Hanwha Techwin TEU-F16: 16-Channel Ethernet over UTP Extender with Pass-Through PoE

The Hanwha Techwin TEU-F16 is a compact, high-capacity solution designed to simplify and strengthen Ethernet dispersion across copper cabling in security, surveillance, and industrial network environments. Built as a 1U rack-mounted Ethernet over twisted pair extender, the TEU-F16 delivers robust, reliable performance for 16 separate channels at 10/100 Mbps while providing Pass-through PoE to powered devices along the same UTP path. This makes it an ideal choice for expanding camera deployments, IP devices, or other network endpoints without the need for deploying additional switches or fiber infrastructure. By leveraging existing Cat5e/Cat6 cabling, the TEU-F16 reduces installation costs, minimizes downtime, and supports scalable growth in busy control rooms, data centers, and field sites.

• 16-channel Ethernet over UTP with Pass-through PoE: Extend 16 independent 10/100 Mbps Ethernet channels over copper while delivering PoE to remote cameras and devices along the same cable run.
• 1U rack-mount form factor: A compact, rack-ready enclosure that fits neatly into standard equipment rooms, networking closets, or CCTV installations for clean, professional deployments.
• Local power operation: The TEU-F16 is powered from a local AC/DC supply at the device site, ensuring stable operation without relying on PoE to power the extender itself.
• Supports standard copper cabling: Works seamlessly with commonly used Cat5e/Cat6 copper cables, minimizing the need for special cabling or rewiring projects.
• Designed for surveillance and network scalability: Ideal for multi-camera systems, security racks, and scalable IoT networks where trusted, uninterrupted data transfer and PoE delivery are critical.

The TEU-F16 is purpose-built to address real-world deployment challenges where a mix of high-channel count, reliable Ethernet, and PoE capability must coexist over a single copper backbone. In security environments, where cameras, switches, and other IP devices must operate in harmony, this extender provides a practical bridge between central network infrastructure and distributed endpoints. Its 1U design minimizes rack footprint while maintaining straightforward access for maintenance and upgrades. With 16 parallel channels, administrators can allocate dedicated bandwidth and plug each camera or device into a dedicated path, reducing interference and improving overall network performance. The pass-through PoE feature further simplifies installation by allowing powered devices to draw energy directly from the same UTP cable used for data transport, eliminating the need for extra power drops or multiple cables per device. In addition, HANWHA Techwin’s engineering focuses on reliability and ease of integration, ensuring compatibility with existing network switches, PoE injectors, and surveillance management software for a smooth, plug-and-play experience.

• Flexible deployment scenarios: Use TEU-F16 in security closets, data centers, or remote sites to extend Ethernet reach and power PoE devices without additional infrastructure.
• Quality of service for surveillance networks: By isolating channels and maintaining consistent data rates, the extender supports stable video streams and reliable device management across all connected endpoints.
• Redundancy and future-proofing: The 16-channel design accommodates current camera fleets and leaves room for expansion as surveillance needs grow, helping to protect the return on investment.
• Easy integration with existing infrastructure: Built around standard Ethernet practices, the TEU-F16 blends into typical IT ecosystems and CCTV deployments without requiring specialized training.
• Robust build and field-ready reliability: Engineered for operational endurance in demanding environments, with attention to thermal management, EMI considerations, and resilience in rack-mount configurations.

Technical Details of TEU-F16

• Channel count: 16 independent Ethernet channels over twisted pair to support multi-point connections.
• Data rate per channel: 10/100 Mbps Ethernet across each channel, enabling compatible IP cameras, video encoders, and PoE devices.
• PoE capability: Pass-through PoE on the same UTP paths, allowing powered devices to receive energy from the network while data is transmitted over copper.
• Form factor: 1U rack-mounted enclosure designed for standard 19-inch rack installations.
• Power configuration: Local power supply required for the TEU-F16; does not rely on PoE to operate the extender itself.
• Cabling: Optimized for use with standard Cat5e/Cat6 copper cables, offering flexibility and cost savings in cabling choices.
• Environment and compatibility: Suited for surveillance networks, data centers, and enterprise IT environments. Compatible with existing network switches and PoE devices typically deployed in these settings.
• Installation footprint: Compact 1U design supports tidy rack integration with other network appliances, power supplies, and cooling arrangements.

How to install TEU-F16

• Mount the TEU-F16 in a standard 19-inch rack within the equipment rack or communications cabinet. Ensure adequate ventilation and clearance for cooling.
• Connect the uplink or main data path to your central network switch, router, or PoE switch using standard Cat5e or Cat6 copper cables. Route each channel's out-of-band connections to the desired devices or cameras.
• Connect the 16 channel outputs to each target device or IP camera using separate UTP cables. If powering devices via PoE, ensure the connected switches or injectors provide compatible PoE power levels for the devices in use.
• Plug the TEU-F16 into a local power source with the included power supply. Verify that the unit powers on and that any status LEDs indicate healthy operation as per the product’s user guide.
• Power up connected PoE devices and perform a basic network test. Confirm that each channel communicates correctly, and monitor video streams or data throughput to ensure stable performance across all 16 channels.

Frequently asked questions

• What applications is the TEU-F16 best suited for? The TEU-F16 is ideal for surveillance and security deployments where multiple IP cameras or PoE devices must be connected over copper cabling, providing extended reach and centralized power management through pass-through PoE.
• Does the TEU-F16 require PoE to operate? No. The TEU-F16 is powered by a local power supply and does not rely on PoE to power the extender itself, preserving PoE budgets for connected devices.
• Can I use standard Ethernet cables with TEU-F16? Yes. The TEU-F16 is designed to work with standard Cat5e or Cat6 copper cabling, making it compatible with most existing network infrastructures.
• How many devices can I power via PoE through the TEU-F16? The TEU-F16 provides pass-through PoE across its 16 channels, enabling PoE-powered cameras and devices on the downstream side, subject to the PoE budget of your uplink switch or injector.
• Is a rack-mount installation required? The TEU-F16 is a 1U rack-mounted extender, which is ideal for organized, space-efficient deployments in server rooms, data centers, or CCTV closets.
• Can I mix non-PoE devices with PoE devices on the same TEU-F16? Yes. Since the unit provides PoE pass-through on certain channels, you can connect both PoE and non-PoE devices as needed, with PoE power supplied along the designated channels where applicable.
• What environments is the TEU-F16 designed for? It is designed for demanding surveillance, IT, and security installations where multiple Ethernet channels and PoE are required over copper cabling while occupying minimal rack space.
