ExtremeNetworks ExtremeSwitching 5420M Ethernet Switch

Engineered for enterprise campuses, data centers, and edge deployments, the ExtremeSwitching 5420M delivers dense 48-port PoE-enabled performance with scalable uplinks, powerful security features, and cloud-managed simplicity. This switch is built to handle high-demand devices—from IP cameras and wireless access points to power-hungry IoT endpoints—while providing flexible expansion options through unpopulated SFP28 uplinks, stacking, and modular power. With MACsec security, a fan module for reliable cooling, and a 1-year XIQ Pilot cloud subscription, the 5420M is designed to simplify network operations and accelerate deployment of high-bandwidth, secure, and energy-efficient networks.

• 48 x 10/100/1000BASE-T ports with full duplex and support for 802.3bt PoE (PoE++, up to 90W per port) to power high-demand devices such as high-end cameras, thin clients, and IP phones, while preserving network performance.
• Flexible uplink and stacking architecture: 4 unpopulated SFP28 10/25G uplink options plus 2 stacking/SFP-DD ports, enabling scalable bandwidth growth, simplified expansion, and resilient, multi-switch topologies for campus or data-center edge environments.
• Security and reliability at the edge: MACsec capability to encrypt traffic between switches and endpoints, combined with a fan module for dependable cooling and two unpopulated modular PSU slots for redundant power configurations—ideal for 24/7 operations.
• Cloud-driven management and analytics: includes a 1-year XIQ Pilot cloud subscription for centralized policy, automation, visibility, and simplified firmware updates, helping IT teams reduce operational overhead and accelerate rollout across distributed networks.
• Performance, simplicity, and scalability: designed for stacking-enabled deployments, the 5420M delivers consistent throughput, low latency, and simplified maintenance across growing networks, making it suitable for enterprise campuses, branch offices, and edge data centers where reliable PoE power and fast uplinks matter most.

Technical Details of ExtremeSwitching 5420M

• Model: ExtremeSwitching 5420M
• Ports: 48 x 10/100/1000BASE-T RJ-45 ports with FDX/HDX support
• PoE: 802.3bt PoE++ up to 90W per PoE port (PoE-capable ports provide power to compatible devices)
• Uplink/Uplink Options: 4 x unpopulated SFP28 10/25G uplink bays
• Stacking: 2 x stacking/SFP-DD ports for fabric expansion and high-availability topologies
• Security: MACsec capable for encrypted layer-2 traffic between switches and endpoints
• Power: 2 x unpopulated modular PSU slots to support redundant power configurations
• Cooling: Includes a fan module to maintain reliable operation in dense deployments
• Management and Cloud: Includes 1-year XIQ Pilot cloud subscription for centralized management, policy automation, and network visibility

how to install ExtremeSwitching 5420M

• Prepare your rack space: mount the 5420M in a standard 19-inch rack, ensuring adequate clearance for air flow around the front and rear panels.
• Install fans and power modules: attach the included fan module if required for your environment and insert the optional PSU modules in the two PSU slots for redundancy. Ensure all power connections are secure and labeled.
• Connect network ports: plan the 48 copper ports for endpoint devices (PoE-enabled where needed) and reserve the 4 SFP28 uplink bays for future 10/25G connections to data center cores or aggregation switches.
• Configure stacking (optional): if you’re deploying multiple Extreme switches, connect stacking cables to the 2 stacking/SFP-DD ports to form a single logical switch, enabling centralized management and linear throughput growth.
• Plan PoE budgets: assess your PoE requirements for cameras, wireless access points, and other devices. Enable PoE on required ports and configure power budgets to prevent overloads during peak usage.
• Initial network setup: connect the 5420M to your management network via a management VLAN or out-of-band management, and access either the XIQ cloud interface or the local CLI to configure VLANs, QoS, and security policies.
• Security and firmware: update to the latest firmware through XIQ Pilot or the CLI, apply security policies (including MACsec configurations where needed), and verify that only authorized devices can access management interfaces.
• Testing and validation: perform connectivity checks, PoE output verification on powered devices, uplink reachability to core networks, and stacking integrity if you’ve enabled a stack. Validate routing or switching behavior as per your design.
• Documentation and backup: save your configuration, export a backup, and document port assignments, PoE budgets, and VLAN mappings for future reference and troubleshooting.

Frequently asked questions

• Does the ExtremeSwitching 5420M support PoE++ on all ports? The model supports 802.3bt PoE++ on PoE-enabled ports up to 90W per port, enabling power delivery to high-demand devices while maintaining network performance.
• How many uplinks does the 5420M have, and can they be populated later? The switch ships with 4 unpopulated SFP28 uplink bays for 10/25G connections, plus 2 stacking/SFP-DD ports for scalable expansion. You can populate these as your network grows.
• Is MACsec available on this switch? Yes, the 5420M is MACsec-capable, adding an important layer of security for encrypted data transmission between switches and endpoints.
• What about management and cloud integration? The model includes a 1-year XIQ Pilot cloud subscription, enabling centralized management, analytics, policy automation, and simplified firmware updates across your Extreme network.
• What power options are included? The base unit provides 2 unpopulated modular PSU slots for redundant power configurations. A separately installed PSU module is recommended for high-availability deployments.
• What environments is the 5420M best suited for? It is ideal for enterprise campuses, edge data centers, and high-density network environments that require PoE power delivery, scalable 10/25G uplinks, secure traffic with MACsec, and cloud-based management.
• How do I expand capacity if I need more ports or bandwidth? Use the 2 stacking/SFP-DD ports to form a stack with other Extreme switches and utilize the 4 SFP28 uplink bays to connect to core or distribution layers, enabling linear growth in bandwidth and simplified administration.
