Extreme Networks Summit X460-G2 VIM-2x: Two-Port 10GbE SFP+ Expansion Module for Summit X460-G2

Elevate your data networking with the Extreme Networks Summit X460-G2 VIM-2x, a purpose-built SFP+ expansion module designed to extend the capabilities of the Summit X460-G2 family. This dual-port 10 Gigabit Ethernet (10GbE) expansion module delivers reliable, high-speed optical connectivity through two SFP+ ports, empowering data centers, campuses, and enterprise networks to scale bandwidth without replacing core switches. Built to integrate seamlessly with Extreme Networks’ Summit OS, the VIM-2x provides a flexible, future-ready solution for uplink optimization, server clustering, storage connectivity, and workload acceleration. As a compact and modular component, it simplifies network design by offering scalable growth paths, improved redundancy, and enhanced performance for virtualization, cloud-ready applications, and large-scale LAN environments. The VIM-2x is the single answer to your expansion needs, leveraging 10GBase-X technology to deliver robust, low-latency links that support today’s demanding workloads while preserving headroom for tomorrow’s traffic surges.

• Two high-speed SFP+ ports for scalable 10GbE uplinks — The VIM-2x provides two dedicated SFP+ interfaces, enabling flexible uplink and server connectivity. This empowers you to deploy direct 10GbE connections to storage arrays, virtualization hosts, or adjacent switches, optimizing traffic flows and reducing bottlenecks across critical workloads.
• Optical fiber and 10GBase-X support — Designed to work with standard 10GBASE-X optical transceivers, the VIM-2x delivers reliable fiber connectivity across campus and data center deployments. It also supports DAC (direct-attach copper) alternatives where appropriate, giving you choice and cost flexibility for short- to medium-length runs.
• Compact, modular design for seamless growth — As a VIM expansion module for the Summit X460-G2 series, the VIM-2x plugs into the chassis to extend capacity without requiring a full switch upgrade. Its streamlined form factor minimizes space usage while delivering meaningful bandwidth enhancements that scale with your network.
• Hot-swappable deployment with minimal downtime — The VIM-2x is engineered for modularity and serviceability. Install or replace the module with minimal disruption to ongoing operations, helping you maintain availability while expanding or upgrading your network fabric.
• Integrated with Summit OS for unified management — When paired with Extreme Networks’ Summit OS, the VIM-2x benefits from consistent management, monitoring, and policy enforcement. Configure SFP+ ports, implement QoS, and coordinate with other network elements using familiar workflows for a cohesive, reliable infrastructure.

Technical Details of Extreme Networks Summit X460-G2 VIM-2x

• Ports: 2 x SFP+ 10GBASE-X uplink ports for flexible optical connectivity
• Module type: Virtual Interface Module (VIM) expansion module compatible with Summit X460-G2 series
• Data rate: Up to 10 Gbps per port (up to 20 Gbps aggregate across both ports)
• Connectivity options: Optical fiber with 10GBASE-X transceivers; supports compatible DAC cables
• Interface compatibility: Designed for seamless integration with Summit OS-managed environments and Extreme Networks infrastructure

How to install Extreme Networks Summit X460-G2 VIM-2x

• Prepare for installation by powering down the device during a planned maintenance window and following proper electrostatic discharge (ESD) precautions.
• Identify an available VIM slot on the Summit X460-G2 chassis and verify compatibility with your current hardware and firmware version.
• Remove the slot cover if required, then align the VIM-2x module with the slot guides and insert it firmly into the chassis until the latch engages securely.
• Install any required SFP+ transceivers or DAC cables into the two ports on the VIM-2x, ensuring correct connector type and fiber orientation.
• Power the switch back on and access the management interface to confirm that the VIM-2x is detected. Check port status, LED indicators, and firmware recognition.
• In Summit OS, configure the two SFP+ ports as needed for your network design—assign VLANs, enable link aggregation if applicable, and apply QoS or security policies to optimize traffic flows.

Frequently asked questions

• Is the VIM-2x hot-swappable? Yes. The VIM-2x is designed for hot-swapping within a supported Summit X460-G2 environment, allowing maintenance and upgrades with minimal downtime when performed according to best practices and device firmware guidance.
• What connectivity does the VIM-2x provide? It provides two SFP+ ports capable of 10GBASE-X connections, suitable for uplinks to core switches, storage networks, or high-performance servers, depending on your topology and cabling choices.
• Which platforms are compatible? The VIM-2x is intended for Extreme Networks Summit X460-G2 switches. It works best within environments running compatible Summit OS firmware and supportive management tooling for expansion modules.
• Do I need specific transceivers? Use only compatible SFP+ transceivers or DAC cables recommended by Extreme Networks for optimal performance and interoperability. Mismatched or non-certified modules may affect link reliability or violate warranty terms.
• How should I configure the ports after installation? In Summit OS, assign the two SFP+ ports to the desired VLANs or trunks, configure link aggregation groups if needed, set port speeds to 10 Gbps, and apply any QoS, security, or routing policies required by your network design.
