Hanwha Techwin PNO-A9081R 8 Megapixel Outdoor 4K Network Camera - Color - Bullet - White

The Hanwha Techwin PNO-A9081R is a premium outdoor 8-megapixel network camera engineered to deliver stunning 4K imagery in challenging environments. This color bullet camera blends a clean white exterior with rugged, industrial-grade performance, making it ideal for perimeter security, parking lots, campuses, retail storefronts, and municipal applications. With advanced compression options, a versatile varifocal lens, and a robust weatherproof and vandal-resistant design, the PNO-A9081R is built to provide reliable, high-quality surveillance 24/7. It captures crisp, life-like color video during the day and maintains strong performance at night thanks to integrated infrared illumination, ensuring you don’t miss critical details after dark. Its compact bullet form factor, combined with IP66/IP67 ingress protection and IK10 impact resistance, makes it adaptable for a wide range of installation scenarios—from poles to walls—without compromising safety or aesthetics.

• Stunning 8MP 4K Resolution — Capture ultra-high-definition video at 3840 x 2160 with smooth 30 frames per second, ensuring fine detail in wide-area scenes and close-up shots. The camera’s 4K output makes it easier to identify faces, license plates, and other important details, reducing ambiguity in security footage.
• Versatile 4.5–10 mm Varifocal Lens — A 4.50 mm to 10 mm varifocal lens provides 2.2x optical zoom, enabling precise framing and flexible field-of-view tuning. This adaptability helps you tailor the camera to different distances and perspectives, from entryways to expansive outdoor spaces.
• Advanced Video Codecs for Efficiency — Supports H.265, H.265 HP, H.264, H.264 MP, and MJPEG. These codecs optimize bandwidth and storage without sacrificing image quality, making remote viewing smoother and more reliable across varying network conditions.
• Rugged Outdoor Durability — Built to endure demanding outdoor environments with an IP66/IP67 rating for weather sealing against rain, dust, and immersion in water, plus IK10 vandal resistance for protection against tampering. This camera is designed for long-term, maintenance-friendly operation in exposure to the elements.
• Color Imaging with Strong Night Capabilities — Delivers vivid color imagery in daylight and reliable nighttime performance with integrated infrared illumination that reaches up to 98.43 feet (approximately 30 meters). This balance of color during the day and effective night vision helps ensure scene detail is preserved around the clock.

Technical Details of Hanwha Techwin PNO-A9081R

• Resolution: 3840 × 2160 (8MP) for true 4K imaging
• Image Sensor: CMOS sensor for high-sensitivity capture
• Optical System: 4.50–10.0 mm varifocal lens with 2.2x optical zoom
• Frame Rate: Up to 30 fps at full resolution for smooth motion
• Video Codecs: H.265, H.265 HP, H.264, H.264 MP, H.264
• Video Streaming: supports multiple streams with adaptable bitrates
• Infrared/Night Vision: 98.43 ft (30 m) infrared distance for low-light surveillance
• Day/Night Imaging: Color mode during the day with night functionality via IR illumination
• Ingress Protection: IP66, IP67 weather resistance for dust, rain, and immersion exposure
• Vandal Resistance: IK10 rated for impact protection against tampering
• Mounting: Pole mount capable with outdoor-ready mounting hardware
• Environment: Outdoor bullet camera designed to withstand harsh conditions

how to install Hanwha Techwin PNO-A9081R

• Plan and prepare the installation — Choose a stable mounting location with a clear line of sight to the area you need to monitor. Ensure access to power and network connectivity, or prepare a PoE-capable switch if supported by your network infrastructure. Verify weather conditions and set up a safe ladder or lift for overhead mounting if required.
• Mount the camera — Attach the PNO-A9081R to a pole or wall using the supplied hardware. Ensure the camera is oriented toward the intended field of view and secured properly to withstand wind and vibration. Tighten mounting screws until the camera is stable but not over-tightened.
• Configure network and power — Connect the camera to your network using an Ethernet cable. If the camera supports PoE, connect it to a PoE-enabled switch to supply power and data over a single cable. If not, provide the required power supply as specified by Hanwha Techwin documentation. Power up the device and wait for it to initialize.
• Access the camera interface — Use the default camera IP address or the discovery tool provided by your security system to locate the PNO-A9081R. Open the web interface or management software to begin configuration. Set the administrator password, configure IP settings (static or DHCP), and enable HTTPS for secure remote access.
• Tune image settings and performance — Adjust exposure, white balance, and sharpness for the camera’s environment. Configure the 4.5–10 mm varifocal lens for optimal framing, and set the desired resolution (4K) and frame rate (30 fps). Enable the H.265 or H.264 stream that best fits your network bandwidth. Calibrate IR illumination distance and angle to maximize night-time visibility while minimizing backlight or glare. Finally, test motion detection, alert rules, and recording schedules to ensure reliable coverage.
• Secure and maintain — Update firmware to the latest version from Hanwha Techwin’s repository, enable user permissions, and implement encryption for data in transit. Schedule routine maintenance checks to inspect mounting hardware, seals, and camera housings to sustain outdoor performance against corrosion and wear.

Frequently asked questions

• What is the maximum resolution of the Hanwha Techwin PNO-A9081R? The camera delivers up to 3840 × 2160 (4K) resolution for highly detailed surveillance footage.
• How far can the infrared night vision reach? The infrared illumination reaches up to 98.43 feet (approximately 30 meters), enabling clear grayscale imaging in low-light conditions.
• Is the camera vandal resistant and weatherproof? Yes. It is IK10 vandal resistant and rated IP66/IP67 for outdoor weather resistance, making it suitable for harsh environments.
• What video codecs does the camera support? It supports H.265, H.265 HP, H.264, H.264 MP, and MJPEG, providing flexible options for bandwidth management and compatibility with various recording systems.
• Can I adjust the lens framing after installation? Absolutely. The camera uses a 4.50–10 mm varifocal lens with 2.2x optical zoom, allowing precise framing adjustments to capture the desired area without re-mounting.
• What mounting options are available? The PNO-A9081R is designed for outdoor mounting on poles or walls, and the package includes hardware compatible with those installations. Ensure proper sealing and mounting torque to maintain weatherproof performance.
• How many streams are supported and can I customize resolutions? The camera supports multiple streams with configurable resolutions and bitrates to optimize storage and bandwidth across the network. Refer to your security software for stream customization options.
• Is the camera suitable for daylight and night-time surveillance? Yes. It provides color imaging in daylight and switches to IR-assisted grayscale imaging at night, maintaining visibility across lighting conditions.
