reduce cabling complexity.
• Built-in diagnostics and robust reliability — Many LR4 modules include Digital Diagnostics Monitoring (DDM) to monitor optical power, temperature, and other vital parameters. This capability supports proactive maintenance, rapid fault isolation, and consistent performance, giving network operators confidence in uptime and service levels.

Technical Details of Extreme Networks 40GBASE-LR4 QSFP+

• Data rate: 40 Gbps total aggregate capacity, via four 10 Gbps lanes (4x10G).
• Interface: QSFP+ pluggable transceiver designed for fiber optic networks.
• Fiber type: Single-mode fiber (SMF) for long-range operation.
• Wavelength: 1310 nm per lane, optimized for low dispersion over SMF links.
• Distance capability: Up to roughly 10 kilometers on standard SMF links, depending on fiber quality and link budget.
• Connector interface: MPO/MTP multi-fiber connector on the module side, with typical downstream use via MPO-to-LC or MPO-to-MTP patching approaches.
• Diagnostics: Supports Digital Diagnostics Monitoring (DDM) for real-time monitoring of optical power, temperature, and other critical parameters.
• Compatibility: Designed for IEEE 802.3ba 40GBASE-LR4, enabling broad interoperability with a wide range of switches and optical networks.

how to install Extreme Networks 40GBASE-LR4 QSFP+

Installing this transceiver is straightforward in a compatible network device. Begin by verifying that your switch or router port supports 40GBASE-LR4 optics and that your fiber infrastructure matches the LR4 requirements (single-mode fiber, appropriate fiber count, and correct connectors or harnesses). Power down the device only if required by your maintenance protocol, then carefully insert the QSFP+ module into an available 40G port with the correct orientation. The module should click into place and be securely seated; you may feel a gentle resistance as the latching mechanism engages. Connect the SMF trunk using the appropriate MPO-to-LC breakout harness or direct MPO-to-MPO patch cable, ensuring clean, dust-free connectors. Once the optical link is established, power up the device and monitor the port status. Use your management software to confirm link negotiation and verify data plane activation. If your deployment supports Digital Diagnostics Monitoring (DDM), you can actively monitor transmit power, receive power, and temperature to optimize link quality and predict maintenance windows. For best results, follow these additional guidelines: maintain clean connectors, minimize bending radius on fiber, and ensure that patch cords and harnesses are rated for single-mode, 1310 nm operation. If you plan to interconnect with multi-vendor equipment, consult the respective vendor’s interoperability guidelines to ensure compliance with LR4 optics and to address any firmware or driver considerations.

Frequently asked questions

• What is a 40GBASE-LR4 QSFP+ transceiver? A 40GBASE-LR4 QSFP+ transceiver is a high-density optical module that enables 40 Gigabit Ethernet over single-mode fiber by multiplexing four 10G lanes. It is designed for long-range connections and is commonly used in data center spine/core networks and inter-data center links.
• What type of fiber and connectors does it use? It uses single-mode fiber (SMF) and typically employs an MPO/MTP connector interface on the module side, with patching solutions such as MPO-to-LC harnesses for compatibility with LC-based patch panels and fiber routes.
• How far can it transmit? LR4 optics are optimized for long-range links, commonly supporting up to about 10 kilometers on standard SMF links, depending on fiber quality, connector losses, and link budget calculations.
• Is the module hot-swappable? Yes. The Extreme Networks 40GBASE-LR4 QSFP+ transceiver is designed to be hot-swapped in supported network devices, enabling maintenance and upgrades with minimal downtime.
• Does it provide diagnostics? Many LR4 transceivers include Digital Diagnostics Monitoring (DDM), which reports real-time optical power levels and temperature, helping with proactive monitoring and rapid troubleshooting.
• Is it compatible with non-Extreme Networks equipment? LR4 QSFP+ modules are designed to adhere to IEEE 802.3ba specifications and are typically compatible with a broad range of switches and optical network equipment that support LR4 optics. Always verify cross-brand interoperability with your vendor’s guidelines to ensure proper operation and support.
