Hall 1 Channel HDBaseT Transmitter
The ECHO-1S Hall 1 Channel HDBaseT Transmitter is engineered to maximize the reach of a single HDMI 2.0 source by sending its signal to multiple distant displays with exceptional clarity. Designed for reliable long‑distance distribution, this transmitter leverages HDBaseT technology to extend a high‑definition signal from a single source to up to two remote locations. When paired with appropriate HDBaseT receivers, it delivers impressive performance for modern audiovisual setups, including business environments, classrooms, and venues where content must be viewed from multiple rooms. With support for 4K UHD at 60 Hz with 4:4:4 chroma on distances up to 70 meters and 1080p at up to 100 meters over a single CAT5e or CAT6 cable, the Hall 1 Channel Transmitter combines simplicity with the power of professional AV distribution.
- HDMI 2.0 source, dual-location distribution: The ECHO-1S transmits a single HDMI 2.0 input to two remote displays via HDBaseT, ensuring synchronized viewing across spaces. This makes it ideal for hallways, conference rooms, or classrooms where content must be shared in real time across multiple screens.
- 4K UHD performance over long runs: Supports HDMI resolutions up to 4K at 60 Hz with 4:4:4 chroma on cable runs up to 70 meters. For standard HD content, it extends up to 100 meters at 1080p, making it a versatile solution for large venues where cables cannot be placed close to displays.
- Reliable CAT5e/CAT6 extension: Uses a single Ethernet cable to carry both video and control signals, simplifying installation and reducing cable clutter. The transmitter works with compatible HDBaseT receivers to deliver robust, long‑distance signal integrity even in environments with potential interference.
- Plug‑and‑play simplicity with professional results: Designed for straightforward deployment, the system minimizes setup time. Connect your HDMI source to the transmitter, run a CAT5e/6 to the remote receivers, and connect each receiver to its display. The result is an easy, scalable solution that keeps content in sync across locations.
- Versatile AV distribution for modern spaces: Whether you’re delivering corporate presentations, digital signage, or educational content, the Hall 1 Channel Transmitter provides a clean, efficient way to extend your HDMI signal to two distant displays without compromising quality or reliability.
Technical Details of Hall 1 Channel HDBaseT Transmitter
- HDBaseT transmitter designed for a single HDMI 2.0 source
- Supports 4K UHD at 60 Hz with 4:4:4 chroma on distances up to 70 meters
- Supports 1080p at distances up to 100 meters over a single CAT5e or CAT6 cable
- Extends signal to up to two remote locations using compatible HDBaseT receivers
- Uses standard CAT5e/CAT6 Ethernet cabling to carry video, with a compact form suitable for AV racks or wall installations
How to Install Hall 1 Channel HDBaseT Transmitter
- Power down all equipment before connecting the transmitter and any receivers to avoid electrical issues during setup.
- Connect the HDMI output from your source device (Blu‑ray player, media PC, conference computer, etc.) to the HDMI input on the Hall 1 Channel Transmitter.
- Run a single CAT5e or CAT6 cable from the transmitter’s HDBaseT output to each HDBaseT receiver located at the remote displays. If you are distributing to two displays, you will typically use two receivers connected to the same transmitter via separate cables.
- Connect each receiver’s HDMI output to its corresponding display, ensuring that the displays are set to the correct HDMI input sources.
- Apply power to the transmitter and all receivers. If needed, configure EDID or display settings on your source to obtain the optimal 4K or 1080p presentation. Verify that both displays show synchronized content and adjust any jumpers, if provided by your receivers, to match your desired resolutions.
- Perform a quick test by playing a 4K60 4:4:4 video (or your best available source material) and confirm that both displays render the content in sharp detail. If color or scaling issues occur, recheck connections and ensure the CAT5e/6 runs are within supported distances and free from excessive interference.
