Gefen DisplayPort Fiber Optic Pigtail Modules — DP Extension up to 1000 Meters

Experience true long-range DisplayPort performance with Gefen DisplayPort Fiber Optic Pigtail Modules. Engineered for professional AV installations, this high-bandwidth solution converts a DisplayPort signal into a single-strand multimode fiber link, enabling reliable extension across rooms, floors, or entire campuses. Featuring DPCP support, these pigtail modules deliver secure, interference-free transmission over fiber while preserving video fidelity, color accuracy, and refresh rates. Whether outfitting a conference center, control room, broadcast facility, or enterprise AV deployment, Gefen’s DP fiber optic pigtail extender provides a compact, scalable, and future-ready solution designed for demanding environments.

• Extend DisplayPort signals up to 3300 feet (1000 meters) over a single-strand 50/125 µm multimode fiber with SC-terminated connectors. This capability overcomes copper-distance limitations, enabling seamless installations across large venues or multi-room setups, while maintaining high bandwidth and pristine image quality. The pigtail module design integrates the DP transmitter and receiver interface with the fiber link in a compact package, reducing clutter and simplifying deployment.
• DPCP support ensures secure, protected DisplayPort content transmission across long distances. By leveraging fiber’s inherent robustness and shielding from electrical interference, these modules help maintain consistent performance in environments with high EMI or dynamic electrical activity, such as stadiums, control centers, and data-driven displays.
• Compatibility with widely used fiber infrastructure: uses 50/125 µm multimode OM2/OM3 fiber terminated with SC connectors. This standard fiber specification offers flexibility in sourcing patch cords and enables straightforward field maintenance and upgrades without specialized cables.
• High reliability with low signal loss: the fiber-optic path minimizes latency and attenuation, preserving color depth, frame rate, and overall DisplayPort fidelity across long runs. The single-strand fiber approach reduces potential points of failure and simplifies routing in complex installations.
• Effortless integration within Gefen ecosystems: designed for seamless pairing with Gefen DP fiber optic extenders, the pigtail modules provide a scalable path to expand installations as AV demands grow. Replaceable components and standardized connectors help maintain uptime in professional environments, while delivering a clean, professional installation aesthetic.

Technical Details of Gefen DisplayPort Fiber Optic Pigtail Modules

• Distance capability: Up to 3300 feet (1000 meters) on a single-strand multimode fiber
• Fiber type: 50/125 µm multimode fiber (OM2/OM3)
• Connector type: SC-terminated fiber connectors
• DisplayPort support: DP signal with DPCP (DisplayPort Content Protection) compatibility
• Module design: Pigtail-based DisplayPort fiber optic extender for streamlined installation

How to install Gefen DisplayPort Fiber Optic Pigtail Modules

• Plan your link length and verify that your environment can accommodate up to 1000 meters (3300 feet) of OM2/OM3 multimode fiber with SC terminations. Ensure you have the correct fiber patch cords and that end devices (DisplaySource and Display) are compatible with the Gefen DP extender system.
• Prepare the fiber path by routing a single-strand 50/125 µm multimode fiber between the transmitter and receiver locations. Ensure the fiber ends are clean and terminated with SC connectors compatible with the pigtail modules.
• Connect the Gefen DisplayPort source (DP output) to the transmitter side of the first pigtail module using a standard DisplayPort cable. Secure the connection and verify physical mounting for stability in its environment.
• Connect the fiber patch cord to the SC fiber connectors on the transmitter module and route it to the SC fiber input on the receiver module. Avoid sharp bends and protect the fiber from excessive tension or impact during installation.
• Connect the receiver module’s DisplayPort output to the display or destination device with a DisplayPort cable. Power on both the transmitter and receiver modules, then configure the DisplayPort output settings (resolution and refresh rate) to align with the capabilities of your source and display.
• Test the full path by powering up the system and verifying signal integrity. If necessary, adjust DP settings to optimize color, timing, and bandwidth. Use proper cable management to maintain reliability and a clean installation appearance.

Frequently asked questions

• Q: What is the maximum distance supported by Gefen DisplayPort Fiber Optic Pigtail Modules? A: The system supports up to 3300 feet (1000 meters) over a single-strand 50/125 µm multimode fiber (OM2/OM3) with SC termination.
• Q: What fiber type and connectors are required? A: The extension uses 50/125 µm multimode fiber (OM2/OM3) terminated with SC connectors. Ensure you source SC-terminated fiber patch cords and appropriate protection for the installation environment.
• Q: Does this solution support DPCP? A: Yes. The Gefen DisplayPort Fiber Optic Pigtail Modules include DPCP (DisplayPort Content Protection) support for secure content transmission over fiber.
• Q: Can I use this extension for 4K or high-refresh-rate DisplayPort signals? A: The modules are designed to extend DisplayPort signals over fiber with high fidelity. For specific resolutions and refresh rates, confirm compatibility with your DP source and display devices and ensure the fiber link bandwidth meets your requirements.
• Q: Do I need any special tools or training to install the pigtail modules? A: Installation is designed to be straightforward for professional AV technicians. You will typically need standard fiber handling tools (cleave and terminate SC connectors if installing new fiber), appropriate DisplayPort cables, and proper mounting hardware. Ensure power is supplied to the units as required by your Gefen extender setup.
