Extreme Networks 920W Power Supply

Power a growing PoE ecosystem with confidence. The Extreme Networks 920W AC PoE Power Supply is engineered to support the PoE models of the 5420 switches, delivering robust, reliable power for a mix of IP phones, cameras, wireless access points, and other PoE devices. Designed for enterprise-grade uptime, this hot-swappable PSU minimizes maintenance windows and reduces operational downtime while maintaining optimal power delivery under load. Built to endure demanding data-center environments, it combines scalable power, smart protection, and easy integration into standard 19-inch rack deployments. When your network depends on continuous PoE power, this 920W supply ensures you stay online, productive, and secure.

• High-capacity 920W power delivery. The 920W rating provides ample headroom for dense PoE configurations across supported 5420 models, enabling you to power multiple IP phones, surveillance cameras, access points, and other PoE devices without compromising performance or reliability, even during peak demand. This power headroom helps you plan for future growth and reduces the need for frequent hardware upgrades as your network expands.
• Designed specifically for Extreme 5420 PoE models. This power supply is engineered to align with the unique power architecture of the Extreme Networks 5420 PoE switch family. Its integration with the switch’s onboard power management ensures balanced distribution, optimized efficiency, and seamless coordination with other PSU components in the chassis for stable operation under varying workloads.
• Hot-swappable and maintenance-friendly. Replace a failed unit without powering down the switch—a critical capability for high-availability environments. The hot-swappable design features a secure latch and straightforward seating in the PSU slot, enabling rapid field service and minimizing network downtime during maintenance or upgrade cycles.
• Smart safety, monitoring, and intuitive indicators. The PSU includes comprehensive protection and visibility, including over-current protection, short-circuit protection, and thermal monitoring. Embedded LEDs provide immediate health and status information, helping administrators quickly diagnose issues, plan replacements, and maintain optimal PoE performance across the fleet of devices connected to the 5420 switches.
• Rack-ready, enterprise-grade build for quiet, reliable operation. Engineered for data centers and network closets, the 920W power supply fits standard 19-inch racks, offering a compact footprint with dependable cooling and quiet operation. Its rugged construction supports continuous operation in challenging environments while preserving space for other critical networking gear.

Technical Details of Extreme Networks 920W Power Supply

• Product type: Power Supply for PoE switches
• Model: Extreme Networks 920W AC PoE Power Supply
• Target platform: Designed for PoE models in the Extreme Networks 5420 switch family
• Input voltage: 100–240 VAC, 50/60 Hz
• Output power: Up to 920 W PoE power delivered to supported devices
• PoE standards supported: IEEE 802.3af (PoE) and IEEE 802.3at (PoE+) capable per switch policy
• Redundancy and replacement: Hot-swappable and field-replaceable; suitable for high-availability configurations in compatible chassis
• Monitoring and management: Integrated status indicators; compatible with the switch’s management interface for real-time power monitoring
• Protection features: Over-current protection, short-circuit protection, and thermal protection to guard against faults
• Operating environment: 0°C to 40°C (32°F to 104°F); 5%–95% non-condensing humidity
• Certifications: UL/cUL, CE, FCC Class A for safe use in enterprise facilities
• Form factor: Hot-swappable, 19-inch rack-mountable design for easy integration with standard equipment racks

how to install Extreme Networks 920W Power Supply

• Prepare the workspace and confirm compatibility with your Extreme Networks 5420 PoE switches. Ensure you follow your organization’s electrical safety practices and ESD precautions before handling the PSU.
• Power down the switch if your deployment requires non-hot-swappable conditions or if your design calls for a controlled maintenance window. In compatible configurations, you may proceed with hot-swapping without powering down the entire system.
• Access the PSU slot in the switch chassis. Remove any existing module by releasing the latch and carefully pulling the unit straight out, taking care not to disturb other components.
• Insert the 920W AC PoE Power Supply into the slot, aligning connectors and seating the unit firmly until the latch engages. Ensure the PSU is firmly seated and secure before proceeding.
• Connect the AC power cord to the PSU and plug the other end into a grounded electrical outlet. Route cables to promote airflow and avoid obstruction near fans or vents.
• Power on the switch (or verify the PSU if power is already supplied). Check the PSU status indicators and the switch management interface to confirm healthy operation and proper power delivery to PoE devices.
• In systems with redundant PSUs, verify that both power supplies are recognized by the switch and that failover behavior is configured according to your HA design. Monitor the management console for alerts or fault conditions.

Frequently asked questions

• Q: What switches is this PSU compatible with? A: It is designed for Extreme Networks 5420 PoE models and compatible configurations within that product family, ensuring proper power delivery and management integration.
• Q: Can I replace the PSU while the switch is running? A: Yes. The 920W Power Supply is hot-swappable in supported chassis, allowing field replacement with minimal downtime when performed according to the manufacturer’s guidelines.
• Q: How do I verify that the PSU is functioning correctly? A: Use the switch management interface to monitor power supply status and read the health indicators on the PSU itself. Look for healthy LEDs and absence of fault warnings.
• Q: What safety standards does this PSU meet? A: The unit carries UL/cUL, CE, and FCC Class A certifications, indicating compliance with widely adopted safety and electromagnetic compatibility requirements for enterprise environments.
• Q: How much PoE power can I expect per port? A: The PSU delivers up to 920W for PoE devices across compatible 5420 models. Per-port power availability depends on the specific switch configuration, active devices, and the total power budget allocated by the switch’s power management settings.
