Extreme Networks Power Module

The Extreme Networks Power Module is a high‑efficiency 550W AC power supply designed to sustain demanding network workloads in Summit switches. Engineered for reliability in data centers and enterprise deployments, this power module uses a back‑to‑front airflow orientation to optimize cooling in compact chassis, helping to maintain peak performance even under maximum load. Built to fit Extreme Networks’ Summit line, this module delivers robust power delivery, fast replacement in emergency scenarios, and a streamlined path to greater uptime for your critical network infrastructure.

• 550W AC power supply module engineered for Summit switches, delivering consistent, dependable power to support high‑throughput networking and mission‑critical operations.
• Back‑to‑front airflow design that aligns with common Summit chassis layouts, enhancing airflow management and reducing hot spots in dense data‑center environments.
• Hot‑swappable and field‑replaceable, enabling maintenance without lengthy downtime or complete system disruption, so your network stays online while you service it.
• Designed for compatibility with Extreme Networks Summit platforms, including X670‑series installations, offering a seamless fit within supported chassis and power architecture.
• Rugged, purpose‑built construction for continuous 24/7 operation, with strict adherence to industry standards to ensure reliability in demanding environments.

Technical Details of Extreme Networks Power Module

• Power rating: 550W AC input power supply module, designed to deliver stable voltage and current to Summit switches under load.
• Airflow orientation: Back‑to‑front airflow to suit chassis cooling strategies in Summit deployments.
• Compatibility: Specifically designed for Extreme Networks Summit switches and compatible X670‑based platforms within supported chassis configurations.
• Maintenance: Hot‑swappable design enables quick replacement with minimal disruption to network services.
• Construction and reliability: Built for data‑center environments with robust connectors and secure mounting to withstand rack‑mount conditions and continuous operation.

How to install Extreme Networks Power Module

• Power down the affected chassis or isolate the power module bay according to your data center’s safety and change‑control procedures.
• Open the module bay using the standard removal process for Summit chassis and carefully release the existing module if replacing an older unit.
• Align the new Extreme Networks Power Module with the chassis connectors, ensuring proper engagement of the power contacts and mechanical guides.
• Slide the module in firmly until it seats with a distinct click, then secure any retention screws or locking mechanisms as required by your chassis model.
• Restore power to the chassis, monitor the power module indicators, and verify that the system recognizes the module and reports normal operation through the management interface.

Frequently asked questions

• Q: What is the main function of the Extreme Networks Power Module? A: It provides a dedicated 550W AC power source for Summit switches, enabling reliable power delivery and supporting high‑availability configurations.
• Q: Is this power module hot‑swappable? A: Yes, it is designed for hot swapping to minimize downtime during maintenance and upgrades.
• Q: Is it compatible with all Summit switch models? A: The module is designed for Extreme Networks Summit switches and is suitable for supported X670‑based platforms within compatible chassis; always verify your chassis and SKU compatibility before purchase.
• Q: Can I use multiple power modules for redundancy? A: In supported chassis configurations, multiple power modules can provide redundancy and load sharing, helping ensure uninterrupted network operation.
• Q: How can I verify the module is operating correctly? A: Status indicators on the module and chassis, along with your network management tools, will report healthy operation and alert you to faults or anomalies.
