Hanwha Techwin SLA-5M7000Q - 7 mmf/1.6 Fixed Lens for M12-mount

Experience precision and reliability with the Hanwha Techwin SLA-5M7000Q fixed lens, engineered for M12-mount surveillance cameras. This high-performance 7mm focal-length lens delivers crisp 5MP imagery with exceptional low-light capability, making it ideal for indoor and outdoor surveillance where detail matters. With a compact form factor measuring approximately 1.4 inches in length and diameter, the SLA-5M7000Q blends seamlessly into tight camera housings while maintaining robust optical performance.

• Compact, space-saving design: A slim 1.4" length and 1.4" diameter fit a wide range of small, discreet camera housings without compromising image quality.
• Stellar low-light performance: Photographic clarity at 0.16 lux @ F1.6 ensures dependable color or black-and-white imaging even in dim environments.
• 5MP imaging with flexible options: Delivers sharp, high-resolution video suitable for face recognition, license plate capture, and detailed scene monitoring.
• Fixed focal length with premium optics: 7.0mm focal length provides balanced field of view for mid-range scenes, with selectable 3.7/4.6/7.0mm fixed-lens options in the 5MP family for different surveillance needs.
• Color or monochrome support: Available in color or B/W configurations to maximize contrast and detail under varying lighting conditions.

Technical Details of Hanwha Techwin SLA-5M7000Q

• Focal length: 7 mm
• Aperture: F/1.6
• Image format: 5 MP capable
• Mount: M12
• Physical dimensions: approximately 1.4" length and 1.4" diameter
• Illumination: 0.16 lux at F1.6
• Color options: Color and B/W (monochrome) variants available
• Compatibility: Designed for use with select 5MP surveillance cameras supporting M12 fixed lenses

How to install Hanwha Techwin SLA-5M7000Q

• Prepare your M12-mount camera or housing and confirm compatibility with 5MP lenses for the lens-to-sensor alignment.
• Remove the existing lens (if applicable) and clean the mounting area to ensure a pristine contact surface.
• Gently insert the SLA-5M7000Q into the M12 socket, ensuring the lens is oriented for the intended field of view and that any locking or securing ring is properly engaged.
• Secure the lens with the appropriate mount hardware, taking care not to overtighten and to avoid damage to the lens’ delicate optics.
• Connect power and check live feed to verify focus, framing, and image clarity. If needed, fine-tune the camera’s gain and exposure settings to optimize the 0.16 lux capability at F1.6.

Frequently asked questions

• Q: What are the available focal lengths for the 5MP lens family, and is the SLA-5M7000Q interchangeable with other fixed lenses?
• A: The SLA-5M7000Q offers a 7.0mm fixed focal length with an F/1.6 aperture and 5MP imaging. The 5MP family includes selectable fixed lenses at 3.7mm, 4.6mm, and 7.0mm to suit different surveillance distances and scene coverage. Replacement with other fixed lenses within the same family is possible where the camera supports it and proper alignment is maintained.
• Q: How does the low-light performance of this lens benefit surveillance applications?
• A: With a 0.16 lux rating at F1.6, the SLA-5M7000Q captures clearer details in dim lighting, enabling color or monochrome imaging without excessive noise. This makes it suitable for entryways, corridors, and exterior areas with limited illumination.
• Q: Is this lens suitable for outdoor use?
• A: The lens is designed for surveillance environments and is compatible with weather- and camera-rated housings. For outdoor use, ensure the camera module and lens assembly are properly sealed and protected from environmental conditions.
• Q: What should I consider when choosing color vs. monochrome (B/W) versions?
• A: Color lenses deliver natural color detail in sufficient lighting, while B/W lenses can improve contrast and edge detail in low-light scenarios or when infrared illumination is used. Pick based on lighting conditions and the camera’s illumination strategy.
